Summary of Contents for SYNAPTICON OBLAC Drives Box
- Page 1 OBLAC Drives Box Documentation v 3.4.3 | Build: 2020-08-04 © 2020 Synapticon GmbH...
-
Page 2: Table Of Contents
1.3 Powering the box off and resetting 1.4 Open OBLAC Drives 1.5 Using OBLAC Drives Box with WiFi 1.6 Sharing a connection with your Host-PC 1.7 Update OBLAC Drives © 2020 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 3.4.3 | Build: 2020-08-04... -
Page 3: Oblac Drives Box
OBLAC Drives virtual machine installation guide installation guide OBLAC Drives Box is a physical machine that comes preinstalled with Linux OS and runs OBLAC Drives and the related services. It supports access over WiFi or local area network. 1.1 Connectors... -
Page 4: Installation
1. Plug in the power connector; the box will automatically boot. 2. Connect the box to your local area network using the upper LAN port. This will allow you to access OBLAC Drives over the local area network rather than having to connect to OBLAC Drives Box over WiFi. - Page 5 The HDMI port is without function. You require a dedicated host PC to control OBLAC Box. For tuning, you may connect several servo drives via EtherCAT and tune one by one. © 2020 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 3.4.3 | Build: 2020-08-04...
-
Page 6: Powering The Box Off And Resetting
If this is not possible you can still access OBLAC Drives via WiFi by entering the IP address given on the sticker. the sticker. Please check in you browser that the Drive is connected: © 2020 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 3.4.3 | Build: 2020-08-04... -
Page 7: Using Oblac Drives Box With Wifi
Select two network adapters “WiFi” and “Ethernet” by selecting each while holding Ctrl Right click and select “Bridge Connection” When you are finished working with OBLAC Drives Box you can simply delete the bridged connection © 2020 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 3.4.3 | Build: 2020-08-04... - Page 8 Connection editor with the terminal: nm-connection-editor Double-click on your Ethernet connection to edit it Enter the IPv4-Settings Select the method “Shared to other computers” © 2020 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 3.4.3 | Build: 2020-08-04...
-
Page 9: Update Oblac Drives
Drives Update Service. It is possible to use OBLAC Drives Box offline and to install and run the previous versions of OBLAC Drives. Newer versions of OBLAC Drives that get installed will be cached on the box, but they will have to be downloaded from the Internet.
