Lisa 1DR Manual

Standalone door alarm

Hide thumbs

1DR specific Power Supply/Controller/

Strobe Assembly x 1 each

Telescoping Sensor & Fasteners

# 8 Wood Screws

x 4 each

10-24 Carriage Bolt, Hex Nuts,

Washers & Lock Washers x 4 each

Allen Key

Ligature Resistant Hinge

12-24 x ½ Torx Flat

Head Screw x 15 each

INS LISA 1DR.vsd Created: 10-6-201 7 Revise d:10-6-201 7

–

x ½ Flat Head Security Screw x 2 each,

Cylindrical Locking Ring x 1 each & 1DR

specific alarm shunt keyswitch w/ surface

mounted box and armored cable x 1 each

Cylinder by others: 1-1/8" to 1-3/8" Cylinder,

Cloverleaf Cam Recommended

–

Telescoping Sensor x 1 each

#10-¾ self Drilling Screw

X 4 each

¼ - 20 x 1-5/8" Sex Bolt

LISA 1DR (Standalone Door Alarm)

x 3/16" Pan Head Phillips Screws, #8 Washers x 2

each & Mounting Plate Spacer x 1 each

¼ - 20 x 1" Torx Flat

Head Screw

x 9 each

INS 00001 30-01 v1.0

Packing List

#8 Wood Screws &

Plastic Anchors x 4

each

(7) Armore d Cab le S trap s

(14) Se lf

drill ing

scre ws

Wire Harness x 1 each

Bottom Portion

Top Portion

Full-Surface Continuous

Hinge x 1 each

Pag e 1

Table of Contents

Need help?

Do you have a question about the 1DR and is the answer not in the manual?

Questions and answers

Summary of Contents for Lisa 1DR

Page 1 X 4 each Head Screw x 9 each ¼ - 20 x 1-5/8" Sex Bolt x 9 each Top Portion Full-Surface Continuous Hinge x 1 each INS LISA 1DR.vsd Created: 10-6-201 7 Revise d:10-6-201 7 INS 00001 30-01 v1.0 Pag e 1...
Page 2 Connect wiring per wiring diagram. Key switch is NC system can not work without DOOR SENSOR See Separate sheet provided for installation instructions. Note that additional sensors/ doors can be added in parallel (see wiring diagram) INS LISA 1DR.vsd Created: 10-6-201 7 Revise d:10-6-201 7 Pag e 2...
Page 3 Test the operation of the sensor. Cover screw Door INS LISA 1DR.vsd Created: 10-6-201 7 Revise d:10-6-201 7 Pag e 3...
Page 4 18) Hold the sensor and depress for 3 sec or longer. LED should turn into red. If not, sensor should be adjusted for more sensitivity. 19) Test the operation again. If good, apply blue LOCTITE® for safety to the screws and install. INS LISA 1DR.vsd Created: 10-6-201 7 Revise d:10-6-201 7 Pag e 4...
