- Page 1 EZ KLING™ user manual...
- Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.
-
Page 3: Table Of Contents
. e l a t i o n l i g h t i n g . c o m C O N T E N T S General Information Warranty Safety Guidelines Device Overview Installation DMX Operation Important Notes Menu Function Configuration Guide Setup Guide Technical Specifications Optional Accessories EZ KLING User Manual ™... -
Page 4: General Information
Please do not discard the shipping carton in the trash. Please recycle whenever possible. BOX CONTENTS (1) 5V Power Supply (1) Flex Pixel Tape Jumper First Cable (1) Clamp Mounting Bracket & (2) Screws Manual & Warranty Card EZ KLING User Manual ™... - Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...
-
Page 6: Warranty
No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof. -
Page 7: Safety Guidelines
M10 x 25 mm, also be sure the hardware is insert in the pre-arranged screw holes in the bracket of the device. Use the original packaging and materials to transport the device in for service. EZ KLING User Manual ™... -
Page 8: Device Overview
D E V I C E O V E R V I E W MODE Button SETUP Button UP Button DOWN Button Bare Wire Terminal Block 3pin DMX Output 3pin DMX Input Power Input RJ45 Network IN/OUT LCD Menu Display EZ KLING User Manual ™... -
Page 9: Installation
I N S T A L L A T I O N V I A M A G N E T O N B A C K P A N E L O R I N C L U D E D B R A C K E T EZ KLING User Manual ™... -
Page 10: Dmx Operation
000-255 AMBER/WHITE (0% - 100%) D M X A D D R E S S I N G The DMX address of the first LED lighting device connected to EZ KLING ™ must be set to 1 and the DMX addresses of additional LED lighting devices will depend on how many DMX channels each device occupies. -
Page 11: Important Notes
(50) EZ KLING units from a single network port of the Gigabit Ethernet Switch. A maximum of (2) output network ports of the Gigabit Ethernet Switch can be used, controlling a maximum of (100) EZ KLING ™ units. -
Page 12: Menu Function
(5) operation modes: LED TAPE, KLINGNET, ARTNET, ESTA ACN, and OPTION, which can be selected by pressing the MODE button. ELATION© EZ KLING™ S Y S T E M M E N U Specifications are subject to change without any prior written notice. - Page 13 LED Color Set ("RGB", "RGBW", "RGBA") will start to flash. Press the SET UP button again and the LCD display will show "H: xxx", then press the UP or DOWN buttons to enter the Pixel Height number EZ KLING ™...
- Page 14 SET UP button and the LCD display will show "U: ×××××", then press the UP or DOWN buttons to enter the desired universe address “U: 00001-32768” and press the SET UP button to confirm. EZ KLING User Manual ™...
- Page 15 C A U T I O N - D O I N G W I L L E R A S E A L L P R E V I O U S L Y S A V E D S E T T I N G S ! EZ KLING User Manual ™...
-
Page 16: Configuration Guide
. e l a t i o n l i g h t i n g . c o m C O N F I G U R A T I O N G U I D E EZ KLING User Manual... -
Page 17: Setup Guide
, you MUST close KlingNet Mapper in Media ™ ™ Master and restart it to remap the LED Tape or LED Lighting again to make the new EZ KLING setting changes take effect. ™ Connecting EZ KLING to a Computer using ARTNET to control LED Tape. -
Page 18: Technical Specifications
3. Connect the computer to the EZ KLING device using standard CAT5e cable. ™ 4. Connect the LED Tape to the Bare Wire Terminal Block on EZ KLING ™ 5. Map the LED Tape with your pixel mapping software (such as Generator or Patch in MADRIX 6. -
Page 19: Optional Accessories
Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. OPTIONAL ACCESSORIES ORDER CODE ITEM NARROW CLAMP PRO 2” Wrap Around Style Clamp FPT-JC Flex Pixel Tape Jumper First Cable AC3PDMX5PRO 5 ft. (1.5m) 3pin PRO DMX Cable Additional Cable Lengths Available EZ KLING User Manual ™...
