Summary of Contents for Sovis CA8 Series
- Page 1 Public Address 8 Channel Power Amplifier MODEL: CA8120 CA8240 Warning:Before attempting to connect,operate or adjust this Amplifier, please read these instructions completely and carefully and save this Manual...
- Page 3 Table of Contents Table of Contents Introductions ----------------------------------------- 2 Features -----------------------------------------------2 Front panel controls ------------------------------- 3 Rear panel controls ---------------------------------4 Block diagram ----------------------------------------5 Specifications ----------------------------------------6...
- Page 4 Introductions/Features Introductions Welcome Congratulation and thank you for the purchasing CA8120 and CA8240 8 channel constant voltage power amplifier. Unpacking and Installation Although it is neither complicated to install nor difficult to operate unit, a few minutes of your time is required to read this manual for a properly wired installation and becoming familiar with its many features and how to use them.
- Page 5 Front Panel Controls Front Panel Controls FRONT PANEL 1.OUTPUT LEVEL METER These indicators show current output level. 2.CLIP INDICATORS These indicators warn against overload shortly on the each output channels. We would like to recommend for users to adjust VOLUME control when CLIP indicators are flickering to make best performance.
- Page 6 Front Panel Controls Rear Panel Controls 1.AC POWER INPUT CONNECTOR A correct capacity of fuse and power cable should be applied. Please make sure the value of fuse before replacing. 2.AMPLIFIER OUTPUTS These amplifier output blocks provide 100V constant voltage output for commercial and industrial use. 3.VOLUME CONTROLS These controls allow to adjust output level.
- Page 7 Block Diagram Block Diagram...
- Page 8 Specifications Specifications Model Name CA8120 CA8240 Rated Output Power 120W X 8CH 240W X 8CH Output / Impedance 100V(83Ω)/ 70V(42Ω) 100V(42Ω)/ 70V(21Ω) Input 0dB/20KΩ Balanced Input sensitivity /Impedance 0dB/20KΩ Balanced link Frequency Response 50Hz - 15kHz T.H.D < 0.1% Crosstalk >70 dB S/N Ratio >90 dB...
