SECURITY HUB STARTER KIT Quick Start Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

STARTER KIT
Quick Start Guide
A

Connecting Controller

1.
Take the devices out of the box and check the package contents according to the data
.
sheet
2.
Open the controller cover
3.
Write down controller's serial number (a set of numbers placed under the bar code
.
on the PCB)
4.
Insert one or two SIM
cards
7.
Connect the
controller to the
Internet using a patch
*
cord
9.
Download and install «Security Hub»
application on your mobile device
*
The controller has 2 Internet communication channels: primary LAN and backup GSM
One communication channel is enough for operation
a
b
5.
Install and connect
backup battery to the
PCB
OPEN
5V
1A
.
Close
Open
6.
Close the
cover
8.
Plug the controller into
220V/AC outlet using
5V/DC power adaptor
(included)
.
Revision SH-komplekt_v2_1_instr
