UCView VIEW MEDIA 10 PLAYER Installation Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

UCView
Reaching Your Audience
Thank you for purchasing the UCView View Media 10 player. Please match the items on the list
below with the items in the box. If any item is missing or damaged, please contact your UCView
Media Networks sales representative immediately.
• One (1) View Media 10 player
• One (1) Power supply
• One (1) Cable cord
• One (1) Antenna

Installing your VM 10 Player

Remove packaging - make sure box and plastic casings are stored away in case a return is
1
necessary.
2
Plug in the LAN/Ethernet cable into the VM 10 player.
3
Plug in your video source, HDMI or VGA cable, into the VM 10 player and the monitor.
4
Plug in the Power cable into the VM 10 player.
5
Attach the antenna, which is included in your package, to your VM 10 player.
LAN/Ethernet
1
HDMI
HDMI (High-Definition Multimedia Interface):
transmitting high - definition video and high - resolution audio.
DVI (Digital Video Interface):
signal.
VGA (Video Graphics Array):
computer to a monitor.
LAN/Ethernet:
A LAN/Ethernet cable can connect to devices over a local area
network, such as PCs and routers.
VIEW MEDIA 10 PLAYER
INSTALLATION MANUAL
VGA
A single cable which is capable of
A cable which is capable of providing digital video
An analog cable which enables connection from your
Power

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIEW MEDIA 10 PLAYER and is the answer not in the manual?

Questions and answers

Summary of Contents for UCView VIEW MEDIA 10 PLAYER

  • Page 1 INSTALLATION MANUAL Reaching Your Audience Thank you for purchasing the UCView View Media 10 player. Please match the items on the list below with the items in the box. If any item is missing or damaged, please contact your UCView Media Networks sales representative immediately.
  • Page 2 Note: Image depicts the back portion of the VM 10 player. Please connect your cable to the appropriate receptacle labeled below. Images are subject to change without notice. Antenna USB port HDMI LAN/Ethernet Power Once the appropriate cables are securely attached to both the VM 10 player and the monitor, firmly press the power button, which is located in front of the VM 10 player.
  • Page 3 Open up an Internet browser. Type in portal.ucview.com (or your server’s address) in the address bar. A login screen will appear. Once you press enter, the user interface displaying EZBoard, Campaigns & Ads, etc., will appear.
  • Page 4 Open up an Internet browser. Type in portal.ucview.com (or your server’s address) in the address bar. See user manual or video tutorials for more information. UCView Reaching Your Audience 18425 Napa St Northridge, CA 91325 Tel: 1-818-772-8255 Toll Free: 1-877-828-4399...
