ST-4000i

FLASH ANALYZER

Intelligent Series

OPERATOR MANUAL

Table of Contents

Need help?

Do you have a question about the Intelligent Series and is the answer not in the manual?

Questions and answers

Summary of Contents for American Aerospace Intelligent Series

Page 1 ST-4000i FLASH ANALYZER Intelligent Series OPERATOR MANUAL...
Page 2 If available, any upgrades will be performed at your next calibration by American Aerospace Corporation. To check the latest Firmware & Application version, product updates & access to Instructional videos visit: http://www.america.aero/st-4000i/ ST-4000i Technical Support American Aerospace Corporation ST-4000i Service & Support PHONE +1(386) 822-9550 E-mail st4000i@america.aero PAGE 2...
Page 3: Table Of Contents
American Aerospace Corporation ST-4000i Flash Analyzer ST4000i-OM-01 Rev C ST-4000i Flash Analyzer Table of Contents Introduction ....................4 ST-4000i Technical Specifications ............. 4 ST-4000i Quick Reference Guide ............... 5 Display Style Selection ................6 ST-4000i Test Mode Functions ..............7 Testing Instructions ..................
Page 4: Introduction
American Aerospace Corporation ST-4000i Flash Analyzer ST4000i-OM-01 Rev C Introduction The ST-4000i Flash Analyzer is an all in one system developed by American Aerospace Corporation for the primary purpose of measuring aircraft strobe light intensities. The system measures strobe light output (Xenon & LED) intensity in effective (Candela), as required by the Federal Aviation Regulations (FAR), FAR 25.1401(f).
Page 5: St-4000I Quick Reference Guide
B. Micro USB female port – For charging and extraction of saved data. C. Mini USB female port – For charging the battery & running external American Aerospace Corp ST-4000i software. D. Charging LED – LED lit when device is charging (off when not charging).
Page 6: Display Style Selection
ST4000i-OM-01 Rev C Display Style & Selection On Start up the American Aerospace Logo will be displayed during boot up, after which the home screen will load in approximately 17 seconds. Figures 4.0 & 4.1. On the Home screen six (6) apps will appear. “RED”, “WHITE”, “SETTINGS”, “FILES”, “INFO”...
Page 7: St-4000I Test Mode Functions
American Aerospace Corporation ST-4000i Flash Analyzer ST4000i-OM-01 Rev C ST-4000i Test Mode Functions Operating RED or WHITE Light Test Mode, the instrument automatically counts nine (9) flashes and then takes the average and displays the results in Effective Candela units. To repeat the measurement, simply press “START”...
Page 8 American Aerospace Corporation ST-4000i Flash Analyzer ST4000i-OM-01 Rev C When the unit measures more than 999 eff cd, for example 3304 eff cd, the display will read “3.304 keff cd”. FIGURE 5.2: SAMPLE READING Additional display messages that may appear are as follows: “PROCESSING”...
Page 9: Testing Instructions
American Aerospace Corporation ST-4000i Flash Analyzer ST4000i-OM-01 Rev C Testing Instructions The following instructions apply when testing aircraft strobe lights. When the system is used in a shop facility environment, the same procedures still applies. The system is calibrated to measure the strobe light intensity with the detector located eight (8) feet (2.44 meters), +/- 2 inches (+/- 5 cm) from the light source.
Page 10 American Aerospace Corporation ST-4000i Flash Analyzer ST4000i-OM-01 Rev C E. Turn on the strobe light. Allow the strobe a few minutes to warm up before taking any readings to assure light source has stabilized. WARNING: ULTRAVIOLET (U.V.) PROTECTIVE EYE-WEAR MUST BE WORN BY THE OPERATOR(S) WHEN STROBE LIGHTS ARE FLASHING.
Page 11: Calibration Requirements
Laser distance meter. Due to the sophisticated nature of this system, we do not recommend that the user attempt to make repairs. Return the unit to American Aerospace Corporation for corrective actions. The optical windows should be carefully cleaned from time to time using common window cleaning fluids. Be careful to avoid spraying or dripping fluid into unit.
Page 12: Environmental Specifications And Considerations
This warranty does not apply to damage resulting from accident, alteration, abuse, misuse, loss of parts or repair by other than American Aerospace Corporation or its authorized agents. The equipment will be repaired or replaced, at our option, without charge to the owner for parts or labor incurred in such repair.
Page 13: Illustrated Parts Catalog
American Aerospace Corporation ST-4000i Flash Analyzer ST4000i-OM-01 Rev C ILLUSTRATED PARTS LIST Item No. Part No. Description Quantity ST-4000i Flash Analyzer ST-4000-1 Instrument ST-4000-2 Detector ST-4000-3 Laser Distance Meter ST-4000-4 Micro USB Charger and Data Cable ST-4000-5 USB Charger Base...

This manual is also suitable for:

St-4000i
