Kupu

screw installation

Need help?

Do you have a question about the Kupu Series and is the answer not in the manual?

Page 1 Kupu screw installation...
Page 3 Pull the red battery-Protection taPe away.
Page 4 Make Marks for screw holes. You can direct your smoke alarm with the aid of the direction arrow. The direction arrow should point in the same direction as the sides of the smoke alarm.
Page 5 drill holes for the screw anchors. Please use Ø 6mm drill bit.
Page 6 Place the screw anchors into the drilled holes.
Page 7 Place the install Plate to ceiling. Remove the installation plate of the smoke alarm by turning it counterclock- wise and lifting it away.
Page 8 insert and drill the screws in Place. You can direct your smoke alarm with the aid of the direction arrow. The direction arrow should point in the same direction as the sides of the smoke alarm.
Page 9 Press kuPu against the installation Plate and turn it clockwise. You can make small changes in the position of the smoke alarm by turning it a few degrees in the direction you want.
Page 10 installation is done. Congratulations - you have made your home a safer place.
Page 11 for more our products visit w w w . j a l o h e l s i n k i . f i...
