- Page 1 RedDot LED User Manual RD & RDS Series Therapy Light REDDOTLED.COM REDDOTLED REDDOTLED...
- Page 3 RD Series Optional Mounting Configurations and Instructions RDS Series Optional Mounting Package Contents Configurations and Instructions 14/15 Install Your Therapy Light Setting up Your RD Series Light 17/18 Connecting Multiple Setting up Your RDS Series Light RD Series Light Units Warranty Connecting Multiple...
- Page 4 It is thought that certain Benefits Of RedDot LED Light Therapy Hair Growth Improves Elasticity of Collagen Fibres...
- Page 5 Why choose us? 1. RedDot led Light Therapy is safe for regular use. 1. RedDot led Light Therapy is safe for 2.Using varying LED wavelengths, this skincare regular use. technique purportedly helps treat acne, reduce 2.Using varying LED wavelengths, this inammation, and promote anti-aging effects.
- Page 7 RD Series Compare Specs RD60 RD500 RD1000 RD1500 LED Power 500W 1000W 1500W Wavelengths: 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm Dimensions 5.9" x 3.9" x 1.4"...
- Page 8 RD Series Specifications RD60 RD500 RD1000 RD1500 LED Power 500W 1000W 1500W Wavelengths 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm Amps @110v —...
- Page 10 RDS Series Compare Specs RDS500 RDS1000 RDS1500 LED Power 500W 1000W 1500W Wavelengths 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm Dimensions 10.4" x 8.7" x 2.3" 18.9" x 8.7" x 2.3" 27.2"...
- Page 11 RDS Series Specifications RDS500 RDS1000 RDS1500 LED Power 500W 1000W 1500W Wavelengths 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm Amps @110v 1.1A 2.1A 3.3A Amps @220v 0.4A 1.1A 1.3A Dimensions 10.4"...
- Page 12 RD & RDS Series Irradiance RD500 & RDS500 RD1000 & RDS1000 mw/cm2 mw/cm2 mw/cm2 mw/cm2 mw/cm2 mw/cm2 mw/cm2 mw/cm2 mw/cm2 mw/cm2 14"x12" 20"x16" 26"x22" 28"x26" 35"x33" 22"x14" 28"x18" 31"x22" 35"x26" 45"x33" Footprint Footprint Footprint Footprint Footprint Footprint Footprint Footprint Footprint Footprint 6"...
- Page 13 RD & RDS Series Irradiance RD1500 & RDS1500 mw/cm2 mw/cm2 mw/cm2 mw/cm2 mw/cm2 30"x14" 37"x18" 39"x22" 43"x26" 51"x33" Footprint Footprint Footprint Footprint Footprint 6" 12" 18" 24" 36" Light Meter Light Meter Light Meter Light Meter Light Meter...
- Page 14 RD Series Optional Mounting Configurations Mobile Stand Tabletop Stand Door Mount Instructions Distance: Apply from 6-12 inches. Session Time: Continue for 2-15 minutes,depending on distance. Frequency:Do this 2 times to 4 times a week until results are felt. Maintenance: Continue using several times a week.
- Page 15 RDS Series Optional Mounting Configurations Tabletop Stand Door Mount Instructions Distance: Apply from 6-12 inches. Session Time: Continue for 2-15 minutes,depending on distance. Frequency:Do this 2 times to 4 times a week until results are felt. Maintenance: Continue using several times a week.
- Page 16 Package Contents ① . ② . LED Therapy Light Patch Cable ③ . ④ . Cable Assembly & Snap Links Power Cable ⑤ . Eye Protection ⑥ . Hanging Hardware ⑦ . Door Hook...
- Page 17 Install Your Therapy Light STEP 1 Lay all of the included hardware, including your Reddot LED, on a padded surface. Next, screw in the threaded posts to the top of the device and hand-tighten with the included Allen wrench. Then, screw the cable supports to the threaded posts, as shown in PIC.1.
- Page 18 PIC.3. PIC.3 STEP 4 To raise your Reddot LED to your desired height, pull down on the loose cable while supporting the device with your opposite hand, as shown in PIC.4. Be sure to adequately support the device while raising and lowering it with the height-adjusting system .
- Page 19 Setting up Your RD Series Light Lead / Follow Buttton STEP 1 Plug the power cord in the female socket and press the red switch, it will illuminated. STEP 2 1. You can choose only red or only IR or both by...
- Page 20 Connecting Multiple RD Series Light Units STEP 1 To connect the lower Reddot LED, lift it into position below the lead device that is already in place. Line up the threaded posts with the holes in the end caps of the upper device. Then, slide the lower threaded posts into the holes, and slide forward to lock in place.
- Page 21 #1 Lead Mode 8888 8888 1500 MODE TIME Neutral Red Infrared Follow Mode STEP 2 1. Choose #1 light as leader. 2. Press #2 light’s follow button,the screen will show “SUB1”, #2 lights stay in “ Follow Mode”. 3. You only need to control the lead light, other lights #2 Follow Mode will follow the lead light’s instruction.
- Page 22 Setting up Your RDS Series Light Pairing Plug STEP Power Plug 1. Plug the power cord into the female socket of your therapy light. 2. Plug the other end of the power cord into a wall Red Switch socket. ON / OFF Infrared Switch 3.
- Page 23 Connecting Multiple RDS Series Light Units STEP 1. Line up the threaded posts with the holes in the end caps of the upper device. Then, slide the lower threaded posts into the holes, and slide forward to lock in place. 2.
- Page 24 Contact Information Product Comments Warranty Clauses 1. ReddotLED are warranted against defects in materials and workmanship for a period of THREE (3) YEAR from the purchase date. 2. Free replacements are warranted for a period of SIX (6) MONTH. 3. Warranty does not cover the following damage(s): product been modied, improper installation or use, improper clean, electrical surges, or nature caused damage.
- Page 25 RedDot LED E-mail: sales@reddotled.com Tel: +86-755-27802682 ADD: 3th Floor, Block 4, Huangpu Zhengfeng Industrial Park,Shajing street, Baoan district,Shenzhen City,Guangdong Province,China reddotled.com Product Design©2008-2019 Red Dot LED lighting Limited. All rights Reserved...
