L&L EASY-FIRE e28S Assembling

ASSEMBLING YOUR L&L EASY-FIRE KILN ASSEMBLING YOUR L&L EASY-FIRE KILN

TABLE OF CONTENTS

TOOLS NEED FOR THE JOB . . . . . . . . . . . 1
UNPACKING . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Inspect for visible damage . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Remove Top from Carton . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unpack Instructions, Vent and Furniture Kit . . . . . . . . . . . . 2
Unpacking the kiln . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ASSEMBLING THE STAND . . . . . . . . . . . . . 4
REMOVING THE LID . . . . . . . . . . . . . . . . . . 5
REMOVING THE HINGE . . . . . . . . . . . . . . . 6
REMOVING THE CONTROL PANEL AND
ELEMENT COVER AS ONE ASSEMBLY . 6
REMOVING THE CONTROL PANEL . . . . 8
REMOVING ELEMENT COVER BOX . . . 9
LOCATING THE KILN . . . . . . . . . . . . . . . . . 10
SETTING UP THE KILN . . . . . . . . . . . . . . . . 10
SETTING UP THE HINGE . . . . . . . . . . . . . . 12
REASSEMBLING THE CONTROL PANEL 15
If you removed the panel separate from
the element cover box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
REATTACHING CONTROL BOX . . . . . . . . 16
TOOLS NEED FOR THE JOB
You will need the following tools for the job:
1) Philip's head screw driver (medium size head)
2) Knife
3) Needle Nose pliers
4) Adjustable Wrench
5) Level
6) Safety Goggles
7) Special Spring Hinge Tool (provided)
easy-fire-install.pdf
 2007 L&L Kiln Mfg, Inc. 505 Sharptown Rd, Swedesboro NJ 08085 P:856.294.0077 F:856.294.0070 sales@hotkilns.com hotkilns.com
WHAT SHOULD YOU READ?
The information in these installation instruc-
tions is as complete as we can make it - which
means that there is more than most people will
need to read or think about . Each heading is self-
contained (for instance "Assembling the Stand")
Most people will be able to figure out how to
assemble their stand by looking at it - so only
read this heading if you get stuck .
First of all be comfortable with where you
are putting your new kiln . If you have any
questions about that read the information about
clearances, ventilation, etc . in the "Installation"
tabbed section . Do that first so you don't have
to redo your work .
If there is anything we feel you must read we
will call it to your attention with one of these
shaded boxes .
CAN YOU MOVE THE KILN
WITHOUT DISASSEMBLING IT?
The kiln is shipped mostly assembled (except
for the stand and the disengaged hinge spring) .
It is possible to move the kiln without disassem-
bling it . However, these kilns, particularly the
e28S and e28T, are very heavy and awkward to
move . If you decide to move it without disas-
sembling the sections first be absolutely certain
you have at least two or three strong people
who are familiar with proper lifting techniques .
Serious back injury could result if such a heavy
object is lifted improperly . See page 5 for details
on how to do it - there are specific instructions
depending on which model you have .
3/1/2007 Rev 1.3 Page 1
