Summary of Contents for Skeet-R-Gone Skeet-R-Gone
- Page 1 Installation and Operation Instructions Cover Page 1 8/31/2006 rev.1 NorthlineExpress.com http://www.northlineexpress.com Toll-Free 1-866-667-8454...
- Page 2 Table of Contents Congratulations on your purchase of this unique and exciting device. The Skeet-R-Gone system is designed to provide you years of use for mosquito control. In the following pages we will explain the set-up and operation of this system.
-
Page 3: Section #1 - System Overview And Requirements
6. Read and understand the installation and operation instructions completely. Answer: The Skeet-R-Gone system is a powerful and effective tool. End users and others who are benefiting by or are affected by its use, need to be aware of, and in full understanding of the system to utilize /operate it safely and effectively. - Page 4 Skeet-R-Gone injection point. For safety, you may assume that two backflow preventers are better than none. 4. Install the Skeet-R-Gone control box on the wall next to your sprinkler control panel (Sec 8: page 2 Fig-A3). Run the wire out to the location of the application/pump box (transformer and 8 pin plug end stay by the Skeet-R-Gone controller).
-
Page 5: Warranty
15. On your sprinkler controller, select and manually activate the closest zone to the gray application box. After a few moments, a green light on the Skeet-R-Gone control panel will illuminate. Your system is now pressurized. The Skeet-R-Gone safety feature will not allow the injection process to work without full system pressure prior to application (this light may stay on continuously). - Page 6 3. Manually activate a sprinkler zone on your sprinkler controller and verify that it is operating correctly. 4. On the Skeet-R-Gone controller, push the red "Activate" button for 10 seconds and then go out and check the measurement bottle to determine how much water you have dispensed in that 10 seconds, (usage amount will vary per individual water pressure and zone).
- Page 7 Section 4: Skeet-R-Gone Component Check List Pressure Switch 50" Wire O-Ring Hose Fitting Assembly Inlet Orifice Mixing and Check Chamber Fitting Rubber O-Ring Transformer Adapter Controller Fitting Teflon Tape Saddle Valve 1" Hose Ties. Pump/ Box Measuring, Wire Nuts. and Hose Storage Hose Clamps.
- Page 8 6. Allow zone to mix and clear (60-90 seconds) 7. Repeat steps 4 - 6 for coverage of remaining zones 8. Remove concentrate container and replace with beaker of water 9. Lock exterior enclosure and un-plug Skeet-R-Gone transformer (Re-printing is authorized) Section # 5 Page 8 8/31/2006 rev.1...
- Page 9 10 milliliter = 0.676 280 451 Tablespoon [US] *Note* For very in-depth conversions of fluids and flow information visit www.onlineconversion.com Remember- never use anything but liquid concentrate in Skeet-R-Gone Skeet-R-Gone will not dispense particulate or clumpy solutions Ounce to Teaspoon...
- Page 10 Skeet-R-Gone Inc. is governed by the laws of the State of North Dakota. Any legal issues or proceedings will be held in the State of North Dakota.
- Page 11 Section 8: Mixing Chamber Assembly Supplement This is the pattern by which the Mixing Assembly should be constructed Pressure Switch Hose Fitting Inlet Orifice/Check Fitting has Rubber O-Ring Very Important It is that the output From the Pump hose goes here. If assembled incorrectly, serious damage to the pump or spilling over of the concentrate could occur.
- Page 12 Section 8: Mixing Chamber Assembly Supplement Fig.A1 Fig.A2 Fig.A4 Fig.A3 Fig.A1 Enclosure placement Fig.A2 Injection site placement Fig.A3 Controller placement Fig.A4 Inside of exterior box Section # 8 Page 12 8/31/2006 rev.1 NorthlineExpress.com http://www.northlineexpress.com Toll-Free 1-866-667-8454...
-
Page 13: Section 9: Wiring Schematic
Remember to individually cap the Yellow and Orange wires Example of the completed wiring for the Skeet-R-Gone unit. The Yellow and Orange wires are for professional installers to use when priming from the exterior location and are not suggested for use by the homeowner.
