Tournesol Siteworks Wilshire Screen Assembly Instructions

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Wilshire Screen Assembly Instructions

This instruction is a guide to installing the Wilshire Screen onto a Wilshire
planter.
Main Bracket(s)
(2 ½" x ~70" metal uprights, black)
VTGX Panel(s)
(48" x 48" or 72" x 48" wire panel)
Wilshire Rectangle
(48", 72", or 96" long FRP or GFRC planter)

Tools Required:

PARTS/HARDWARE LIST

2pcs. per
1 or 2 pcs. per
1pc. per
3/16" hex driver, 7/16" socket or box wrench or ratchet-drive socket, and
silicone sealant.
Tournesol Siteworks, LLC
Successful sites start here
2930 Faber Street, Union City, CA 94587
ph: 800.542.2282 f: 510.471.6243
www.tournesolsiteworks.com
48-00382-00, Rev. C
¼-20 SST Flathead Screw
¼" SST Lock Washer
¼-20 SST Hex Nut
¼-20 SST Hex Screw
¼ SST Flat Washer
TM
4pcs. per
4pcs. per
4pcs. per
4pcs. per
4pcs. per

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wilshire Screen and is the answer not in the manual?

Questions and answers

Summary of Contents for Tournesol Siteworks Wilshire Screen

  • Page 1 Wilshire Screen Assembly Instructions This instruction is a guide to installing the Wilshire Screen onto a Wilshire planter. PARTS/HARDWARE LIST Main Bracket(s) 2pcs. per ¼-20 SST Flathead Screw 4pcs. per (2 ½” x ~70” metal uprights, black) ¼” SST Lock Washer 4pcs.
  • Page 2 ¼” hex bolt, lock washer, and nut, attach the connection bracket to the joiner brackets on the panels. Hand tighten until all hardware has been installed and then tighten making certain Tournesol Siteworks, LLC Successful sites start here 2930 Faber Street, Union City, CA 94587 ph: 800.542.2282 f: 510.471.6243...
  • Page 3 Apply another bead of silicone to the side of the washer that will go against the planter. Tournesol Siteworks, LLC Successful sites start here 2930 Faber Street, Union City, CA 94587 ph: 800.542.2282 f: 510.471.6243...
  • Page 4 Note: A level could be placed on top of the panel and small adjustments can be made while final tightening of the hex screws is completed. Note: The illustration above shows how the Wilshire Screen (planters and VTG panels) can be used to create a screen or wall to section areas or provide privacy.
