To our Users:
If you do not have the tools or are unaccustomed to the
installation, or you are not sure about whether any base
exists on ceiling or wall, or when installing this product
on a concrete wall, ask the professional installer.
About the professional installer, ask your dealer or
us.
Professional installers that have contracted for the
installation should submit this manual together with
the instruction manual.
Thank you for your purchase.
■ Ensure that you read this installation and instruction manual carefully and use the screen correctly.
Be sure to retain the manuals for future reference.
E110628E(I)
E1 Electric Screen
Index
Safety Precautions・・・・・・・・・・ 2〜4
Accessories ・・・・・・・・・・・・・・ 5
Construction & Parts name ・・・・・・・ 6
Cautions in installation・・・・・・・・ 7
Installation Guideline ・・・・・・・ 8〜9
Fitting IR receiver & power cable
Cautions: operation of screen
Limit Switch Setting
Q&A
Specifications ・・・・・・・・・・・17〜18
1
・・ ・ 10
・・・・
・・・・
12〜15
・・・・・・・・・・16
11
Advertisement
Related Manuals for OSI CO Os Screen E1 Series
Summary of Contents for OSI CO Os Screen E1 Series
- Page 1 E1 Electric Screen To our Users: If you do not have the tools or are unaccustomed to the installation, or you are not sure about whether any base exists on ceiling or wall, or when installing this product on a concrete wall, ask the professional installer. About the professional installer, ask your dealer or Professional installers that have contracted for the installation should submit this manual together with...
- Page 2 Important Safety Instructions Ensure you follow the below instructions for safety. This manual explains the necessary precautions to prevent the harm to the user or the others and any damage to property. ■ The marks show the level of harm and damage caused by the mal-handling or the disregard to the precautions.
- Page 3 WARNING Stop using, when anything like metal, water, or liquid goes into the screen, and pull out the power plug. The continuous use may cause a fire and an electric shock. Take the power plug to connect, not the power cable. It may damage the power cable and cause a fire and an electric shock.
- Page 4 CAUTION Do not pull out the screen more than the STOP label point. The screen fabric may fall out. Do not put anything or fragile thing below the screen. Anything could block the movement of the screen causing damage. Do not use the sharp cutlery or pointed metal near the screen. It might damage the screen fabric.
- Page 5 Accessories Please confirm the accessories before installation. The parts and tools are subject to change according to the installation places and mounting methods. Infrared remote controller x1 AAA dry batteries x2 Infrared receiver x1 Spare sticker x1 Mounting brackets x2 Stoppers x2 ...
- Page 6 Construction & Parts name The screen is composed of parts as below. Please confirm before installation Screen main unit Case Screen Fabric STOP Label Infrared receiver Refer to page 7 Power Supply (Left) Under pipe Input (large) for FS-1(Option) Adjustment knob Input (small) for Infrared receiver Mounting bracket...
- Page 7 Cautions in installation ■ Do not install the screen to such places to avoid malfunctioning and troubles. Place where vibration and impact might apply. Place where heat, steam, and oil or smoke generates. Place where wind of heating apparatus comes ■ Please check the structure and material of the mounting place before installation. ■ Make sure to put a blanket or soft cloth before installation to avoid any damage to the product or the floor.
- Page 8 Installation Guideline [Introduction] Please note all the parts have the determined mounting area and direction. Follow the instructions and drawings in this manual before installation. When installing this product, tighten the attached screws into base wood with more than 20 mm thickness in the ceiling or wall. If the base WARNING ...
- Page 9 3. Mounting the main unit １）Fit the mounting bracket into the groove of Mounting bracket the screen case and then push the case horizontally in the direction of the arrow so that the fixed spring hooks in with the click sound ...
- Page 10 Fitting the IR receiver and power cable For those users who use FS-1, please refer to the instruction manual of FS-1. FS-1 should be connected to the input (large). 1) Connect the plug of the Infrared receiver (the cable length is 300mm) to the input (small) located at the left cap of the case.
- Page 11 CAUTION : operations of screen ■ Be careful in repeating the screen going up and down. ●The continuous use of the up and down operations may cause the heat prevention circuitry work, and stop the screen. When this happens, please operate after some time (15 – 20 minutes) for cooling off. This is not the breakdown.
- Page 12 Limit switch setting ■ Change of【U P】position It should be below the pre-set position. Take off the white cover for the limit adjustment hole. Confirm the adjustment volume. Make sure the screen is set at UP (Stored) position before adjustment. ...
- Page 13 Reminder: Be careful in repeating the screen going up and down. The continuous use of the UP and DOWN operations may cause the heat prevention circuitry work and stop the screen. When this happens, please operate after some time (15-20 minutes) for cooling off. -This is not the breakdown.
- Page 14 ■ Change of【DOWN】position It should be upper than the pre-set position. Confirm the adjustment volume in the left side of the case. Make sure the screen is set at DOWN (Projection) position before adjustment. Limit adjustment volume ...
- Page 15 Reminder: Be careful in repeating the screen going up and down. The continuous use of the up and down operations may cause the heat prevention circuitry work, and stop the screen. When this happens, please operate after some time (15-20 minutes) for cooling off. This is not the breakdown.
- Page 16 Q&A Please do the following checks before requesting for repair when malfunction happens. Please pull out the power plug before you check. If the malfunction cannot be remedied even after all the checking points as below are confirmed, consult with the dealer or us. Symptom Check Remedy...
- Page 17 Specifications E1-□□□H-□□□/E1-□□□V-□□□ ■Side view(Stored) Total length A From screw to screw G ■Mounting bracket E110628E(I) 17 ...
- Page 18 2571×1094 2846 2250 or above 12.5 Specifications and design may change without prior notice. OSI CO., LTD. Room 1605, 16/F, Seaview Centre, 139 Hoi Bun Road, Kwun Tong, Kowloon, Hong Kong PHONE : +852-3580-0087 FAX : +852-2367-4300 E-mail : info-hk@os-worldwide.com U R L : http://hk.os-worldwide.com ...
