UDG Ultimate Trolley to go Assembly Instruction

Prepare a wrench, hex wrench
1
and new wheels set.
10
( 1 set spare part for right & left wheel )
wheel, screw, washer & nut
4
R
C C
Install the new wheel, screw, washer & nut
L
C
Doc. No. 2016 /4/25 V1
2
Turning anticlockwise the right wheel
and turning clockwise the left wheel
for loosen the screw
5
D
Tighten up the new wheel
with hex key & wrench
C
D
UDG Ultimate Trolley to go
UDG Ultimate DIGI Trolley to go
3
R
L
C
R
D
L
D

Wheel assembly instruction

UDG Ultimate Slingbag Trolley Deluxe
UDG Ultimate Slingbag Trolley set Deluxe
C
A
A
B
B
A
A
B
B
A Put the wheel into the frame
B
Install the screw into the hole between
frame & bearings
C
Install the nut into the screw inside the bag
D Tighten up the new wheel with hex
key & wrench.
C
C
