Superior Engineering SUP-200MOD Installation Instructions

Page 1 of 3
Superior Engineering
Installation Instructions
Part Description: TOYOTA 200# STEALTH SLIDERS
Part Number: SUP-200MOD
NOTE: Read and understand these Installation Instructions before beginning the installation
process. Retain these installation Instructions for future reference.
It is recommended this item is installed by a Qualified Person.
Kit Includes:
QTY DESCRIPTION
1 DRIVER SIDE STEALTH
PASSENGER SIDE STEALTH
1
2 M12 X 1.75 X 110mm BOLT
1 M12 X 1.75 X 130mm BOLT
1 M12 X 1.75 X 120mm BOLT
2 M12 X 1.75 X 160mm BOLT
9 M12 FLAT WASHER
6 M12 SPRIG WASHER
3 M12 X 1.75 NYLOCK NUTS
CAUTION
Please ensure all bolts are tightened to
correct torque setting with Loctite.
NOTE: working on one side at a time can make
installation easier.
Size Torque (Nm)
M12 85
1. Start with the vehicles front and rear wheels
chocked and the vehicle in gear or park with the
hand brake on.
2. Remove the factory side steps as per vehicle
service manual. (If fitted). As well as the two
guards seen in figure 1 and 2.
NOTE
There are different length bolts. The 110mm
bolts are for the rear mounts. The 120mm
are for the driver side middle mounts. The
130mm bolt is for the passenger side middle
mount. The 160mm bolts are for the front
mounts.
© Superior Engineering 499 Uhlmann Rd Burpengary QLD 4505 Australia
Torque (ft-lb)
64
499 Uhlmann Rd
Burpengary QLD 4505
3. Hold the Superior Engineering Slider in place and
loosely fit all M12 bolts using spring and flat
washers through the slider's mounting plate
holes. Using M12 nuts where needed.
NOTE: Ensure the all mount are underneath any
fuel, AC or brake lines.
4. Make sure the slider is in its correct position with
the front and rear of the slider profile having an
even gap from the body of the vehicle.
5. Tighten all bolts to correct torque settings.
6. Re attach factory guard that were removed earlier
WARNING
Take care in not bending or breaking any of
the fuel, A/C or brake lines. They may need
to be moved slightly to make the sliders fit.
Make sure there is clearance between the
lines and the mount.
7. Check over vehicle and make sure the slider do
not fowl on any components and has clearance in-
between the body and the slider.
Australia
