Summary of Contents for Mealink HDMX0009M1
- Page 1 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product.
- Page 2 Introduction HDMX0009M1 is an 16-by-16 HDMI matrix. It allows any of the Sixteen Input Channels (HDMI) to be routed to any of the Sixteen Output Channels (HDMI), no matter the source is HDCP or not. Users can choose several different ways to control the matrix: by Push button , RS232, and Ethernet control.
-
Page 3: Product Overview
HDMI Matrix (Routing Type) Product Overview Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Features ■ Allows up to eight HDMI audio/video devices to be independently switched to ... - Page 4 Notice We. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth.
-
Page 5: Package Contents
Package Contents ■ 1x Main unit. P/N_ HDMX0009M1. ① 1x Power line ② ③ 1x CD-ROM(Control software operating instructions). ④ Mounting ears. NOTE: PART NUMBER (Abbreviation as P/N). ■ Panel Descriptions ① LCD indicator, displays the status of each output port. -
Page 6: Connections And Operations
Connect the HDMI input source ( such as HD-DVD/ PS3/STB etc.)Into HDMX0009M1. Connect HDMI OUT of HDMX0009M1 to display equipment. Power on the input source you want to show. ( Keep the unused input power off, otherwise it may interfere the normal display). - Page 7 Plug the power cable into HDMX0009M1. Turn on the displays you want to watch. Use the Front Panel, RS232 and Ethernet port to control. 3. Control via RS232 and Ethernet. 1) The Interface of HDMX0009M1 control...
- Page 8 2) The Message Window 2.1) Receive Window The “output window” will show the message received from MX1616.It will send out the message about “operation results” as below. 2.2) Status Button Click the Output window x, will pop up on the right window, click the drop-down menu, select the input source 2.3) Setting Button Matrix running configuration, For example 16x16 matrix selection 16.
- Page 9 2.4) IP SET Button Click this button to set IP address for LAN control (for example: 192.168.0.3). Set: Matrix ip address Port: 10002 Open: open Ethernet Close: close Ethernet 2.5) RS232 Set button Set: set serial,baudrate. Open: open RS232 Close: close RS232 2.6) Keyboard control Mode of operation is similar to the front panel buttons control...
- Page 10 ■ Specifications Operating Temperature Range 0 to +35° C (32 to +95° F) Operating Humidity Range 5 to 90 % RH (no condensation) Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) DTV/HDTV:4Kx2K/3D/ 1080P/1080i/720P/ Video Format Supported 576P/480P/576i/480i Audio Format Supported DTS-HD、Dolby HD...
-
Page 11: Replacement Parts
Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: ... - Page 12 Labor(90) Days)which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or replace will be made by the warrantor. During the “Labor”...
