Quick
Installation Guide
300Mbps Wireless AP/Client Router
TL-WR843N
Configure the Router
WISP Client Router Mode
1 Connect the power adapter to your router and plug the power adapter into an outlet, and then
press the ON/OFF button to turn on the router.
2 Connect your device to the router wirelessly or via an Ethernet cable. The Wi-Fi network name
and password is on the router's label.
3 Launch a web browser and type http://tplinkwifi.net into the address bar. Enter admin (in
lowercase) for both user name and password to log in.
4 Click Quick Setup on the left panel and click Next to start configuring the router. Select the
Control the system mode by software checkbox. Select WISP Client Router mode and click
Next.
*
Power the router with the included passive PoE injector.
Use this when the router is installed in a location far from a power outlet.
Public Wi-Fi
Network Name
Note:
1. The passive PoE injector supports a cable length up to 30 meters
due to the environment.
2. If you need a longer data transmission distance (not exceeding 100
meters), TP-LINK's 48V PoE adapters such as TL-POE200,
TL-POE150S and TL-POE10R are recommended.
Product information can be found on our official website
http://www.tp-link.com.
Public Wi-Fi
Network Name
ON/OFF POWER
ON/OFF POWER INTERNET 1
Getting Started
Which mode do you need? Please refer to the table to choose the appropriate operation
mode.
I want to connect to a Wireless Internet Service Provider (WISP),
and share the Internet with local devices.
The wired network is only limited to one device to connect at a
time, but I want to share the Internet with more wireless
devices.
You can configure the router using the Setup Wizard on the supplied CD-ROM (for
Windows only), or simply follow the specific instructions in this Quick Installation Guide
for your selected operation mode.
WPS/
INTERNET 1 2 3 4 ROUTER WISP RESET
LAN (1/2/3/4)
5 Select the WAN Connection Type of your Internet Service Provider and follow the
screen instructions to configure the router. In the most common setup, select
Dynamic IP.
6 On the Wireless screen, click Survey to automatically find all available networks.
7 Click Connect button next to the Wi-Fi network you want to connect to.
8 Type in the selected Wi-Fi network's password when prompted. In the AP settings
section, customize your Wi-Fi network name and password, then click Next.
9 Click Reboot to complete the configuration.
Enjoy!
WPS/
2 3 4 ROUTER WISP RESET
Scenarios
TL-WR843N's
Wi-Fi Name
TL-WR843N's
Wi-Fi Name
Passive PoE Injector
Operating Modes
WISP Client Router
Standard Wireless Router
or
or
