Great Outdoors
STAINLESS
Assembly and Owner's Manual
Stainless
Series
Gas Grill
ASSEMBLER / INSTALLER:
Leave these instructions with the consumer.
CONSUMER / USER:
Read all of these instructions and keep them in a safe place for future reference.
FOR YOUR SAFETY
If you smell gas:
1
Shut off gas to the appliance.
2
Extinguish any open flame.
3
Open lid.
4
If odor continues, immediately call
your gas supplier or fire department.
FOR YOUR SAFETY: Never leave a grill unattended when in use.
FOR YOUR SAFETY
1
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2
An unconnected liquid propane
cylinder should not be stored in the
vicinity of this or any other appliance.
TM
