- Page 1 UNIVERSAL IO-LINK HANDHELD MASTER IOL-PORTABLE 600008-0000EN · Rev 1 · 2020/07 USER MANUAL...
-
Page 2: Table Of Contents
4.8 LED function .................................. 7 4.9 Environmental ................................8 4.10 Approval and markings ..............................8 4.11 Accessories ................................. 8 5 UNBOXING 5.1 Switch ON your IOL-Portable ............................9 5.2 Screen gestures ................................9 5.3 General info ..................................9 6 SOFTWARE 6.1 Funktion ..................................10 6.2 Example of Connected Ultrasonic sensor ........................16... -
Page 3: Introduction
IOL-PORTABLE 1 INTRODUCTION This manual is a reference guide for IOL-Portable. It describes how to set up and use the product for its intended use. 1.1 VALIDITY OF DOCUMENTATION This manual is valid only for IOL-Portable and until any new documentation is published. It describes the function and operation of the product for its intended use. -
Page 4: Structure
IOL-PORTABLE 2 STRUCTURE LEDs LEDs indication state indication main battery Status Main battery Power Micro SD card port Micro USB port M8 3-wire M8 4-wire 600008-0000EN · Rev 1 · 2020/07... -
Page 5: Description
IOL-PORTABLE 3 DESCRIPTION The IOL-Portable is the Industry 4.0 portable, self-powered and user friendly configurator for IO-Link sensors that accesses your sensor data and manages its parameters. There is no need for a PC and dedicated software. Through a 5.5 in HD touchscreen display and dedicated Apps you can now: ƒ... -
Page 6: Features
+ (plus) Reserved for future use - (minus) Power button Hold for 3 sec to power on / off your IOL-Portable Short press to switch on / off the screen 4.6 ELECTRICAL RATINGS Standard charger via micro USB 5V/1A or PC USB port 4.7 BATTERY INFO... -
Page 7: Led Function
IOL-PORTABLE 4.8 LED FUNCTION Battery LEDs (green) Flashing When the device is connected to power, it flashes from the first LED on the left to the other LEDs on the right and indicates that the main battery is being charged. -
Page 8: Environmental
IOL-PORTABLE 4.9 ENVIRONMENTAL Operational environment To be used in indoor applications only IP-rating IP30 Ambient air temperature Charging: 10 to + 35°C Operating: 0 to + 40°C Storage temperature 0 to + 50°C Ambient humidity range Operating: 0 to + 90% non condensing... -
Page 9: Unboxing
IOL-PORTABLE 5 UNBOXING 5.1 SWITCH ON YOUR IOL-PORTABLE To switch on your IOL-Portable, press and hold the power key button for 3 seconds. 5.2 SCREEN GESTURES Touch: touch an item once. For example, touch to select an option Swipe: swipe your finger on the screen vertically to scroll through a list or horizontally to change a value 5.3 GENERAL INFO... -
Page 10: Software
IOL-PORTABLE 6 SOFTWARE 6.1 FUNCTION Home screen Settings Battery info Wi-Fi switch Time and date Store Configuration Icon 600008-0000EN · Rev 1 · 2020/07... - Page 11 If requested, insert the password Step 2: store > update Select the Store Keep your IOL-Portable up to date and accept available software updates to get new and enhanced features 600008-0000EN · Rev 1 · 2020/07...
- Page 12 IOL-PORTABLE Step 3: start configure app with sensor Connect your sensor Select the icon to start Loading IODD Icon Details IO-Link: Close Configure App and go Parameterization back to home screen Identification Observation Diagnosis Measurement value (mm) All process data...
- Page 13 IOL-PORTABLE Error messages Back to home screen Sensor unrecognized Sensor not connected IODD file not found in the device Press the icon to download it automatically from internet 600008-0000EN · Rev 1 · 2020/07...
- Page 14 IOL-PORTABLE Create a user: parameterization > settings > users John Doe Select icon Select Settings Select tab Users Select to add an user Select the new users role via the drop down menu Rollen Functions Observer Maintenance Specialist Identification Check...
- Page 15 IOL-PORTABLE Project options: parameterization > save or load Delete, rename or load a project List of projects Save or load a project Select the project to open Touch to open a saved project and touch IODD options: parameterization > settings > IODD...
-
Page 16: Example Of Connected Ultrasonic Sensor
IOL-PORTABLE 6.2 EXAMPLE OF CONNECTED ULTRASONIC SENSOR Process data Example: activated switching output Measurement value (mm) All process data Example: activated switching output Selct Configuration of switching output for a ultrasonic sensor Select icon Select parameter details Scroll verticallly to find the parameter 600008-0000EN ·... - Page 17 IOL-PORTABLE Parameter ultrasonic sensor Reset sensor to factory settings Configure switchpoint mode (Window mode, Reflex mode, Single point mode) Configure switchpoint logic NO/NC Configure switchpoint 1 (mm) Command icons Touch this to activate the live mode When the live mode is turned on, the changes are written automatically...
- Page 18 IOL-PORTABLE Add a parameter to the favourite list Scroll vertically to find the Favourites list Swipe left desired parameter, for example Press to add it to the NO/NC configuration (LO Logic) favourites list Delete a favourite parameter Example of SO active...
- Page 19 IOL-PORTABLE SOLUTIONS. SOLUTIONS. CLEVER. PRACTICAL. CLEVER. PRACTICAL. di-soric GmbH & Co. KG | Steinbeisstrasse 6 | 73660 Urbach | Germany Phone +49 71 81 98 79-0 | Fax +49 71 81 98 79-179 | info @ di-soric.com www.di-soric.com...
