Sunset User's Manual
USER'S MANUAL
Powered Wheelchair - Sunset
This manual MUST be given to the user of the product.
BEFORE using this product, read this manual and save for future
reference.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sunset and is the answer not in the manual?

Questions and answers

Related Manuals for DNR Sunset

Summary of Contents for DNR Sunset

  • Page 1 Sunset User’s Manual USER’S MANUAL Powered Wheelchair - Sunset This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
  • Page 2 Sunset User’s Manual 1. Handle 2. Seat upholstery 3. Controller 4. Footrest 5. Footrest Shaft lock 6. Footplate 7. Front wheel 8. Foldable set 9. Armrest pad 10.Motors 11.Hand-rims 12.Hand Brake 13.Battery 14.Rear wheel mechanism 15.Anti-Tipper 16.Cross Bar 1. Assembly Your power wheelchair is shipped partially disassembled to protect during shipping.
  • Page 3 Sunset User’s Manual 1.2 Installing The Power Wheelchair 1.2.1 Before use, unfasten the power wheelchair. Please hold the handle and lightly expand the back support to the left and right. Please see Fig. 5. 1.2.2 Push down on one side of the seat frame, so your weight is applied from above with both hands.
  • Page 4 Sunset User’s Manual Warning: please be aware that the pinch may occur when assemble and store the power wheelchair. 1.4 Installing Controller and Connecting Cables 1.4.1 Assemble the controller connect rod on the right armrest bracket. Please fix the knob to fasten the controller.
  • Page 5 Sunset User’s Manual Fig. 15 Fig. 16 Reattach the controller connecting rod to the left armrest. Please see Fig. 17. Replace the controller and tighten the screws on the connecting rod.. Please see Fig. Fig. 17 Fig. 18 1.5 Connecting The Cable There is one plug in the other end of the controller.
  • Page 6 Sunset User’s Manual 1.6 Installing and Removing Footrest The footrest is swinging away and detachable. When the footrest lock lever is raised, the footrest can be removed or turn around 90 degrees to correct direction. Please see Fig. 21. 2. Operation 2.1 Generals...
  • Page 7 Sunset User’s Manual 2.2.2 Power Mode: the latch mechanism is flush with the central plane. Central plane Latch mechanism- Internal latch mechanism (Fluorescence water transfer print) 2.2.3 Switch from Power Mode to Manual Mode 2.2.3.1 Pull out the latch mechanism and slightly turn it.

  • Page 8: Fig

    Sunset User’s Manual 2.2.4.1 Pull out the latch mechanism and slightly turn it. 2.2.4.2 Then, release the latch mechanism and turn it till hear "click" sound. 2.2.4.3 Make sure the latch mechanism is flush as the central plane. 2.2.4.4 If it is flush, the power wheelchair is in power mode.

  • Page 9: Fig

    Sunset User’s Manual 2.4 Controller Retract Horizontally The controller is mounted with a mechanism which allows the controller to be locked in a forward or retracted position. When the controller pin is pulled out, the controller connects rod can be retracted horizontally.

  • Page 10: Fig

    Sunset User’s Manual 2.6 Anti-Tipper Adjustment 2.6.1 Disengaging the anti-tipper Removing the C type lock that locks the anti-tipper to the frame. Pull the anti-tipper out. Please see Fig. 30 and Fig. 31. Fig. 30 Fig. 31 2.6.2 Anti-tipper adjustment The C type lock must be removed first.
  • Page 11 Sunset User’s Manual Place the battery bag with battery on the front and left of power wheelchair main frame. There are two vertical Velcro passes over the power wheelchair main frame and battery bag. Please paste with Velcro firmly. Please see Fig. 35.
  • Page 12 Sunset User’s Manual Battery Gauge ON/OFF button Horn Button Speed Profiles Indicator Speed Button: Acceleration and Deceleration Joy Stick 3.1.1 ON/OFF button Press the ON/OFF button locates in front of the joystick to activate your power wheelchair. The controller’s LED light is on, the power wheelchair power is on.
  • Page 13 Sunset User’s Manual Pressing the speed, acceleration button will set the speed at the faster setting. Pressing the speed deceleration button will slow down the speed. The controller sets the reverse speed, acceleration and deceleration proportionally and automatically for your safety.
  • Page 14 Sunset User’s Manual Warning! Do not operate your power wheelchair in manual mode on a slope. 3.3 Electromagnetic Brakes Your power wheelchair comes with an Electromagnetic Brakes., i.e. an automatic magnetic disc safety brake which is also known as Fail-Safe brake.
  • Page 15 Sunset User’s Manual Fig. 38 Fig. 39 ② ① ③ ⑤ ④ Item Specification Power cord ① Ventilation hole ② Cooling Fan ③ Power Cord Lit Red: power is on. ④ POWER /ON :RED ON CHARGING : ORANGE ON Charging light ⑤...
  • Page 16 Sunset User’s Manual batteries fully charge for at least once every month. According to the battery type and condition of the battery, the battery usually can be fully charged in 3 to 6 hours. This will be indicated when the status LED light in the battery charger side panel turn green.
  • Page 17 Sunset User’s Manual flash red light. If meet this situation, please unplug AC cord over 10 seconds till the light off and then plug AC cord in again. 4.2.4 Charge the battery after removes it from the power wheelchair. Please remove the battery from the power wheelchair, and apply the step above.
  • Page 18 Sunset User’s Manual 5.1.2 Weekly Check 5.1.2.1 Inspect the connections by disconnecting the controller and charger harnesses from the electronics connector housing. Look for signs of corrosion. 5.1.2.2 Ensure that all parts of the controller system are securely fastened to your power wheelchair.
