Zoran DVD Player Design---Vaddis 966
Project: DC0
Version: V20
Features:
D
1. Main:
ZR36966 + 1x16Mb/1x64Mb SDRAM + 4/8/16Mb FLASH + 2Kb EEPROM
(Default: 1x16Mb SDRAM + 8Mb FLASH, no EEPROM)
2. Full OPUs compatibility:
DV342 /Mitsumi502W /S71 /KHM313A /HOP1250 /SPU3153 /DPD20428 /Arima
(Default: Sanyo HD65)
3. Motor Driver:
BA5954
4. Audio:
- Internal and external ADC/DAC.
(Default: Internal ADC and DAC)
C
- 6ch/2ch audio output
(Default: 6 channel)
- Coax and optical SPDIF output
- Karaoke input
5. Video Output:
- CVBS / S-VIDEO / YPrPb(Shared with RGB, video switch added)
6. Standby function
7. Interface: USB, Memory Card, FTA, SCART.
B
Notes:
1. Assembly Note (See comments in every schematics page and Implementation/Implementation Option field of each component)
2. The Value of some components shown such as XXX [YYY]. "XXX" is default value, "YYY" is optional value.
3. High current type ferrite bead must be chosen in power supply circuit.
4. Need add "Implementaion" and "Implementation Option" fields when generates BOM.
Abbreviations:
A
1. NM means "Not Mount".
2. 0R = 0 ohm, 392R= 392 ohms.
3. FB means "ferrite bead". The value of FB such as "220Z" means the resistance =220 ohms @ 100MHz \(including DC and AC).
4. MP means "Mass Production".
5. R&D means "Research & Develop".
