- Page 1 Installation, use and maintenance Type 4 barrier for Access Control with Muting functions integrated...
-
Page 2: Table Of Contents
OVERRIDE WITH HOLD-TO-RUN CONTROL ....................34 OVERRIDE WITH PULSE CONTROL ......................34 RESTART (MANUAL OPERATION) ........................35 AUTOMATIC OPERATION ..........................35 MUTING ENABLE............................... 36 REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 3 HARDWARE characteristics requested by the PC for connection................66 SOFTWARE characteristics requested by the PC for connection ................66 How to install SAFEGATE CONFIGURATOR ......................66 CONFIGURATION PHASES..........................66 THE TOOLBAR ..............................67 REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
- Page 4 SAFEGATE DIAGNOSTIC - ERRORS ......................79 CONTROLS, CARE AND MAINTENANCE ................80 PRE-ACTIVATION CHECKLIST ........................80 PERIODIC CONTROL ............................80 CARE AND MAINTENANCE ..........................81 WARRANTY ..........................82 REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 5: Introduction
¾ SAFEGATE active and passive element ¾ CD-ROM (Containing configuration software and this Manual) ¾ Quick Installation Guide ¾ Mounting accessories bag ¾ Sealing caps for unused connectors REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 6: Glossary
Directive 2012/19/EU as implemented in the Member State where the product is disposed of. For further information please contact REER or your local dealer. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 7: Safety
The strict and complete observance of all the standards, indications and prohibitions set forth in this manual is a prerequisite for its proper operation. REER S.p.A. therefore, declines any liability in case of non-respect, even partial, of these indications. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 8: Cautions Before Installation
If the device is placed in environments subject to sudden temperature fluctuations, it is imperative to take the appropriate steps to avoid condensation on the lenses, which may impair the detection capability. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 9: List Of Applicable Standards
SIL 3 Safety level ¾ IEC 61508-3:(ed.2) ¾ IEC 61508-4:(ed.2) SILCL 3 ¾ IEC 62061:2005/A2:2015 PL e - Cat. 4 ¾ EN ISO 13849-1: 2015 REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 10: Ec Declaration Of Conformity
TÜV SÜD Product Service GmbH – Zertifizierstelle – Ridlerstraße 65 – 80339 – München – Germany N.B. number: 0123 - Certificate No: Z10 17 12 24820 074 Carlo Pautasso Simone Scaravelli Direttore Tecnico Amministratore Delegato Technical Director Managing director REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 11: System Architecture
Main connector Seat for anchorage of any Muting arms Sensor 3-4 Muting Sensor 1-2 connector Muting connector Signals label REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 12: Possible Configurations (Via Optional Accessories)
ACTIVE ARM ACTIVE ARM Optional Optional Accessory Accessory MAT4P TRX 2R SX V MAT4P TRX 2R DX V REFLECTOR REFLECTOR Optional Optional Accessory Accessory REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 13 MA2P SX 2B MA2P DX 2B ACTIVE ARM ACTIVE ARM Optional Optional Accessory Accessory MA2P SX 2R MA2P DX 2R REFLECTOR REFLECTOR Optional Optional Accessory Accessory REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
- Page 14 MZT4PP SX MZT4PP DX ACTIVE ARM ACTIVE ARM Optional Optional Accessory Accessory MZT4PA SX MZT4PA DX ACTIVE ELEMENT ACTIVE ELEMENT Optional Optional Accessory Accessory REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 15: The Muting Function
¾ If the distance between the muting sensors is lower than required, the SAFEGATE safety function is not guaranteed. ¾ Make sure that the MUTING/OVERRIDE signal lamp is correctly installed in a visible location by the operator. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 16: A) 2 Integrated Cross Muting Sensors, Only For Pallet Outputs (Lx)
Î The minimum distance between two consecutive pallets must be less than 10 cm or greater than 32cm. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 17: B) 2 Integrated Parallel Muting Sensors, Only For Pallet Outputs (L2)
For the safe operation of the L2 configuration, it is imperative that horizontal Muting sensors are located within the hazardous area. Î The minimum distance between two consecutive pallets must be greater than 40 cm. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 18: C) 2 Integrated Cross Muting Sensors, For Bi-Directional Gates (Tx)
This mode also allows selecting the maximum duration of the Muting condition (timeout) as 30 seconds or 9 hours. Î Î Other timings are available with programmable programs. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 19: D) 4 Integrated Parallel Muting Sensors, For Bi-Directional Gates (T4)
Other timings are available with programmable programs. Î Î In both modes of operation, the minimum pallet length must be 70 cm (to ensure simultaneous occupancy of all four sensors). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 20: E) 2 External Cross Integrated Muting Sensors, For Bi-Directional Gates (Tx)
Muting condition (timeout) can be selected in 30 seconds or 9 hours. Î Î Other timings are available with programmable programs. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 21: F) 4 External Parallel Muting Sensors, For Bi-Directional Gates (T4)
Other timings are available with programmable programs. Î Î In both modes of operation, the minimum pallet length must be 70 cm (to ensure simultaneous occupancy of all four sensors). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 22: Partial Muting
6 of the active element) must switch from LO to HI (rising edge) before starting the Muting cycle. Î Î Refer to the “OPERATING MODES” section to correctly set this function. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 23: Muting Override
The timer (point 1) and the counter (point 2) are reset if one of the following conditions occurs: 1. A proper sequence of Muting. 2. A system reset (turning it off and on). the parameter “timeout override” can be set through the configuration software. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 24: Installation
T1 response time of the protection device in seconds T2 machine reaction time to stop the hazardous operation, in seconds. additional distance expressed in mm. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 25: Models With 2/3/4 Beams
European standard EN 415-4, which are repeated here. From low level (floor) Above the conveyor (rollers) Device with 3 beams at least Device with 2 beams at least Dimensions in m REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 26: Multiple Systems
Systems side by side: A Adjacent positioning of the two Active Elements Overlapping systems: B “L” combination: C Cross-positioning between Active and Passive elements REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 27: Distance From Reflecting Surfaces
Active Element and Passive Element. During this procedure, the red LED on the Passive Element must never go off. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 28: Mechanical Assembly And Optical Alignment
If the Active and Passive Elements are mounted in areas subject to strong vibrations, in order not to compromise the operation of the circuits, it is necessary to use anti-vibration dampers. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 29: Sm - Smo Models Electrical Connections
(3) 0VDC (4) SENSOR1 (“Table 4”, page 31) (“Table 3”, page 31) Modelli SMP, SMPO REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it (10) OVER1_RESTART (2) USB+ 0VDC (2) (1) 24VDC MUT_LAMP (1) - Page 30 In free protected area conditions, the Active Element provides a voltage of 24VDC on both outputs. Therefore, the established load must be connected between both output terminals and the 0VDC. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 31: Test Function
(this time is declared for each model). This fault detection system is always active and does not require any external intervention. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 32: Selection Of Operating Modes
STATUS (12) 4 SENSORS CONCURRENT 9 hours n.c. / 0VDC n.c. / 0VDC Configuration error n.c. / 0VDC n.c. / 0VDC SPM/SPMO models: programming needed REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 33: Edm
The time allowed to elapse from the activation of the OSSD outputs and the opening of the FBK t < 500ms. contacts must be REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 34: Override
The function starts only if the signals are activated at the same time (within a maximum delay of 400 ms) and the control is kept active for at least 400 ms. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 35: Restart (Manual Operation)
If the SAFEGATE light curtain is used in AUTOMATIC mode, it will not be equipped with a start/restart interlock circuit. In most applications, this safety function is mandatory. Carefully evaluate the risks analysis of your own application. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 36: Muting Enable
The Muting cycle is activated only with the correct transition of the MUTING ENABLE signal Enabled (see figure below) and will terminate with the release of the last sensor. Muting Enable active: correct Muting sequence REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 37: Appendix A1: Sm - Smo Models Wiring Samples - Manual Mode
OVERRIDE1_RST, (10) Violet OVERRIDE2 (9), Red EDM (8), Grey MUT_ENABLE (7) Black * (See diagram 2 for Override/EDM/Mu�ng Enable configura�on in Manual) PE (5), Pink REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 38 MUT_ENABLE (7) Black ENABLE STATUS (12), Red/Blue SEL_A (6) Yellow * (See diagram 1 for Mu�ng PE (5) SEL_B (11) configura�on in Manual) Pink Pink/Grey REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 39: Appendix A2: Sm - Smo Models Wiring Samples - Automatic Mode
OVERRIDE1_RST, (10) Violet OVERRIDE2 (9), Red EDM (8), Grey MUT_ENABLE (7) Black * (See diagram 4 for Override/EDM/Mu�ng Enable configura�on in Manual) PE (5), Pink REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 40 MUT_ENABLE (7) Black ENABLE STATUS (12), Red/Blue SEL_A (6) Yellow PE (5) SEL_B (11) Pink Pink/Grey * (See diagram 3 for Mu�ng configura�on in Automa�c) REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 41: Smp - Smpo Models Electrical Connections
To check the SMP/SMPO model wiring with software configuration, refer to the paragraph “APPENDIX B: SMP - SMPO MODELS WIRING SAMPLE”, page 49 diagrams. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 42 Refer to the section “SELECTION OF SEL_B Grey/ Pink Input MUTING CONFIGURATION OPERATING MODES”, page 42 STATUS Red/Blue Output SYSTEM STATUS PNP active high REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
- Page 43 Using LX or TX configuration with 2 sensors: SENSOR1 wiring is mandatory, while the position of the second muting sensor is free between SENSOR2 and SENSOR3. SENSOR2: sensor arms MALX; SENSOR3: sensor arms MATX or external photocells. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 44: Test Function
The time allowed to elapse from the activation of the OSSD outputs and the opening of the FBK contacts must be the one indicated in the figure below. SOFTWARE CONFIGURATION: FBK K1/K2 reading delay programming: Range allowed: 100ms to 1300ms (100ms steps). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 45: Override (Pc Programming)
The function starts only if the signals are activated at the same time (within a maximum delay of 400 ms) and the control is maintained active for at least 400 ms. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 46: Restart (Manual Operation)
If the SAFEGATE light curtain is used in AUTOMATIC mode, it will not be equipped with a start/restart interlock circuit. In most applications, this safety function is mandatory. Carefully evaluate the risks analysis of your own application. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 47: Muting Enable
ENABLE/DISABLE signal. Furthermore is possible to choose if the MUTING ENABLE only enables or also enable/disables the Muting function thanks to the programming software. Muting Enable/Disable active: Correct Muting sequence REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 48: Partial Muting
This activation only applies to a STAND-ALONE MUTING CYCLE; it is therefore necessary to reconfirm the partial Muting deactivation before any new Muting function request (refer to the timing below). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 49: Appendix B: Smp - Smpo Models Wiring Sample
Black N.C. EXT_ENABLE PARTIAL MUTING ON SEL_A / PARTIAL MUTING PARTIAL_MUTING (6) Yellow N.C. PARTIAL MUTING OFF N.C. SEL_B (11), Pink/Grey PE (5), Pink REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 50: S Models Electrical Connections
(“Table 7”, page 51) (“Table 8”, page 51) 24VDC (2) (8) PE OSSD2 (3) (1) OSSD1 EDM (4) (7) 0VDC SEL_A (5) (6) SEL_B REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 51 : connected to : 24VDC with EDM (through the RESTART pushbutton) 24VDC (PIN 2) (through series of contatcts N.C. of external relays) REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 52: S-A Models Electrical Connections
50 m). CONNESSIONI ELEMENTO ATTIVO ACTIVE ELEMENT CONNECTIONS (“Table 9”, page 53) OSSD1 (2) (1) 24VDC 0VDC (3) OSSD2 (4) (5) PE REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 53: Automatic Operation
(this time is declared for each model). This fault detection system is always active and does not require any external intervention. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 54: Appendix C: S Models Wiring Samples
SEL_B (6) PE (8) SEL_B (6) Pink Pink OSSD1 (1) +24Vdc White EDM (4) GND (7) Yellow Blue +24Vdc EDM (4) Yellow PE (8) REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 55: Light Signals
Override request Flashing Yellow Sensor interrupted Blue Orange No barrier programmation Flashing Flashing Detected double programmation Blue Orange Flashing Flashing Flashing (hardware and software) REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 56: Active Element Signals (S / S-A)
Generic default board error: Contact ReeR after sales service Interfering Emitter Detected: Verify the presence of another curtain not 8 blinks red correctly positioned (see section “MULTIPLE SYSTEMS”) REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 57: Active Element Signals (Integrated Lamp)
Curtain awaiting RESTART (gate clear) Green Normal operation (gate clear) Occupied gate Red Flashing Detected failure (-> DIAGNOSTICS) Yellow Muting active Yellow Flashing Override active Yellow/Red Override request REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 58: Active Element - Fault Diagnosis
Receiving beams failure Contact ReeR after sales service Verify the presence of another curtain not correctly positioned Interfering Emitter Detected (see section "Multiple Systems") REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 59: Technical Specifications
Operating temperature -30°C ÷ +55°C Degree of protection IP 65 and IP 67 Section Size (l x h) 50mm x 55mm * S-A models excluded REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 60 Pin on main connector, disabled if not required and monitored S, SM, SMO, SMP, SMPO Multibeam MODELS Beams Response time (ms) 7,42E-09 7,58E-09 7,68E-09 MTTF 409,0 401,0 399,4 98,5% 98,2% 99,2% REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
- Page 61 With 4 parallel photocells M TRX Number of single photocell beams Response time (ms) Working range (m) 0...2 (MZT4P TRX G) Working range (m) 1...3,5 (MZT4P TRX) REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 62: Mechanical Dimensions
Models with Lamp without lamp MODEL A1 (mm) A2 (mm) B (mm) 1012 1112 1087 LL fixing brackets Fastening inserts with 2 M6x16 pins REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 63: Accessory Dimensions
MAL2P TRX V - 2 parallel beams muting arm with reflector (high speed) MA2P SX 2R V MA2P DX 2B V REFLECTOR ACTIVE ELEMENT REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... - Page 64 MAT4P TRX V 2B SX MAT4P TRX V 2B DX ACTIVE ELEMENT ACTIVE ELEMENT MAT4P TRX V 2R SX MAT4P TRX V 2R DX REFLECTOR REFLECTOR REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
- Page 65 MZT4P TRX - 4 parallel beams M TRX muting arms MZT4PP SX MZT4PP DX REFLECTOR REFLECTOR MZT4PA SX MZT4PA DX ACTIVE ELEMENT ACTIVE ELEMENT REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it...
-
Page 66: Software Safegate Configurator
¾ CONFIGURATION VALIDATION AND LOADING ¾ CONFIGURATION DELETION ¾ PRINT REPORT ¾ CURTAIN ACTIVATION ¾ CURTAIN CONDITION MONITORING ¾ ERRORS DOWNLOAD ¾ ERRORS HISTORY REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 67: The Toolbar
13-> ERRORS DOWNLOAD (refer to the errors table at the end of the manual) 14-> ERROR HISTORY CANCELLATION 15-> CHANGE PASSWORD 16-> CONFIGURATION DELETION REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 68: Graphical Interface
SAFEPASS password (all capital letters). The operator who knows the level 2 password is enabled to enter a new level 2 password (alphanumeric, max 8 characters). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 69: Connection With Safegate
¾ In order to view the curtain configuration, it is necessary to request a download of the configuration (icon Î Î Otherwise, the SAFEGATE configuration procedure is required. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 70: Curtain Programming
CONFIGURATION VALIDATION AND LOADING (icon ¾ Check the correctness of the configuration with the validation procedure (icon ¾ Then send the configuration to SAFEGATE and confirm: REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 71: Print Report Configuration
, the operator can download the Errors Log file containing Error Code, Micro involved and Error Address. Please refer to the errors table at the end of the manual to follow the appropriate corrective action. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 72: Safegate Activation
FBK K1/K2 reading time: Lets you set a delay in reading the external FBK signal. Possible values: from 100 ms to 1300 ms (with 100 ms steps). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 73: Setting Muting Parameters
If selected, it allows Muting activation only if it is time >150 ms between activation of sensor 1 and sensor 2 (or sensor 4 and sensor 3). External Lamp Control: If selected, the Muting lamp is compulsory. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 74: Sequential" Muting
SENSOR, closure occurs after the release of the last but one sensor. External Lamp Control: If selected, the Muting lamp is compulsory. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 75: L" Muting
If selected, it allows Muting activation only if it is time >150 ms between activation of sensor 1 and sensor 2 (or sensor 4 and sensor 3). External Lamp Control: If selected, the Muting lamp is compulsory. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 76: T" Muting
If selected, it is only possible to activate Muting if a time > 150 ms elapses between the activation of Sensor 1 and Sensor 2 (or Sensor 4 and Sensor 3). External Lamp Control: If selected, Muting lamp is compulsory. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 77: Partial Muting
10 beams was selected. THE BEAMS WITH Partial Muting FUNCTION ARE HIGHLIGHTED IN YELLOW, WHILE GREEN COLOURED BEAMS WORK NORMALLY: ACTIVE CURTAIN. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 78: Muting Override
OVERRIDE request. Timeout: It allows you to set the time, which varies from 10 seconds to infinity, within which the function Override must end. REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 79: Safegate Diagnostic - Errors
Muting sensors configuration error ¾ Verify position of sensor 2 with the software ¾ If no error is detected, return the barrier to ReeR to be repaired REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 80: Controls, Care And Maintenance
AUTOMATIC: Stop at least one beam of the protected area and verify that the green LED is lit again on correct operation (beams free). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 81: Care And Maintenance
It is therefore essential to pay particular attention during the cleaning steps of the curtain front window, particularly in environments where abrasive powders are present. (e.g. cement plants, etc.). REER S.p.A. - Via Carcano, 32 - 10153 Torino, Italy - Internet: www.reersafety.com - e-mail: info@reer.it... -
Page 82: Warranty
The validity of the warranty is subject to the following conditions: Î Î The failure must be reported by the user to REER within twelve months from the date of delivery of the product. Î Î...
