- Page 1 NEW HOLLAND OPERATOR’S MANUAL 48” Snow Blade LS Yard Tractors Model No. 715648006–T1S0001 & Up Publication Number: 86619977 10/2000...
-
Page 2: Table Of Contents
Thank you for purchasing a New Holland product. Caution signals a hazard that may cause minor or All of us at New Holland want you to be completely moderate injury if the recommended precautions are not satisfied with your new product, so feel free to contact followed. -
Page 3: Assembly
Assembly Loose Parts Note: Use the chart below to identify parts used for assembly. DESCRIPTION QTY. Blade assembly Control rod Cotter pin, 1/8 x 1 in. (25 mm) Assembling the blade Frame assembly Bolt, 3/4-16 x 3-3/4 in. (95 mm) Locknut, 3/4 in. -
Page 4: Assembling The Blade
Assembling the Blade 7. Slide the channel between the frame mount and secure it with a 3/4-16 x 3-3/4 in. (95 mm) bolt and a 3/4 in. locknut (Fig. 4). 1. Lift and rotate the channel and trip spring assembly so that the holes align with the lower blade mounts. -
Page 5: Installing The Blade
3. Remove the muffler shield. 5. Close the latch levers and secure them with 3/4 in. (19 mm) clevis pins and small hairpin cotters (Fig. 7). 4. Install four 3/8-16 x 1 in. (25 mm) carriage bolts into keyhole slots in axle bracket (Fig. 5). 5. - Page 6 10. Close the latch by rotating it back until the release 13. Position the notch in the lift plate around the left side button pops out to lock it in place (Fig. 9). tractor lift arm and slide the lift plate onto the attachment lift arm (Fig.
- Page 7 7. Slide the fitting through the slot and push it to the right, ensuring there is a jam nut on each side of the frame (Fig. 13). m05040 & 5041 9, 10, & 11 Figure 13 1. Rear view 5. Fitting 2.
-
Page 8: Removing The Blade
12. Pull down on the cable jacket to remove slack and secure the cable to the handle using three cable clips, three 1/4 x 1 in. bolts, and three 1/4-20 in. locknuts (Fig. 12). Installing the Steering Stops 1. Align a steering spindle stop in front of the rear tabs on each front wheel spindle so that the stops contact the axle during tight turns and prevent the wheels from contacting the blade frame (Fig. -
Page 9: Operation
Operation Caution If you hit fixed objects with the blade, the tractor could stop abruptly, causing you to lose control, personal injury, and equipment damage. Travel at a safe, slow speed. Check the area to be plowed and mark all fixed 1246a objects so you can avoid them. -
Page 10: Adjusting Dial-A-Height
The top hole provides the greatest scraping pressure and 3. Move the lift lever forward to lower the blade. the bottom hole provides the least scraping pressure (Fig. 23). New Holland recommends using the second hole from the top for removing snow. -
Page 11: Tips For Using The Blade
Oil the linkages Yearly/Storage Service Examine the scraper for wear and replace if damaged or worn Paint chipped surfaces (Paint is available from your Authorized New Holland Dealer.) Caution If you leave the key in the ignition switch, someone could accidently start the engine and seriously injure you or other bystanders. -
Page 12: Reversing The Scraper Blade
Grease the Channel Pivot 1. Lower the attachment. 2. Set the parking brake, stop the engine, and remove the ignition key. 3. Clean the area around the channel pivot with a rag. Apply grease to the pivot bolt, frame and sector (Fig. - Page 16 Publication No. 86619977 Form No. 3324-751 Rev A New Holland North America, Inc., New Holland, PA Printed in U.S.A.
