LED Indicators

Power LED is red.
SBS MODE LED is blue when this feature is selected.
HDMI 1LED is blue when this input source is selected and detected.
HDMI 2 LED is blue when this input source is selected and detected.
Status
Standby state
(Input power cord)
HDMI 1 input source
(Default)
HDMI 2 input source
HDMI 1 input source &
SBS mode enable
Power on & HDMI 2
input source & SBS
mode enable

Connection

Connecting the AC adapter

AC adapter
1
Power LED SBS MODE
(Red)
Off
Steady light
Steady light
Steady light Steady light
Steady light Steady light
1
2
4
HDMI 1
(Blue) (Blue)
Off Off
Off Steady light
Off Off
Steady light
Off
Power cord
2
HDMI 2
(Blue)
Off
Off
Steady light
Off
Steady light
