Summary of Contents for Lippert Components Manual Step with SolidStance
- Page 1 Manual Step with SolidStance OEM INSTALLATION MANUAL ™...
- Page 2 TABLE OF CONTENTS Introduction Safety Resources Required Installation Operation Extending Position Stowed Position Introduction The SolidStance™ Step Stabilizer gives additional support to recreational vehicle steps. The SolidStance Step Stabilizer has two adjustable support legs with footpads to accommodate the height from the bottom step to the ground, giving solid and secure support to keep the steps from rocking when in use.
- Page 3 Always wear eye protection when performing installation procedures. Other safety equipment to consider would be hearing protection, gloves and possibly a full face shield, depending on the nature of the task. Moving parts can pinch, crush or cut. Keep clear and use caution. Resources Required •...
- Page 4 Operation NOTE: The operation of the manual step with SolidStance should NOT be left in the extended position or used during the manufacture and completion of the trailer. After verifying the manual step with SolidStance operates in the extended and retracted position, leave the manual step with SolidStance in the fully retracted position.
- Page 5 If the footpads do not reach the ground, pull the spring loaded pin (Fig. 6B) out on the drop leg to extend the inner leg (Fig. 6C) down so that the footpad (Fig. 6D) touches down to the ground. Align the closest pin hole in the inner leg (Fig. 6C) to the spring loaded pin (Fig. 6B). Allow the spring loaded pin to insert into the inner leg to lock it in place.
- Page 6 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
