VARIABLE SPEED
STOCK No.39042
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE
This manual has been compiled by Draper Tools and is an integrated part of the power tool equipment, which
should be kept with the machine.
This manual describes the purpose for which this tool has been designed and contains all the necessary
information to ensure its correct and safe use.We recommend that this manual is read before any operation of
the machine, before performing any kind of adjustment to the machine, and prior to any maintenance tasks. By
following all the general safety instructions contained in this manual, it will ensure both machine and operator
safety, together with longer life of the tool itself.
All photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
machine.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the Draper Tool
policy of continuous improvement determines the right to make modifications without prior warning.
WOOD LATHES
63938
• INSTRUCTIONS •
SAFE AND EFFECTIVE USE OF THIS TOOL.
GENERAL INFORMATION
PART No.WTL90
WTL95
02/2001
Advertisement
Table of Contents
Related Manuals for Draper WTL90
Summary of Contents for Draper WTL90
- Page 1 02/2001 GENERAL INFORMATION This manual has been compiled by Draper Tools and is an integrated part of the power tool equipment, which should be kept with the machine. This manual describes the purpose for which this tool has been designed and contains all the necessary information to ensure its correct and safe use.We recommend that this manual is read before any operation of...
-
Page 2: Table Of Contents
Basic Wood Turning..................9-16 Optional Accessories ..................17 Troubleshooting .....................18 DECLARATION OF CONFORMITY Draper Tools Ltd. Hursley Road, Chandler’s Ford, Eastleigh, Hampshire. SO53 1YF. England. Declare under our sole responsibility that the product: Stock No:- 39042 & 63938. Part No:- WTL90 & WTL95. -
Page 3: Specification/Guarantee
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the 12 month period. -
Page 4: Power Supply
(i.e. red). Fuse covers are available from your Draper Tools stockist. If the fitted plug is not suitable, it should be cut off and destroyed. *The end of the cable should now be suitably prepared and the correct type of plug fitted. -
Page 5: General Safety Instructions
IMPORTANT Draper Tools Limited recommends that this machine should not be modified or used for any application other than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us in writing and we will advise you. -
Page 6: Getting To Know Your Wood Lathe
1. Always wear eye protection which complies to a recognized standard. 2. Wear a mask or respirator when dust is generated. 3. Keep hands clear of moving parts. 4. Only use Draper approved accessories and spares. 5. Keep turning chisels sharp. 6. Keep pulley cover guards in place when working. -
Page 7: Assembly
✪✌ with the four ✫✌ legs ✫✌. Bolt on the shelf (WTL95) or four ✬✌ supports (WTL90) ✬✌ and tighten all the fixings. Fig.2. Note: The Wood Lathe stand should always be fastened down securely to the floor using four suitable fixings (not supplied). -
Page 8: Operation And Use
ASSEMBLY Fitting Bed Extension (WTL90 only) ✴✌ Using the fixings supplied, bolt the extension ✴✌ to the headstock end of the bed. Fig.8. OPERATION & USE NO-VOLT ON/OFF SWITCH Fig.9. Note: The WTL95 is fitted with an additional emergency shut off cover. - Page 9 OPERATION & USE WTL 95 WTL90 ROTATING THE HEADSTOCK Fig.11A. Fig.11B. The headstock can be rotated 45, 90, 135 and 180°. Loosen handle ✷✌ and pull the release ✸✌ ✷✌ pin ✸✌.When pin ✸✌ is pulled out, the head ✷✌...
-
Page 10: Basic Woodturning
BASIC WOODTURNING The following pages of this manual explain Fig.16. and illustrate the correct use of the turning tools, the tool rest and other information to help you. If you are new to woodturning, we suggest that you practice using various woodturning chisels following the operations listed below. - Page 11 BASIC WOODTURNING USING WOODWORKING CHISELS: Professional woodturning chisels have handles approximately 250mm long. This provides the operator with good grip and leverage. A sharp chisel will be much easier to work with and will give the job a cleaner finish. Fig. 20 shows the six most commonly used types of turning chisel.
- Page 12 BASIC WOODTURNING KNOWING WHEN TO CUT AND WHEN TO Fig.23. SCRAPE There are two different approaches to the work when turning. The first is towards a circumference of the workpiece (eg. When turning down the outer surface of a cylinder or the inner wall of a hollow round box).
- Page 13 BASIC WOODTURNING POSITIONING THE TOOL REST FOR Fig.24. CIRCUMFERENCE TURNING When turning, the object is to pierce the outer surface of the wood to a desired depth, then to hold the chisel steady with the bevel edge parallel to the work circumference, so that the chisel will peel off a shaving at this desired depth.
- Page 14 BASIC WOODTURNING If the tool rest is positioned too far away from Fig.28. the workpiece as shown in Fig.28, the chisel, when correctly held will again be too high on HANDLE KICKED the workpiece.You will also find that you have less leverage on your side of the tool rest and it will be very difficult to hold the chisel.
- Page 15 CUTTING sufficient for home workshop turning, but EDGE ADVANCED other sizes are available (refer to Draper Catalogue). A gouge chisel is normally used for rough circumference turning or turning raw stock down to a cylinder of workable size. It is best used for rapid removal of the...
- Page 16 Fig.38. Two skew chisels 12, 25mm are all that are required for general use although other sizes are available (refer to Draper Catalogue). This chisel is used mostly for making finished cuts, to cut vees and beads and square shoulders. When correctly used, it will produce the best finish that can be obtained with a chisel.
- Page 17 12mm spear point, 12mm round nose and 26mm flat nose. Each of these chisels may be purchased in various sizes, (refer to the Draper Catalogue) for special jobs. All of these are very useful for diameter scraping (see Figs.45, 46, 47) operations and for circumference scraping when cutting methods cannot be employed.
-
Page 18: Optional Accessories
Part No.AWL8 Stock No.29429 Combination Chuck Part No.AWL40 Stock No.37168 Face Shield Part No.FS8 Stock No.33831 HSS Wood Turning Chisels Part No.AWL44 Stock No.58697 For a comprehensive range of wood lathe accessories refer to the Draper Catalogue - 17 -... -
Page 19: Troubleshooting
1. Tighten locking handle tight Wood burns at tailstock 1. Live centre too tight or 1. Back of tailstock barrel and lubricate live centre. not lubricated See Basic Lathe Operation “Spindle Turning” DRAPER HELPLINE (023) 8049 4344 - 18 -... - Page 20 ©Published by Draper Tools Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
