- Page 1 TUNED DIPOLE ANTENNA MODEL AD-100...
- Page 2 All equipment manufactured by Com-Power Corporation is warranted against defects in material and workmanship for a period of two years from the date of shipment. Com-Power Corporation will repair or replace any defective item or material if notifi ed within the warranty period.
- Page 3 It is issued with the understanding that none of this material may be reproduced or copied without written permission from Com-Power. If You Need If you encounter problems while using the Model AD-100 Dipole antenna, con- tact Com-Power Corporation at (949) 459-9600. Assistance...
-
Page 4: Table Of Contents
Theory of Operation ................. 3-1 List of Figures Antenna Factors ..................1-3 Balun Loss ....................1-3 List of Tables Equipment Specifi cations ................. 1-2 Element type & collapsed length ............. 2-1 Dipole typical tuned lengths, factors & balun loss ........3-2 AD-100 Dipole Antenna... -
Page 5: General Information
1.2 General Description The Model AD-100 dipole is a the standard antenna for EMC measure- ments, site calibration and as a reference antenna for calibrating other antennas over the frequency range of 30 to 1000 MHz. -
Page 6: Equipment Specifi Cations
Table 1-1. Equipment Specifi cations Model: Dipole Antenna model AD-100 Frequency range: 30 MHz -1000 MHz Overall Balun1 (DB-1) 30 MHz - 65 MHz Balun 2 (DB-2) 65 MHz - 180 MHz Balun 3 (DB-3) 180 MHz - 400 MHz... -
Page 7: Antenna Factors
Figure 1.1 Antenna Factors for Tuned Dipole Antenna Figure 1.2 Typical Balun Loss AD-100 Dipole Antenna... -
Page 8: Operating Procedures
(III) beyond it. The DB-3 balun uses only the shorter collapsible elements (III). The DB-4 balun elements are already inserted and fi xed. Table 2.1, Tunable dipole antenna elements (in.) Element Type Length Fixed 27.5 Collapsible Collapsible 4.25 AD-100 Dipole Antenna... - Page 9 2.1.2 Setup for receiving signals The Model AD-100 dipole antenna can be used to measure EMI from an equip- ment under test (EUT). The antenna is mounted on either an antenna mast (such Model AM-400) or an antenna tripod. The coax cable is used to connect the antenna to the a measuring instrument.
-
Page 10: Theory Of Operation
Theory of Operation Functional Block Diagram 3.0 Overview This section describes the theory of operation of AD-100 Dipole Antenna. 3.1 Theory of Operation The tuned dipoles are standard antennas used for calibrating Open Area Test Sites (OATS), EMC measurement and as a reference antenna for calibrating other antennas. - Page 11 Due to the fi nite diameter of the elements, the optimum or tuned length of the dipole is found to be slightly less (approx. 4%) than determined by calculations. AD-100 Dipole Antenna...
