- Page 1 PANTHER Installation and operating guide KLIMASKLEP, ul. Orzechowa 3, 72-010 Przęsocin k/Szczecina tel.: (91) 432-43-42, tel.: (91) 432-43-49 e-mail: sklep@klimasklep.pl, www: www.KlimaSklep.pl...
- Page 2 PANTHER Condensate removal pump Installation and operating guide The PANTHER is a self-contained condensate removal system for use directly inside trunking and high- wall-mount air conditioners.The small remote sensor can be fitted inside the air handler whilst the pump unit can be positioned elsewhere.
-
Page 3: Safety Instructions And Warning
SAFETY INSTRUCTIONS AND WARNING Under normal use this equipment requires no user intervention. Installation, both fixing and electrical, and maintenance work shall be carried out only by the manufacturer or by its service center or in any case by a person having similar skills, so as to prevent any risk. - Page 4 The PANTHER sensor can be installed at any angle between horizontal and vertical so long as the breather tube inlet is above the condensate inlet (Fig. 3). The PANTHER sensor can also be tilted sideways up to 30° from horizontal (Fig. 2).
-
Page 5: Power Supply
Fig.9. Fig.7. Wiring Connections Connect the ground, live and neutral wire from the supply cable of the PANTHER pump to the supply terminals (see Fig.6) This product must be connected using a switch with contact separation in all poles that provide full disconnection from the power supply under over-voltage categories III. -
Page 6: Warranty
Continue to add water and the pump should switch to full power and the alarm contacts should open. Do not continue to add water if it becomes visible in the breather tube. Allow the PANTHER to clear the water. The pump should switch off and the alarm relay should reset. - Page 7 KLIMASKLEP EDC International Ltd. ul. Orzechowa 3 Brook House, Station Road, 72-010 Przęsocin k/Szczecina Pangbourne, RG8 7AN, UK tel.: (91) 432-43-42 Phone: +44 (0) 118 984 2991 tel.: (91) 432-43-49 Fax: +44 (0) 118 984 5300 e-mail: sklep@klimasklep.pl info@edcpumps.com www: www.KlimaSklep.pl...
