Kindred Steel Queen Installation Manual

Undermount sinks

Advertisement

Available languages

Available languages

Quick Links

Installation of Steel Queen
SURELL BY FORMICA
CORIAN BY DUPONT
For all other polymer based materials, or natural stone countertops,
• Steel Queen undermount sinks have a highly polished sink rim. To highlight this unique design
feature, our installation system reveals up to 3/8" of the sink rim.
• Kindred accepts no liability for damage to the solid surface countertop, or sink fixture, during
installation.
• Inspect the sink fixture for any shipping damage, prior to installation. Do not install a damaged unit.
• Aesthetics are essential to presentation of the installed sink unit. Take the necessary care to ensure
that the exposed silicone joint is kept to a minimum, the sink is properly aligned to the cut-out, and
excess silicone is cleaned from the sink.
HARDWARE SUPPLIED BY KINDRED
Kindred has supplied within the sink carton: 3 1/2" strainers (waste assembly), a die-cut corrugated template,
homeowner's manual, and a hardware kit. The intention of the hardware kit is to clamp the sink rim to the
underside of the countertop, and backup the silicone seal.
This kit includes the following:
Machine screws
Brackets
Thumbscrews
Tee nuts
1" diameter PVC discs
Loctite Prism 401
THE FABRICATOR WILL REQUIRE:
• An assortment of clamps
• A solvent such as methyl hydrate or denatured alcohol
• Silicone sealant
• 1/2" plywood buildup
• 180 grit sandpaper
30149
Undermount Sinks
METHOD ONE
NOTE: These instructions apply only to:
refer to Installation Method Two following.
Kindred Customer Service: 1-866-687-7465
AVONITE (CLASS 1)
FOUNTAINHEAD BY NEVAMAR
Use for Method One
• Jig saw
• 1 1/2" router guide bushing
• 1/2" straight cutter bit
www.kindred-sinkware.com
Use for Method Two
0605

Advertisement

loading
Need help?

Need help?

Do you have a question about the Steel Queen and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kindred Steel Queen

  • Page 1 For all other polymer based materials, or natural stone countertops, refer to Installation Method Two following. • Steel Queen undermount sinks have a highly polished sink rim. To highlight this unique design feature, our installation system reveals up to 3/8” of the sink rim.
  • Page 2 FABRICATOR TEMPLATE PREPARATION • The die-cut corrugated template supplied by Kindred follows the exact size and shape of the finished countertop cut-out. • The cut-out will reveal approximately 3/8" of the mirror finished sink rim. • We recommend that the corrugated plug template be used to create a female template from 1/2" plywood.
  • Page 3 TEMPLATE PREPARATION (FIGURE 1) 1 / 2 " K I N D R E D C O R R U G A T E D P L U G 1 / 2 " P L Y W O O D C U T - O U T S C R A P T E M P L A T E 1 1 / 2 "...
  • Page 4 • Kindred Undermount sinks have a highly polished sink rim. To highlight this unique design feature, our installation system reveals up to 3/8” of the sink rim. • Kindred accepts no liability for damage to the natural stone or solid surface countertop, or sink fixture, during installation.
  • Page 5 FABRICATOR TEMPLATE PREPARATION • The die-cut corrugated template supplied by Kindred follows the exact size and shape of the finished countertop cut-out. • The cut-out will reveal approximately 3/8" of the mirror finished sink rim. • We recommend that the corrugated plug template be used to create a female template from 1/2" plywood.
  • Page 6 TEMPLATE PREPARATION (FIGURE 1) 1 / 2 " K I N D R E D C O R R U G A T E D P L U G 1 / 2 " P L Y W O O D C U T - O U T S C R A P T E M P L A T E 1 1 / 2 "...
  • Page 7 PRÉPARATION DU GABARIT (DESSIN 1) 1 2 , 7 m m ( 1 / 2 p o ) G A B A R I T M A L E E N C A R T O N O N D U L E K I N D R E D G A B A R I T E N P A R T I E D E C O U P E E A , C O N T R E P L A Q U E D E...
  • Page 8 PRÉPARATION DU GABARIT D’INSTALLATION PAR LE FABRICANT DU COMPTOIR • Le gabarit en carton ondulé découpé à l’emporte-pièce, fourni par Kindred, a été usiné aux dimensions et à la forme exactes de la découpure finie du comptoir. • La découpure laisse apparaître le rebord poli miroir de l’évier sur environ 9,5 mm (3/8 po) de largeur.
  • Page 9 9,5 mm (3/8 po). • Kindred n’accepte aucune responsabilité en cas de dommages à la surface du comptoir ou à l’évier, lors de l’installation. • Vérifier si l’évier n’a pas été endommagé au cours du transport, avant de l’installer. Ne pas installer d’évier endommagé.
  • Page 10 PRÉPARATION DU GABARIT (DESSIN 1) 1 2 , 7 m m ( 1 / 2 p o ) G A B A R I T M A L E E N C A R T O N O N D U L E K I N D R E D G A B A R I T E N P A R T I E D E C O U P E E A , C O N T R E P L A Q U E D E...
  • Page 11 PRÉPARATION DU GABARIT D’INSTALLATION PAR LE FABRICANT DU COMPTOIR • Le gabarit en carton ondulé découpé à l’emporte-pièce, fourni par Kindred, a été usiné aux dimensions et à la forme exactes de la découpure finie du comptoir. • La découpure laisse apparaître le rebord poli miroir de l’évier sur environ 9,5 mm (3/8 po) de largeur.
  • Page 12 9,5 mm (3/8 po). • Kindred n’accepte aucune responsabilité en cas de dommages à la surface du comptoir ou à l’évier, lors de l’installation. • Vérifier si l’évier n’a pas été endommagé au cours du transport, avant de l’installer. Ne pas installer d’évier endommagé.
