Stainless Steel
RGBW Color Changing
LED Light
Instructions for Operation
Safety • Warranty
Thank you for purchasing EasyPro's
submersible color changing LED light.
With this LED light you can illuminate a
pond or waterfall, highlight a deck or patio and extend the enjoyment of your
entire landscape in the evening hours. This light is fully submersible and may
be used in or out of water. Included is fixture with pigtail and optional stainless
steel mounting plate.
RGB9PL Specs
•
Corrosion resistant stainless steel housing, bracket and base mount
•
Epoxy filled fixtures
•
Pigtail with 5 pin, quick connect end
•
Water proof connections
•
Dimmable, 24 volt DC
•
17.5 Watts (maximum with full color mix)
•
RGBW for color mixing and true warm white color option
Safety and Electrical Connections
1.
Always disconnect the electrical supply before handling, maintaining,
repairing or installing any pond equipment.
2. Lights must be attached to a matching 5 pin RGBW cords and RGBW 5 pin
24 volt DC controller.
3. Never connect the lights directly to a 110 volt or higher outlet.
4. Connect the RGBW controller/transformer to a 110 volt receptacle that is
protected by a Ground Fault Circuit Interrupter.
5. Do not modify wiring in any way, quick plug ends must stay intact to
function and should not be replaced with any other connections.
6. Not approved for swimming pool or spa use.
7. All electrical work must be performed by a qualified technician. Always follow
the National Electrical Code (NEC) or the Canadian Electrical Code as well as
all local, state and provincial codes. Failure to follow manufacturer's installation
instructions may result in electrical shock, fire hazard, personal injury or
death, damaged equipment, provide unsatisfactory performance and will void
manufacturer's warranty.
RGB9PL
Advertisement
Summary of Contents for EasyPro RGB9PL
- Page 1 LED Light Instructions for Operation Safety • Warranty Thank you for purchasing EasyPro's submersible color changing LED light. With this LED light you can illuminate a pond or waterfall, highlight a deck or patio and extend the enjoyment of your entire landscape in the evening hours.
- Page 2 Installation of LED Light For a complete system you will need RGBC controller unit with remote control, 5 pin power cables with quick disconnects, optional splitters and RGB9PL fixture(s). All items are sold separately. 1. Before installing the product, check for damaged or missing parts.
- Page 3 9. The LED light will default to mode 1 on initial startup. Use controller’s remote to change settings and colors. 10. The longest length maximum length from controller to fixture should not exceed 300’. Remote Control Operation (remote control will come with controller) To change settings and colors, use the unit’s remote control.
- Page 4 EasyPro shall not be held liable for any loss of fish, plants or any other livestock as a result of any failure or defect of this Product.
