IMPLEMENTATION MANUAL
DOMINO - STANDARD ORGANIZER
FOR MODULAR INSIDE MUTUALISATION POINT
For installing and cabling this product in the best conditions, we recommend that you read and
apply this manual.
Document: ABS1376-01/A
Code: 20216641
Date: 02/12/2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOMINO Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Nexans DOMINO Series

  • Page 1 Document: ABS1376-01/A Code: 20216641 IMPLEMENTATION MANUAL Date: 02/12/2013 DOMINO - STANDARD ORGANIZER FOR MODULAR INSIDE MUTUALISATION POINT For installing and cabling this product in the best conditions, we recommend that you read and apply this manual.

  • Page 2: Table Of Contents

    DOMINO - STANDARD ORGANIZER Table of Contents INTRODUCTION ................... 4 1.1 TECHNICAL CHARACTERISTICS ................5 1.2 OVERVIEW OF THE PRODUCT................6 1.2.1 PRODUCT COMPOSITION ..............6 1.2.2 CONNECTION AREA ................10 1.2.3 PATCHING AREA ................. 12 1.2.4 ORGANIZER OVERVIEW ............... 14 1.2.5 TRAYS OVERVIEW ................
  • Page 3 DOMINO - STANDARD ORGANIZER UTILIZATION ..................42 5.1 CONNECTING A CUSTOMER ................42 5.2 USING ADAPTERS WITH AN EXTERNAL SHUTTER ..........43 ABS1376-01/A 3/44...

  • Page 4: Introduction

    DOMINO - STANDARD ORGANIZER INTRODUCTION The Domino for Modular Inside Mutualisation Point is designed to answer the needs of mutualization of optical wiring in buildings. The Domino ensures the following functions: Interconnection (by patching or splicing) between the optical fibres of the riser cable and those of the operators' network cables.

  • Page 5: Technical Characteristics

    DOMINO - STANDARD ORGANIZER 1.1 Technical characteristics DOMINO 100 DOMINO 165 DOMINO 210 Weight (empty) 2.6kg 2.7kg Colour RAL 7035 RAL 7035 RAL 7035 Dimensions LWH (mm) 450 x 150 x 100 450 x 150 x 165 450 x 150 x 210 REQUIRED TOOLS - Flat screwdriver - Small cruciform screwdriver...

  • Page 6: Overview Of The Product

    DOMINO - STANDARD ORGANIZER 1.2 Overview of the product 1.2.1 Product composition V. 100 ABS1376-01/A 6/44...
  • Page 7 DOMINO - STANDARD ORGANIZER V. 165 ABS1376-01/A 7/44...
  • Page 8 DOMINO - STANDARD ORGANIZER V. 210 ABS1376-01/A 8/44...
  • Page 9 DOMINO - STANDARD ORGANIZER The module is made up of the following elements: A plastic body Four removable panels A removable left side flange Two centring legs to ensure the correct alignment of the module during wall mounting Sectile seal holders A removable door A lock Four holes for wall or rail mounting...

  • Page 10: Connection Area

    DOMINO - STANDARD ORGANIZER 1.2.2 Connection area V. 100 Micromodules routing towards the plate Fibres routing towards another module Cables entry Clamping of the cables on the plate and Connection management of overlengths of tubes or micromodules Splicing and/or coupling, management of fibres overlengths Splicing and management...
  • Page 11 DOMINO - STANDARD ORGANIZER V. 165 At connection, possibility of managing supernumerary fibres V. 210 Splicing and/or coupling, management of fibres overlengths on 2 levels ABS1376-01/A 11/44...

  • Page 12: Patching Area

    DOMINO - STANDARD ORGANIZER 1.2.3 Patching area V. 100 1. Patching 3. Patchcords routing towards the other modules 2. When patching, management 3. Patchcords routing of patchcords overlengths towards the other modules V. 165 ABS1376-01/A 12/44...
  • Page 13 DOMINO - STANDARD ORGANIZER V. 210 ABS1376-01/A 13/44...

  • Page 14: Organizer Overview

    DOMINO - STANDARD ORGANIZER 1.2.4 Organizer overview Stand V. 165 Fig. Plate support device (stand) V. 100 V. 210 (Version 165 only) There are 2 possible positions A and B depending on module use (position A by default). Do not move the plate when the product is cabled.

  • Page 15: Trays Overview

    DOMINO - STANDARD ORGANIZER 1.2.5 Trays overview Small tray: Installation of splice supports Coiling of 250μm fibres overlengths. Max. capacity: 12 splices. G657 fibre only. Fig. Small tray Large tray: Installation of splice supports Coiling of 250μm fibres overlengths. Tray compatible with G652 fibre.

  • Page 16: Kits Provided

    DOMINO - STANDARD ORGANIZER 1.3 Kits provided Description Quantity Wall mounting kit including: - 2 or 4 screws - 2 or 4 plugs. Rail mounting kit including: - 2 or 4 screws - 2 or 4 oblong nuts. Standard clamping kit including: - 1 clamping support plate - 1 securing screw - 2 plastic collars...

  • Page 17: Gaining Access To The Module

    DOMINO - STANDARD ORGANIZER 1.4 Gaining access to the module 1.4.1 Opening - closing the door 1.4.2 Removing - reinstalling the door >90° 1.4.3 Opening - closing the organizer ABS1376-01/A 17/44...

  • Page 18: Mounting The Module

    DOMINO - STANDARD ORGANIZER MOUNTING THE MODULE 2.1 Removing the panels Remove one or several panels if necessary, according to your installation. The panels cannot be removed any more once the modules are stacked. It is recommended not to remove the module flanges before wall or rail mounting.

  • Page 19: Wall Mounting

    DOMINO - STANDARD ORGANIZER 2.2 Wall mounting Use the drilling template provided for drilling and installing the pegs. V. 100 V. 165 V. 210 Centring 1. If another module is already installed, align the new module using the 2 centring legs.
  • Page 20 DOMINO - STANDARD ORGANIZER 2. Install the module on the wall using the screws provided in the kit. (For version 100, use 2 diagonal holes.) V. 100 V. 165 V. 210 ABS1376-01/A 20/44...

  • Page 21: Rail Mounting

    DOMINO - STANDARD ORGANIZER 2.3 Rail mounting 1. Install the nuts: A. Insert the oblong nut in the dedicated C. Screw until the screw is level with the slot. nut or slightly protrudes. B. Mount the screw inside the module. D.

  • Page 22: Preparing The Organizer

    DOMINO - STANDARD ORGANIZER 3. Secure the module: A. When the module is in its final position, B. Tighten the screw: the nut must be push hard on the screw using a angled screwdriver to free the nut C. Repeat the same steps with the other screws.

  • Page 23: Adjusting The Position Of The Organizer Support Plate (Version 165 Only)

    DOMINO - STANDARD ORGANIZER 3.2 Adjusting the position of the organizer support plate (Version 165 only) This operation must be performed before cabling the product. A. Remove the right guide of the plate from its slot (A or B), then the left guide. Install the left guide in the adjacent slot (corresponding to position A or B), then clip the right guide.

  • Page 24: Preparing The Trays

    DOMINO - STANDARD ORGANIZER 3.3 Preparing the trays Splicing only : prepare the small trays. Splicing - coupling: prepare the large tray located under the plate. 1. Remove the tray plastic cover. 2. Detach and install the shutters (small tray only). 3.

  • Page 25: Installing The Trays

    DOMINO - STANDARD ORGANIZER 3.4 Installing the trays 1. Install the first 2 trays in slots A and B using the provided screws. 2. To add more trays, clip them onto the already installed trays. Distribute the trays evenly in slots A and B. Each slot can host up to : 2 trays (version 100) 4 trays (versions 165 and 210).

  • Page 26: Installing The Baskets

    DOMINO - STANDARD ORGANIZER 3.5 Installing the baskets Install the required baskets in slots A and B using the provided screws. If using module splitters, install only one basket in slot B. 3.6 Installing the adapters Clip the SC adapters at the front of the patch panel, with the polarising slot directed downwards.

  • Page 27: Installing The Pigtails

    DOMINO - STANDARD ORGANIZER 3.7 Installing the pigtails A. Connect the pigtails to the patch panel. Order of the splices in the tray: Route the fibres in the guiding pegs and to the combs at the entry of the trays. C.
  • Page 28 DOMINO - STANDARD ORGANIZER V. 165 Routing in the guiding pegs 1 2 3 4 5 6 Columns: Columns: V. 210 Trays connection order ABS1376-01/A 28/44...

  • Page 29: Installing The Splitters

    DOMINO - STANDARD ORGANIZER 3.8 Installing the splitters 3.8.1 Straight splitters A. Install the first splitter in the left basket, as illustrated Order of the in the opposite figure. splitters in the Connect the branches onto the patch panel. support: Proceed column by column, 4 fibres at a time.

  • Page 30: Module Splitters

    DOMINO - STANDARD ORGANIZER 3.8.2 Module splitters Fig. Module splitter Fig. Principle of installation of module splitters A. Install the first splitter on the upper left side of the plate. Perform a U-turn in the basket with the trunk and route it in the pathway to the large tray entry. C.
  • Page 31 DOMINO - STANDARD ORGANIZER Insert the trunks, starting from the inner side of the comb. Large tray Tray entry Repeat the same steps for the second splitter. Install the second splitter on the lower left side of the plate, the third splitter on the first one, the fourth splitter on the second one, etc.
  • Page 32 DOMINO - STANDARD ORGANIZER Particular case of version 210: sharing of branches between 2 plates 1. Mount the 1st splitter on the lower left side of the lower plate to allow routing of the branches towards the upper plate. 2. Connect the branches onto the upper patch panel as illustrated below. Splitter no 1 3.

  • Page 33: Connection

    DOMINO - STANDARD ORGANIZER CONNECTION Pre-install the 4.1 Clamping the cables securing screw. 1. Clamp the cable or fanout device on its support using 2 plastic collars (1). 2. To gain access to the seal holders (2), unclip the left side flange (3). Removable section 3.

  • Page 34: Splicing On Pigtails

    DOMINO - STANDARD ORGANIZER Pay attention to Print directed up- the orientation of wards the holder. Removable part towards the outer side Print directed down- wards The seals are recommended for cables Ø6 to 14 mm. 6. Put the seal holder back in its casing. 7.
  • Page 35 DOMINO - STANDARD ORGANIZER Towards upper plate Towards lower plate Fig. Version 210 3. Route the fibres in rings (A) et (B), then up to the trays entries. 4. Strip the fibres 5mm past the combs and perform the splices. ABS1376-01/A 35/44...

  • Page 36: Coupling

    DOMINO - STANDARD ORGANIZER 4.3 Coupling 1. Install the plastic cable guides (1). 2. If necessary, coil the fibres in the cable guides (1). Towards plate 3. Route the fibres in rings (A) and (B) and in the pathway (C), up to the large tray entry (D). Case of a straight splitter Coiling area Case of a module splitter...

  • Page 37: Pre-Terminated Cables

    DOMINO - STANDARD ORGANIZER 4. Strip the fibres 5mm past the comb and perform the splices. Large tray 5 mm Splice Pathway Comb for 900μm fibres 4.4 Pre-terminated cables 1. Install the plastic cable guides (1). Pre-install the 2. Clamp the fanout device on its support using securing screw.
  • Page 38 DOMINO - STANDARD ORGANIZER 5. Route the fibres through rings (A) and (B). 6. For connection, proceed column by column, 4 fibres at a time: Install the first 4 adapters onto the patch panel (C) Route the fibres through the rings (D) then coil fibre overlengths in basket (E) Removable support Repeat the same steps with the next 4 adapters and so on, until there are no more adapters to connect.

  • Page 39: Splicing Without Patching

    DOMINO - STANDARD ORGANIZER 4.5 Splicing without patching 1. Install the plastic cable guides (1). 2. Clamp the cable or fanout device on its support using 2 plastic collars (2) and mount them at the back of the module using the screw provided. 3.
  • Page 40 DOMINO - STANDARD ORGANIZER Particular case: use of a pre-terminated cable with miniflex. Pre-install the securing screw. To clamp the secondary fanout device, the screw must be installed at the bottom. V. 100 Towards plate Miniflex Cable 1 V. 165 Towards plate Cable 1 Miniflex...

  • Page 41: Fibre Sharing Between Two Modules

    DOMINO - STANDARD ORGANIZER 4.6 Fibre sharing between two modules A. Coil the fibres (cf. dotted lines) in module 1, as in the standard procedure. Route the shared fibres (cf. full lines) through the chimney to module 2 (upwards or downwards, depending on the configuration).
  • Page 42 DOMINO - STANDARD ORGANIZER UTILIZATION 5.1 Connecting a customer We recommend that: The first 2 operators use patchcord of length 1 metre The 3rd and 4th operators use patchcord of length 1.5 metre. 1. Identify the adapter of the customer to connect. 2.
  • Page 43 DOMINO - STANDARD ORGANIZER 5.2 Using adapters with an external shutter 1. Keep the shutter open to insert the connector's socket into the adapter. 2. Push until you hear a "click". ABS1376-01/A 43/44...
  • Page 44 DOMINO - STANDARD ORGANIZER ABS1376-01/A 44/44...
