Installation instructions
Clamp-on surface variation
Included in package:
Unit
Step 1
Slide unit mount onto
edge of surface.
Step 2
Tighten thumb screws
on underside of the
surface.
Step 3
Plug in the unit.
2X Thumb Screws
Under surface mount variation
Included in package:
Unit
3X #10 Wood Screw
Tools needed:
• Philips head screwdriver
• Pilot drill bit (optional)
Step 1
With two of the provided screws, attach the
mounting bracket to the underside of the
surface in the location desired, utilizing the
two slotted holes. Do not fully tighten screws.
Step 2
Adjust the mounting bracket
into its final desired position
and drive in the third screw
through the remaining hole.
Tighten all screws.
Mounting Bracket
Plastic Thumb Nut
