830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com
INSTRUCTIONS FOR INSTALLING ADJUSTABLE GATE PLATE (GTPLKIT & GTPL230X)
Drawing # 105959
Table of Contents
Device parts breakdown view with part numbers.................................
Install gate plate and strike bracket......................................................
Install Value Series or Advantex mounting plate and strike.................
Install 03GS, 08GS or 08GSN options for Value Series/Advantex......
Install ECL-230X mounting plate..........................................................
Install 03GS option for ECL-230X........................................................
Should you have a Qustion/Problem with your Detex device please call Detex Technical Support
from the job site at 1-800-729-3839 and choose option 2 on our menu. Please do not return the
product to the distributor.
For WARRANTY information,
scan code below or
go to www.detex.com/warranty
Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045
Owner's Copy
104918 sheet 1
104918 March 26, 2020
Sheet
2
3
4
5
6
7
For device installation videos,
scan code below or
go to www.detex.com/vidoes
B
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Detex GTPLKIT
- Page 1 104918 March 26, 2020 Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045 830-629-2900 / 800-729-3839 / Fax 800-653-3839 / Text photos only: 830-481-6433 / INTERNET: www.detex.com INSTRUCTIONS FOR INSTALLING ADJUSTABLE GATE PLATE (GTPLKIT & GTPL230X) Drawing # 105959 Table of Contents Sheet Device parts breakdown view with part numbers.........
- Page 2 PARTS BREAKDOWN Order Item Description Part # Strike Latch Receiver Bracket, Silver 107134 Protector, Gate Latch, Silver 107137 Adjustable Plate, Silver 107135 Adapter Plate Kit, 230X Strike (ECL-230X only) 104345 Hardware Kit, Gate Plate 105656 Optional Accessories Lock Box, Silver 03GS Spacer, Narrow Lever Trim, Silver 08GSN...
-
Page 3: Top View
Installing the Adjustable Gate Plate Tools required: Safety glasses, Pencil, Level, Power drill, Screwdriver, Tape measure 7-3/4" MAXIMUM if using optional 03GS Lockbox Latch side of gate STEP 1: For added security & for large gaps between gate Mark the BOTTOM of the PLATE and post, use Gate Latch Protector. - Page 4 Detex panic device gate mounted instructions (Value Series shown, Advantex similar) (continued from sheet 2) STEP A: Install device mounting plate Detex panic device mounting hardware supplied with Detex device. A1: Install device plastic A2: Align strike holes in template template into...
- Page 5 OPTIONAL: Required for 03GS Lock Box and 08GS / 08GSN Trim Spacers A6: Draw a vertical line between the backplate mount holes. NARROW WIDE STILE STILE device device Drill a 1/2" hole where the 2 centerlines meet. For 08GSN Trim Spacer For 03GS Lock Box A7: 08GSN ONLY: Drill two 1/4"...
- Page 6 ECL-230X device gate mounted instructions (continued from sheet 2) STEP B: Install device mounting plate Detex panic device mounting hardware supplied with Detex device. B1: Install adapter plate kit B2: Position template against (p/n 104345) adapter plate and align template 40"...
- Page 7 ECL-230X with 03GS Box B9: Drill four 1/4" holes at the locations shown below. B7: Draw vertical line through these marked locations B8: Drill 1/2" hole at the intersection of the 2 lines device 1/4" hole device 1/2" hole (ref) 1/4"...
