Summary of Contents for Spectrum Technologies IPM Scope CAM
- Page 1 IPM Scope CAM ITEM # 2860CAM Operation Manual (ES) Equipements Scientifiques SA - Département Bio-tests & Industries - 127 rue de Buzenval BP 26 - 92380 Garches Tél. 01 47 95 99 90 - Fax. 01 47 01 16 22 - e-mail: bio@es-france.com - Site Web: www.es-france.com...
-
Page 2: Table Of Contents
• Please operate moving parts carefully to avoid damage. Thank you for purchasing the IPM Scope CAM. This manual will familiarize you with the features and operation of your new IPM Scope CAM. Please read this manual thoroughly before using your instrument. -
Page 3: Overview
Overview Features • 3X to 300X magnification • 2 inch LCD display for easy viewing, capturing • SD Card allows the stored files editing on PC. • 180 degree rotating Lens tube captures images at any angle. • 6 White-light LEDs and adjustable illumination for clear images. •... -
Page 4: Keys And Indicators
Keys and Indicators (ES) Equipements Scientifiques SA - Département Bio-tests & Industries - 127 rue de Buzenval BP 26 - 92380 Garches Tél. 01 47 95 99 90 - Fax. 01 47 01 16 22 - e-mail: bio@es-france.com - Site Web: www.es-france.com... - Page 5 Indicator Light Blue: Device powered on. Red: Device charging. Turns off when fully charged. (ES) Equipements Scientifiques SA - Département Bio-tests & Industries - 127 rue de Buzenval BP 26 - 92380 Garches Tél. 01 47 95 99 90 - Fax. 01 47 01 16 22 - e-mail: bio@es-france.com - Site Web: www.es-france.com...
-
Page 6: Inserting The Battery
The initial battery charge takes approximately 8 hours. USB Connection Plug the USB cable into a PC and the IPM Scope CAM and click the power key. Two functions will appear on the LCD. “Data Transfer” transfers data from the microscope to the PC. -
Page 7: Device Setup
Device Setup Click “MENU” key to enter MENU mode. Then click “Right” key to enter Device Setup. Select the setup parameters: Format, Beep, Language, Auto Off, System Reset, Light Frequency, Date & Time, and TV. (ES) Equipements Scientifiques SA - Département Bio-tests & Industries - 127 rue de Buzenval BP 26 - 92380 Garches Tél. -
Page 8: Getting The Best Image
4. Adjust the focus know to get a clear image. 5. Hold the IPM Scope CAM in your hand, adjust the distance, or set it on a sturdy object to obtain the best image. -
Page 9: Operation
Operation Shooting Mode: Viewfinder Information 1. In shooting mode, click “MENU” to display menu lists. 2. Setting “Capture” parameters: Size, Color, Quick View, Date Stamp, Grid. (ES) Equipements Scientifiques SA - Département Bio-tests & Industries - 127 rue de Buzenval BP 26 - 92380 Garches Tél. - Page 10 Recording Mode: Viewfinder Information 1. In recording mode, click “MENU” to display menu lists. 2. Setting “Video Output” format: Size. Playback Mode: Viewfinder Information 1. In shooting or recording mode, click “PLAYBACK” to enter playback mode. 1. In playback mode, click “MENU” to display menu lists. 2.
- Page 11 File Storage There are two locations to save capture and recording files: 1. SD card 2. Built-in flash memory. The files in flash memory won’t display when the SD card is being used. The files can be copied to the SD card. Use Playback mode “Copy to Card”...
-
Page 12: Warranty
Warranty The IPM Scope CAM is warranted to be free from defects in materials and workmanship for a period of 1 year from the date of original purchase. During the warranty period, Spectrum will, at its option, either repair or replace products that prove to be defective. This warranty is void if the product has been damaged by customer error or negligence, or if there has been an unauthorized modification.
