SMARTROOMSOUND SBT Series Installation Manual

SMAR T
SMARTROOMSOUND SAYS
THANK YOU FOR CHOOSING!
Innovative design and advanced engineering built in to our SBT series of wireless Bluetooth ceiling
mount speakers. Designed for easy installation and high quality sound, within seconds each room is
ROOM
setup and ready. This manual describes the installation of SBT series speakers within conventional
stud and sheetrock (Joist and plasterboard) ceilings.

SAFETY WARNING

Before use please read completely and use in accordance with these safety instructions.
Before commencing any electrical work ensure the supply is switched OFF at the mains. Either
by switching off the consumer unit or by removing the appropriate fuse. This product should
be installed in accordance with the relevant sections of the building regulations code and in
accordance with the latest edition of IEE regulations (BS 7671).
SOUND
If the unit is to be used as a replacement for an existing product, remove the existing unit from its
location and disconnect the wiring. Connect the wires as shown in diagram. Ensure terminals are
properly tightened and ensure no bare wires are visible. When fitting the speaker into ceiling,
ensure no wires are trapped.
READ THE INSTRUCTIONS CAREFULLY BEFORE STARTING THE
Installation PROCESS AND KEEP THEM SAFE FOR FUTURE
REFERENCE.
• Failure to follow the instructions in this guide voids all warranties on your speakers.
•
Warning: Do not use the product in water.
• Warning: Do not install speaker directly above any heat sources such as radiators, or other
apparatus that produce heat.
•
Warning: To reduce the risk of fire or electric shock, do not expose this speaker to rain or
moisture (directly above bath or shower area) or in Bathroom Zone 0 or Zone 1.
• Protect the power cable from being damaged, do not over stretch cable.
•
Only use attachments / accessories specified by the manufacturer SMARTROOMSOUND.
• Turn off the power to the speaker when unused for long periods of time.
•
A Fire and Acoustic speaker hood must be used in accordance with UK building and IEE
Regulations with a fire rating of up to 60 minutes, is Parts B, L, C and E complaint.
• Do not open the back cover to the speaker as this protects the PCB as this will invalidate the
warranty and could cause electric shock.
•
Ensure speaker location is free from obstructions such as electrical conduit, HVAC ducts or
Water lines.
1

CONTENTS OF YOUR BOX

Please ensure you read the entire instruction manual carefully before you commence any work.
carefully unpack the speakers from the packaging. Please check to ensure all the parts shown
below are included.
If any parts of the speaker appear damaged, please contact your dealer/reseller immediately or
contact mail@smartroomsound.com for contact details.
MODEL SBT1 OR LBT1/IP P
LED COVER BLUETOOTH CEILING
SPEAKER
PREPARATION
Listed below is the hardware equipment needed to install the speaker, with the addition of
a ladder to ensure the installation is done safely. A cutting template is included in the box.
PENCIL STUD FINDER
PROTECTIVE EYEWEAR TAPE
SPEAKER CABLE WIRE CUTTERS
AIR MODELS
ALSO INCLUDE
SPEAKER GRILLE
POWER ADAPTOR PASSIVE CEILING SPEAKER
CUTTING GUIDE 5M SPEAKER CABLE
EQUIPMENT YOU WILL NEED
SCREWDRIVER CUTTING SAW
MEASURING TAPE DRILL
