GOLD HUNTER
Gold metal detector that
visualizes buried metals
on your smatphone
User manual
TREASUREHUNTER3D
Makes underground treasures visible

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOLD HUNTER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TreasureHunter3D GOLD HUNTER

  • Page 1 GOLD HUNTER Gold metal detector that visualizes buried metals on your smatphone User manual TREASUREHUNTER3D Makes underground treasures visible...
  • Page 2 TREASUREHUNTER3D Instruction manual Makes underground treasures visible Table of contents...
  • Page 3: Table Of Contents

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Welcome Read before use - important notes Metal detector safety warnings ���������������������������������������������������������������������������������������������������������������������������������������������������������������������5 Treasure hunter’s code of ethics �������������������������������������������������������������������������������������������������������������������������������������������������������������������5 Safety precaution for use ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������5 Assembly & getting started Assembly ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Battery ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Battery Status Indicator �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Smart control unit ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������8...
  • Page 4: Welcome

    Here at TreasureHunter3D we are constantly focusing on innovating in order to provide high quality, affordable & easy to use products that incorporate high technology to our customers, by purchasing this device you are helping us to push metal detecting to the next level�...
  • Page 5: Read Before Use - Important Notes

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Read before use - important notes Metal detector safety warnings Any piece of equipment can be dangerous if not operated properly� It is YOU who is responsible for the safe operation of this equipment�...
  • Page 6: Assembly & Getting Started

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Assembly & getting started...
  • Page 7: Assembly

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Assembly 1. Attach coil to lower shaft� 2. Connect coil� 3. Fix smart control unit and make sure the batteries are inserted� Incorrect way of sweeping In order to get the best results it is important to keep the search coil parallel to the ground.
  • Page 8: Smart Control Unit

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Smart control unit GREEN BLUE device smartphone turned ON connected Headphones connector Sensitivity / gain knob Threshold knob Discrimination / ground balance Volume buttons buttons Power button: Holding this button for Pin-point / Ground grab button...
  • Page 9: Smartphone Application

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Smartphone application GoldHunter uses iOS application to display detector information as well as 3D object scans� In order to use all GoldHunter features, iPhone 6s or later model must be used� 1. Install GoldHunter application Applications can be downloaded from http://www�treasurehunter3d�com/downloads...
  • Page 10: Detector Basics & Operating Modes

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Detector basics & operating modes...
  • Page 11: How Does Detector Work

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible How does detector work? Metal detectors work by 1� transmitting a magnetic field generated by coil and then 2. analyzing that field as it returns from the environment that the signal was transmitted� 3. Processing of the signal is done by control unit that 4.
  • Page 12 TREASUREHUNTER3D Instruction manual Makes underground treasures visible GOLDHUNTER DETECTOR OPERATES IN THREE MODES DISCRIMINATION MODE This mode is recommended for starters and beginners, it is simple and easy to use, it provides quick information of type and depth of buried object and good performance.
  • Page 13: Discrimination Mode

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Discrimination mode How to identify buried objects or what is Target ID? Target ID is used to distinguish one type of metal target from other� GoldHunter detector offers three Target ID presentations for beginners and also for advanced / experienced users�...
  • Page 14 TREASUREHUNTER3D Instruction manual Makes underground treasures visible TARGET ID ICONS E.g. Rings, pull tabs and lower E.g. Iron objects, nails and value coins. horseshoes. E.g. Aluminium foil and lower E.g. Low and high value coins value coins. and screwcaps. Target ID accuracy There are many factors that influence on Target ID accuracy, like soil mineralisation or angle between target and coil, by gaining experienced in the field, you should be able to recognised many types of targets by Target ID value.
  • Page 15 TREASUREHUNTER3D Instruction manual Makes underground treasures visible SILVER TARGET ID OTHER MATERIALS TARGET ID Silver engagement ring Brass head of gun shell 53-55 Silver Sterling stud earrings 83-85 Platinum Ring Silver engagement Ring 83-86 Lead bale Seal 72-74 with Gem stone...
  • Page 16: What Does Gain Knob Do

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible What does gain knob do? For beginners it is recommended to start with The higher sensitivity, the deeper or smaller objects can be gain at middle position or lower, so that you don’t detected�...
  • Page 17: How To Setup Detector To Ignore Items Like Nails, Cans & Aluminium Foil

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible How to setup detector to ignore items like nails, cans & aluminium foil? Discrimination is ability of metal detector device to eliminate BLUE and RED line on top of Target ID scale indicates weather unwanted targets like trash &...
  • Page 18: All-Metal Mode

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible All-metal mode How to eliminate interference of ground minerals? Soil contains iron minerals that can cause much higher signals than buried targets we are interested in� With ground balancing we calibrate detector device to local ground, this eliminates false signals from minerals , enabling detector to detect deeper and provide more accurate Target ID results�...
  • Page 19: Manual Adjust

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Manual adjust User is also able to manually set or adjust Ground Balance values by + an - button on the control box� SOME TYPICAL GROUND MINERALIYATION TYPES ARE: For fine adjustment user should continue to raise and lower...
  • Page 20: 3D Ground Scan Mode

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible 3D ground scan mode Performing 3D ground scanning 3D ground scan mode enables user to visualize buried objects. In order to perform 3D scan of an object user should do the following: 1. Enter 3D ground scan mode�...
  • Page 21: Detector Sounds And Environmental Interferences

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Detector sounds and environmental interferences When target is detected metal detector device produces sound through internal speaker or headphones when it those are connected� User is able to adjust volume by +- buttons on the control box at any time�...
  • Page 22: Smartphone Application Features

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Smartphone application features...
  • Page 23: Connectivity Splash Screen

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Connectivity splash screen Connectivity splash screen will appear when device is not connected or connection with device was lost� In such situation user must make sure: • that battery is installed in metal detector and is full •...
  • Page 24: 3D Scan Examples

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible 3D ground scan mode When device is operating in 3d ground scan mode user is able to: • Adjust transparency of scanned data • Enter 3d scan viewer to observe scanned data • restart 3d ground scan system in order to start new scan •...
  • Page 25: Using Detector Without Smartphone Application

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Share/save 3D scans / open scan • share screen as image or as comma separated values format (csv� data) that can be imported into other 3d mapping softwares • save 3d scan Browse stored scans / open scan In the 3d scan browser user can browse stored scans�...
  • Page 26: Technical Spec. & Warranty

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Technical spec. & warranty...
  • Page 27: Technical Specification

    TREASUREHUNTER3D Instruction manual Makes underground treasures visible Technical specification Weight: 1�2kg Material: Carbon & plastic Batteries: single 9V • 11” DD elliptical waterproof search coil for deep penetration Searchcoil: • 5” DD Round Closed Waterproof Search Coil Operating principle: VLF induction balance...
  • Page 28 TREASUREHUNTER3D Instruction manual Makes underground treasures visible TREASUREHUNTER3D Makes underground treasures visible www.treasurehunter3d.com info@treasurehunter3d.com...
