CROMMELINS PORTABLE CONCRETE
VIBRATOR 45mm
OPERATION & INSTRUCTION MANUAL
Thank you for your selection of a Crommelins Portable Concrete
Vibrator. This Operation Manual explains its use, installation, checking
and maintenance. We highly recommend that you retain this manual
for reference regarding its proper handling.
Sales: 1300 650 659
Head Office: (08) 9350 5588
Customer Service: 1300 554 524
www.crommelins.com.au
email@crommelins.com.au
Advertisement
Table of Contents
Related Manuals for Crommelins PV45HRN
Summary of Contents for Crommelins PV45HRN
- Page 1 CROMMELINS PORTABLE CONCRETE VIBRATOR 45mm OPERATION & INSTRUCTION MANUAL Thank you for your selection of a Crommelins Portable Concrete Vibrator. This Operation Manual explains its use, installation, checking and maintenance. We highly recommend that you retain this manual for reference regarding its proper handling.
-
Page 2: Table Of Contents
Thank you very much for purchasing a Crommelins Portable Concrete Vibrator which can be used in construction, councils, hire industries and general use. This manual covers its operation and maintenance. Please take a moment to familiarise yourself with the proper operation and maintenance procedures in order to maximise the safe and efficient use of this product. -
Page 3: Safety
SAFETY This manual contains important information on how to use the Crommelins Portable Concrete Vibrator 45mm, model number PV45HRN, correctly and safely. Please read through this manual before you attempt to operate the machine. This portable concrete vibrator is designed to give safe and dependable service if operated according to the instructions. -
Page 4: Applications, Functions And Controls, Hazards
APPLICATIONS • Piers, pre-cast beams, foundations, stairs, walls, floors, slabs, panels, floor stumps, footings and fence posts. FUNCTIONS & CONTROLS • The machine is controlled by an ON/OFF switch and a throttle lever. • The engine is 4-stroke, only use unleaded petrol. MECHANICAL HAZARDS •... -
Page 5: Assembly Guide
ASSEMBLY GUIDE • To fit the two parts of the portable vibrator together, lay both parts on a flat surface. • Remove centre cap-screw from aluminium connector and loosen the other two screws • Locate drive tube into the connector and push together. If they don’t push fully together rotate one part to locate square drive on the end of the shaft to the square hole in the alloy connector. -
Page 6: Operation And Specification Chart
• Do not use as an external vibrator or leave running for extended periods out of the concrete as the unit needs to be immersed in the wet concrete to remain cool. ENGINE The engine user manual is enclosed. PORTABLE CONCRETE VIBRATORS SPECIFICATION CHART MODEL PV45HRN Shaft Size 45mm Frequency 9000vpm Engine Make... -
Page 7: Maintenance, Storage, Psa And Warranty
You can also visit our website at www.crommelins.com.au to find your local service agent who will be able to assist with all warranty claims. -
Page 8: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE PROBLEM CAUSE SOLUTION 1. Turn switch to ‘ON’ Engine won’t start, or 1. Engine switch set to ‘OFF’ stops suddenly 2. Refuel 2. No fuel 3. Clean the spark plug or 3. Spark plug is replace it with a new one carbonized 1. -
Page 9: Parts Diagram
PARTS DIAGRAM 25-1 21-1b 21-1a... -
Page 10: Parts List
PARTS LIST Item No. Part No. Part Description Rem. 7365-001 End cap 4908-15036 O-ring 1.5x36 4900-00015 Circlip #A15 4000-03202 Bearing 3202 7365-003 Rotor Shaft 7365-002 Barrel 7365-004 Rotor connector 4701-16287 Oil seal TC 16x28x7 7365-005 Oil seal holder 4908-15019 O-ring 1.5x19 7365-006 Front end casing 4921-00131... -
Page 11: Notes
NOTES... - Page 12 CROMMELINS PORTABLE CONCRETE VIBRATOR 45mm OPERATION & INSTRUCTION MANUAL Sales: 1300 650 659 Customer Service: 1300 554 524 Head Office: (08) 9350 5588 email@crommelins.com.au www.crommelins.com.au...
