PCE Americas PCE-SLD 10 Operation Manual

Sound level data recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SD card real time data recorder
4 - 20 mA output
SOUND LEVEL DATA RECORDER
Model : PCE-SLD 10
OPERATION MANUAL
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: (561) 320-9162
Fax: (561) 320-9176
info@pce-americas.com
www.pce-instruments.com/english
www.pce-instruments.com
Your purchase of this
SOUND LEVEL DATA RECORDER
with 4 - 20 mA output, marks a
step forward for you
into the eld of
precision measurement.
Although this meter a
complex and delicate
instrument, its durable
structure will allow
many years of use if
proper operating
techniques are
developed. Please read
the following
instructions carefully
and always keep this
manual within easy
reach.
PCE Instruments UK Ltd.
Unit 11
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: (0) 2380 98703 0
Fax: (0) 2380 98703 9
info@pce-instruments.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCE-SLD 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for PCE Americas PCE-SLD 10

  • Page 1 SD card real time data recorder 4 - 20 mA output SOUND LEVEL DATA RECORDER Model : PCE-SLD 10 Your purchase of this SOUND LEVEL DATA RECORDER with 4 - 20 mA output, marks a step forward for you into the eld of precision measurement.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. FEATURES....................2. SPECIFICATIONS..................3. FRONT PANEL DESCRIPTION..............4. MEASURING PROCEDURE................ 4-1 Sound Pressure Level Measurements (SPL)......... 4-2 Sound Pressure Measurements Range select………………….. 7 4-3 Sound Frequency weighting select ............. 4-4 Sound Time Weighting select ………......………….. 4-5 Data Hold......................4-6 Data Record ( Max., Min.

  • Page 3: Features

    1. FEATURES * Frequency and Time weighting are designed to meet IEC 61672 class 2. * A & C weighting networks comply with standards. * LCD is dot-matrix with backlight and easy reading. * Data-logger and Sound level meter. * 0.5" standard microphone head. * Time weighting (Fast &...

  • Page 4: Specifications

    2. SPECIFICATIONS Circuit Custom one-chip of microprocessor LSI circuit. Display LCD size : 50 mm x 30 mm LCD with backlight ( ON/OFF ). Measurement SPL : Sound pressure level Type Measurement SPL：30-80,50-100,80-130 , Auto ( 30 - 130 dB ). Range Resolution 0.1 dB.
  • Page 5 Frequency Characteristics of A & C. Weighting Network A weighting : The characteristic is simulated as "Human Ear Listing" response. Typical, if making the environmental sound level measurement, always select to A weighting. C weighting The characteristic is near the "FLAT" response.
  • Page 6 Calibration Build in external calibration(key), easy to calibrate on 94 dB level by Key Adjustment. * Calibrated via external SOUND CALIBRATOR ( PCE-SC 42, optional ). PCE-SC 42 class 2 sound calibrator Calibrator Datalogger Auto 5,10,30,60,120,300,600,1800, Sampling Time 3600 seconds Setting range Memory device external memory device :...
  • Page 7 230 g/ 0.51 LB. (without battery) Dimension 132 x 80 x 32 mm. ( 5.2 x 3.1 x 1.3 inch ). Accessories 1 x Decibel meter PCE-SLD 10, 1 x Microphone, Included ..1 x Wall holder, 1 x Memory card, …………………...

  • Page 8: Front Panel Description

    3. FRONT PANEL DESCRIPTION Fig. 1 3-1 Display. 3-11 Stand 3-2 Power Button( Backlight Button ) 3-12 Battery cover/ Battery compartment 3-13 Screw of the battery cover 3-3 ▲ Button ( Range ) 3-4 REC Button ( HOLD ) 3-14 Hanging unit (with sticker) 3-5 TIME Button (Set) 3-15 Reset Switch.

  • Page 9: Measuring Procedure

    4. MEASURING PROCEDURE 4-1 Sound Pressure Measurements (SPL) In SPL mode the display shows readings of the sound pressure level. 1) Power ON the meter by pressing and holding the " Power Button " ( 3-2, Fig. 1 )for at least 1.5 seconds, the meter's default function is "...

  • Page 10: Sound Time Weighting Select

    4-4 Sound Time Weighting select According to various measuring sound source, by pressing the "▼ ( Time Weighting) Button " ( 3-6, Fig. 1 ) once to select the Time Weighting ( Fast or Slow or PEAK Fast ) . Note : a.

  • Page 11: Lcd Backlight On/Off

    b) To exit the memory record function, just press the " REC " button > 2 seconds at least. The display will revert to the current reading. 4-7 LCD Backlight ON/OFF After power ON, the " LCD Backlight " will light automatically.

  • Page 12: Datalogger

    5. DATALOGGER 5-1 Preparation before execute datalogger function a. Insert the SD card Prepare a " SD memory card " ( 1 GB to 16 GB, optional ), insert the SD card into the " SD card socket " ( 3-17, Fig. 1). The front panel of the SD card should face against the left side plastic case.
  • Page 13 at the same time the measuring data along with the time information will be saved into the memory circuit. Remark : How to set the sampling time, refer to Chapter 7-2, page 16. b. Pause the datalogger During execute the Datalogger function , if press the "...

  • Page 14: Check Time And Sampling Time Information

    5-3 Check time and sampling time information During the measurement if press " TIME Button " ( 3-5, Fig. 1 ) once, the LCD display will present the time and sampling time information of Year/Month/ Date , Hour/ Minute/Second, and sampling time information in second unit.

  • Page 15: Saving Data From The Sd Card To The Computer

    6. Saving data from the SD card to the computer ( EXCEL software ) 1) After execute the Data Logger function, take away the SD card out from the " SD card socket " ( 3-17, Fig. 1 ). 2) Plug in the SD card into the Computer's SD card slot ( if your computer build in this installation ) or insert the SD card into the "...
  • Page 16 EXCEL graphic screen ( for example )

  • Page 17: Advanced Setting

    7. ADVANCED SETTING Under do not execute the Datalogger function, press the " TIME Button " ( 3-5, Fig. 1 ) continuously at least 1.5 seconds will enter the " Advanced Setting " mode. then press the "TIME Button " (3-5, Fig. 1 ) once a while in sequence to select the six main function, the lower display will show : DATE……...

  • Page 18: Set Sampling Time

    2) After set all the time value ( Year, Month, Date, Hour, Minute, Second ), the screen will jump to " Set sampling time character " setting screen ( Chapter 7-2 ). Remark : After the time value is setting, the internal clock will run precisely even Power is off ( The battery is under normal condition, no low battery condition ).

  • Page 19: Set Beeper Sound On/Off

    7-4 Set beeper sound ON/OFF When the lower display show " BEEP " 1) Use the " ▲ Button " ( 3-3, Fig. 1 ) or " ▼ Button " ( 3-6, Fig. 1 ) to select the upper text to " YES " or "...

  • Page 20: Sd Memory Card Format

    2) After select the upper text to " USA " or " EURO ", press the " ENTER Button " ( 3-7, Fig. 1 ) will save the setting function with default. 7-6 SD memory card Format (Suggest using AC to DC Adapter) When the lower display show "...

  • Page 21: Power Supply From Dc Adapter

    8. POWER SUPPLY from DC ADAPTER The meter also can supply the power supply from the DC 9V Power Adapter. Insert the plug of Power Adapter into " DC 9V Power Adapter Input Socket " ( 3-9, Fig. 1 ). 9.
  • Page 22 Meter (9W 'D" Connector) Center Pin..........Pin 4 (3.5 mm jack plug) Ground/shield........... Pin 2 2.2 K resistor Pin 5 The 16 digits data stream will be displayed in the following format : D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0 Each digit indicates the following status : Start Word When send the SPL display data = 1...

  • Page 23: Frequency Weighting Characteristics Calibration

    11. CALIBRATION 1) Prepare the optional " SOUND CALIBRATOR "PCE-SC 42 ( set range to 94.0 dB ). Power on the Sound Calibrator & plug calibrator output socket into the " Microphone " head ( 3-20, Fig. 1 ) of the Sound Level meter.

  • Page 24: Toneburst Response (Fast & Slow)

    13. TONEBURST RESPONSE ( F/S ) CHARACTERISTICS Max. response Tolerance Charac. ref. continuous ( IEC 61672 Class 2 ) signal F ( Fast ) 200 ms - 1.0 dB ± 1.0 dB - 4.1 dB ±1.0 dB S ( Slow ) 500 ms...
