- Page 1 GETTING STARTED Onion Omega2S Development Kit Getting Started Guide Version 1.0 Omega2 IoT Computer Onion Omega2S Development Kit...
- Page 2 Revision History Revision Date Description March 17, 2018 Initial release Onion Omega2S Development Kit...
-
Page 3: Table Of Contents
5.1.1 Using GPIOs 5.1.2 Using USB Storage 5.1.3 Using an SD card 5.1.4 Rebooting the Omega2S 5.1.5 Factory Reset 5.2 Removing Omega2S from the Dev Board 6. Additional Resources 6.1 Hardware Setup Video 6.2 Omega2S Datasheet 6.3 Schematics 6.3.1 Development Board Schematics 6.3.2 Omega2S Reference Design Schematics... -
Page 4: Introduction
DDR2 DRAM, Flash memory, and all of the components necessary to allow this product to be a fully functional and complete device. The Omega2S Development Board has an easy insertion socket for the Omega2S Module, and exposes all of the available Omega2S hardware I/O: including the USB Port, Ethernet Port, Dual Reset Functions, and Connectors Pins for all other I/O. -
Page 5: Hardware Overview
Omega2S. It has 42 additional I/O pins, and a uFL connector for an external antennas. It is available in two memory size versions, similar to the Omega2: ●... -
Page 6: Differences From The Omega2
Pinout Diagram: 2.1.1 Differences from the Omega2 Other than the obvious form-factor differences from the through-hole Omega2, the Omega2S also features the following: ● Exposes more IOs: 43 General Purpose I/Os (as opposed to the 21 available on the through-hole version) ●... -
Page 7: Sd Card Development Board Overview
2.2 SD Card Development Board Overview This version features an SD card slot. Onion Omega2S Development Kit... -
Page 8: Emmc Development Board Overview
2.3 eMMC Development Board Overview This version features an on-board 8GB eMMC storage module. It does not feature an SD card slot as they are mutually exclusive. Onion Omega2S Development Kit... -
Page 9: Hardware Setup
Steps: ● Insert Omega2S into the socket ○ Omega2S has 3 sides with pins, make sure to match the sides with pins to the rail-pins on the Dev Board socket ○ Make sure your Omega is plugged and pressed down to complete the connection... - Page 10 ● Socket pin combing ○ Ensure the connection between the Omega2S and socket by using your thumb to comb the rail-pins of the Omega2S socket on the Development Board to avoid disconnected pins and undefined behavior (Please see the picture below) ●...
- Page 11 ○ For best results, use a high-quality cable that is at most 2m (6ft) long ● Omega LED indicates booting ○ LED218 Blinks on Boot. Once booted, it will become solid, meaning that the Omega has completed its boot sequence. ○ LED243 Stays solid at all times when powered up Onion Omega2S Development Kit...
- Page 12 Onion Omega2S Development Kit...
-
Page 13: First Time Setup
4. First Time Setup When Omega2S has completed the boot sequence, LED218 will stop blinking and remain solid. This takes approximately 1 minute. Since the Dev Board has a USB-to-Serial chip on-board, use USB connection to connect to the serial terminal. -
Page 14: Using An Sd Card
5.1.3 Using an SD card ● Omega2S Development Kit SD Card Slot Version comes with an on-board SD card slot ● SD Cards up to 128GB are supported ● For further details and information about using SD cards, follow our guide on ... -
Page 15: Rebooting The Omega2S
Omega 5.1.5 Factory Reset The Omega2S can be restored to a “factory” state in case of data corruption or lost configuration files. Performing a Factory Restore on the Omega will revert all files to the default for the currently installed firmware, a ll other files will be deleted. -
Page 16: Removing Omega2S From The Dev Board
First, power off the Omega and Dev Board. Use the hole in the Omega2S socket on the Dev Board to push the Omega2S from the underside with your finger. Push the Omega until it is free of the socket rail-pins, then grab it from the opposite side. -
Page 17: Additional Resources
6. Additional Resources 6.1 Hardware Setup Video Refer to our visual guide for more clarity on the safely inserting and removing the Omega2S to and from the Development Board socket: h ttps://youtu.be/aoYadArVJPw 6.2 Omega2S Datasheet To learn more about the Omega2S moudle, see the ... - Page 18 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Onion OM2S-DK-EM OM2S-DK-SD...
