ProBot Egg Painter Mini v1.1 Assembly Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ProBot:
Egg Painter Mini v1.1
assembly instruction
www.probot.xyz

Advertisement

loading
Need help?

Need help?

Do you have a question about the Egg Painter Mini v1.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ProBot Egg Painter Mini v1.1

  • Page 1 ProBot: Egg Painter Mini v1.1 assembly instruction www.probot.xyz...
  • Page 2 www.probot.xyz...
  • Page 3 Installation of electronics in the case bottom 0000001 Case Bottom Arduino UNO ULN2003 Stepper Motor Driver Board M2 4 Screw M3 Nut...
  • Page 4 Assembling the case top 0000002 0000003 0000004 Case Top Logo M5 Nut Holder M3 Nut M5 Nut...
  • Page 5 Assembling the right egg holder 0000005 0000006 0000007 0000008 0000009 15mm Rubber Gasket Axis R Holder 0000010 Axis R Axis R Lock 15x20 Spring 5 Bolt Holder Bottom Spring Holder M5x20 Bolt 608zz Bearing 5 Bolt Holder Top...
  • Page 6 Assembling the left egg holder 0000011 0000012 28byj-48-12v Stepper Motor Axis L Holder Axis L 24mm Rubber Gasket M3x12 Screw M3 Washer M3 Nut...
  • Page 7 Assembling the hand bottom 0000013 0000014 0000015 0000009 0000010 M5x20 Bolt 28byj-48-12v Stepper Motor M3x12 Screw 5 Bolt Holder Top Hand Holder M3 Washer Hand Holder Guide M3 Nut Hand Holder Guide Case 5 Bolt Holder Bottom...
  • Page 8 Assembling the hand 0000016 0000017 Hand H Hand V 2 x 18mm Iron Nail without a hat SG90 Micro Servo M3x16 Screw Hand Bottom (Step 5)
  • Page 9 Electronics connection (5v Stepper Motors) 28byj-48-5v Hand Stepper Motor SG90 Micro Servo +5 GND 13 IN1 IN2 IN3 IN4 ULN2003 Stepper Motor Driver 9 10 11 Arduino UNO IN1 IN2 IN3 IN4 ULN2003 Stepper Motor Driver 28byj-48-5v Egg Stepper Motor To PC...
  • Page 10 Electronics connection (12v Stepper Motors) 28byj-48-12v Hand Stepper Motor SG90 Micro Servo +5 GND 13 IN1 IN2 IN3 IN4 ULN2003 Stepper Motor Driver 9 10 11 Arduino UNO IN1 IN2 IN3 IN4 ULN2003 Stepper Motor Driver 28byj-48-12v Egg Stepper Motor To PC 12V DC...

  • Page 11: Final Assembly

    Final assembly 0000018 Case Bottom (Step 1) Case Right Case Top (Step 2) M3x12 Screw Left Egg Holder (Step 4) M3x16 Screw Hand (Step 6) Right Egg Holder (Step 3)
