Mobital LUNAR STORAGE BED Assembly Instructions

GENERAL NOTE: CAREFULLY REMOVE ALL WRAPPING MATERIALS AND ENSURE ALL PARTS
ARE ACCOUNTED FOR. ASSEMBLE ON A CLEAN FLAT SURFACE TO AVOID SCRATCHES. DO NOT
DISCARD THE PACKAGING UNTIL ITEM IS FULLY ASSEMBLED.
NOTES:
1. Check contents against list for quantity.
2. Familiarize yourself with the components and hardware by reviewing the Assembly Instructions.
3. Do not over tighten the screws and bolts as it may damage the threads.
4. Keep all hardware parts out of the reach of children.
5. Please "LIFT UP" the bed whenever you want to move it.
6. Do not pull down the spring frame without putting the mattress on first.

HARDWARE LIST

NO. DESCRIPTION
A Headboard Leg
(Pre-attached to
headboard)
B 50mm screw
(Pre-attached to
headboard)
C Frame Leg
D A-45
E B-45
F D-45 corner
G Hydraulic
H Cross bar
I M8*30mm
J Y8
K M8*20mm
L M8*40mm
M Bed Drawstring
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTION
QTY
COMPLETED ASSEMBLY
2 PCS
4 PCS
4 PCS
2 PCS
1 PC
6 PCS
2 PCS
6 PCS
56 PCS
1 PAIR
1 PC
6 PAIRS
1 PC
ITEM:
LUNAR
STORAGE BED
ITEM: LUNAR STORAGE BED
KING SIZE:1850*2050*310mm
QUEEN SIZE:1550*2050*310mm

STEP 1
