FairCape Woodworks Adirondack Glider Assembly Instructions

Hide thumbs
1
2

Advertisement

Table of Contents

Adirondack Glider Additional Assembly Instructions


1. Turn assembled Adirondack upside down on a flat table top as shown.

2.Attach base leg supports to front and base legs. Insert two 1¾" screws through
front (square end) of one base leg support until tips show. Also insert one 1¾ " screw
and one 3" screw through back of base leg support as shown in the photo until the tip
of the 1¾" screw shows. Apply glue and line up screws to pre-drilled holes on inside
of front leg and bottom of base leg. Tighten screws. Repeat for second base leg
support on other side.
Unpack and examine all additional parts,
which consist of:
1 each: Glider base frame with swing arms
2 each: Adirondack base leg supports
1 each: Additional hardware
1 each: Assembly instructions
NOTE: BOTH BASE LEG SUPPORTS ARE
LABELLED FOR CORRECT ALIGNMENT.





Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Adirondack Glider and is the answer not in the manual?

Questions and answers

Summary of Contents for FairCape Woodworks Adirondack Glider

  • Page 1 Adirondack Glider Additional Assembly Instructions Unpack and examine all additional parts, which consist of: 1 each: Glider base frame with swing arms 2 each: Adirondack base leg supports 1 each: Additional hardware 1 each: Assembly instructions NOTE: BOTH BASE LEG SUPPORTS ARE LABELLED FOR CORRECT ALIGNMENT.  ...
  • Page 2           3.   B olt   A dirondack   C hair   t o   g lider   a rms   o f   G lider   F rame.   T urn   A dirondack   t he   r ight   w ay   up  and  place  it  over  the  glider  frame  with  the  ‘FairCape’  nameplate  facing  the  front  of  the  ...
