- Page 1 HyDefinition ® RHF Console Setup Configuration For Systems with Short Torch Leads (20'/6m or less) Field Service Bulletin 803490 - Revision 0...
- Page 2 Hanover, New Hampshire 03755-5010 Tel.: (603) 643-3441 Fax: (603) 643-5352 http://www.hypertherm.com email:info@hypertherm.com © Copyright 1998 Hypertherm, Inc. All Rights Reserved Hypertherm, HyDefinition, HT and LongLife are trademarks of Hypertherm, Inc. and may be registered in the United States and/or other countries...
- Page 3 HyDefinition RHF Console Setup Configuration HyDefinition RHF Console Setup Configuration In this bulletin: Introduction ..................2 Purpose ................... 2 General .................... 2 Applicability ..................2 Identifying Effected RHF Consoles ..........3 RHF Console Modification ..............4 Power Supply Modification ..............6...
- Page 4 (20 feet or less). General HyDefinition systems that use short torch leads and have an RHF console containing a three- capacitor spark gap assembly may experience decreased starting reliability. This bulletin includes instructions for modifying effected power supplies and RHF consoles to improve the reliability of the starting cycle.
- Page 5 HyDefinition RHF Console Setup Configuration Identifying Effected RHF Consoles WARNING ELECTRIC SHOCK CAN KILL Turn off the power, unplug the power cord and wait 5 minutes before opening RHF con- sole. If the power supply is directly connected to a line disconnect switch, place switch in the OFF position.
- Page 6 HyDefinition RHF Console Setup Configuration RHF CONSOLE MODIFICATION WARNING ELECTRIC SHOCK CAN KILL Turn off the power, unplug the power cord and wait 5 minutes before opening RHF con- sole. If the power supply is directly connected to a line disconnect switch, place switch in the OFF position.
- Page 7 HyDefinition RHF Console Setup Configuration Install the nut to secure the capacitor assembly to the spark gap. Make sure washer is installed as shown. Install the screw and lock washer to secure wire to the capacitor. Washer Close and secure the RHF console.
- Page 8 HyDefinition RHF Console Setup Configuration POWER SUPPLY MODIFICATION WARNING ELECTRIC SHOCK CAN KILL Turn off the power, unplug the power cord and wait 5 minutes before removing any power supply cover. If the power supply is directly connected to a line disconnect switch, place switch in the OFF position.
- Page 9 HyDefinition RHF Console Setup Configuration Remove wire 66 from relay CR4. Relay CR4. Attach wire 66 along with wire 67 to the lower terminal of relay CR4. Replace the right side pane to the power supply and secure in place.
- Page 10 HyDefinition RHF Console Setup Configuration Blank FIELD SERVICE BULLETIN...
