Summary of Contents for KonNad C2000-A2-SMD4240-AC5
- Page 1 Last updated: 2019-12-27 C2000-A2-SMD4240-AC5 User Manual Wi-Fi ⇋ 2AI + 4DI + 4DO 0-10V / 16bit Remote I/O Module — Wi-Fi I/O Module SinoCon Co., Ltd.
-
Page 2: Table Of Contents
C2000-A2-SMD4240-AC5 User Manual Catalog Catalog 1. Hardware Description 1.1. Specifications 1.2. Apprearance 1.3. Indicators 1.4. Port Description 1.5. Product Dimensions 1.6. Installation Method 2. Package Contents 3. Warranty Policy SinoCon Co., Ltd. www.sinoconsys.com 2 / 12... - Page 3 Copyright Notice ©2000 - 2019 SinoCon Co., Ltd. All Rights Reserved. Trademarks The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer This document only provides information about KonNaD products. No license to any intellectual property rights is granted by this document, including any intellectual property licenses, expressed or implied, or by any means.
- Page 4 C2000-A2-SMD4240-AC5 User Manual SinoCon Co., Ltd. www.sinoconsys.com 4 / 12...
-
Page 5: Hardware Description
C2000-A2-SMD4240-AC5 User Manual 1. Hardware Description 1.1. Specifications Classification Parameter Specification Wireless Wireless Standard 802.11b/g/n Parameters Networking Mode AP/STA Communication Mode 2.4G WiFi Antenna Connector Standard SMA female antenna interface,<br />characteristic impedance 50Ω Downstream Serial Standard RS485 Serial Port No. of Ports... - Page 6 C2000-A2-SMD4240-AC5 User Manual Classification Parameter Specification Digital Input DI Channels DI Connector Terminal block Input Type Dry/Wet contact DI Mode Logic level & pulse count Digital Filtering Time Interval 6 sample periods Counter Frequency 1kHz Logic Logic 0: Open or input voltage < 3.8V; Logic 1: Short to...
-
Page 7: Apprearance
C2000-A2-SMD4240-AC5 User Manual 1.2. Apprearance SinoCon Co., Ltd. www.sinoconsys.com 7 / 12... -
Page 8: Indicators
C2000-A2-SMD4240-AC5 User Manual 1.3. Indicators Classification Indicator Description Meaning Digital Input Digital input Steady on：Short to GND or input voltage more than indicators (dry/wet the threshold voltage contact) Off：Open or input voltage less than the threshold voltage Digital Digital input Steady on：On... -
Page 9: Port Description
C2000-A2-SMD4240-AC5 User Manual 1.4. Port Description Recommended Classification Port Description wiring Analog Input +、- Positive analog input, Negative analog input RVV 2*0.5 Digital Input Digital input RVV 2*0.5 DI.COM Dry and Wet contact mixed input common, not in common RVV 2*0.5... -
Page 10: Product Dimensions
C2000-A2-SMD4240-AC5 User Manual 1.5. Product Dimensions unit: mm（inch） 1.6. Installation Method SinoCon Co., Ltd. www.sinoconsys.com 10 / 12... - Page 11 C2000-A2-SMD4240-AC5 User Manual 2. Package Contents Contents Device (contain mounting kit) * 1 Terminal block * 1 set Installation guide card * 1 SinoCon Co., Ltd. www.sinoconsys.com 11 / 12...
-
Page 12: Warranty Policy
C2000-A2-SMD4240-AC5 User Manual 3. Warranty Policy In the normal use of the products you purchased, free warranty service will be provided from the date of purchase whenever the quality problems caused by raw materials or production process are concerned. However, due to the user's failure to install, disassemble or improperly use the product according to the requirements of this product manual, the company provides maintenance services, but charges appropriate maintenance fees.
