  • Page 1 Grants Automaton MANUAL 4G Door Station AN1404 4G Door Station (ACCESS CONTROL SYSTEM) For your protection, read these instructions completely and keep them for future reference. www.grantsautomation.com.au AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTION ..............3 AN1404 4G DOOR STATION INTRODUCTION ............4 AN1404 4G DOOR STATION WITH ACCESSORIES ..........4 INSTALLATION ....................... 5 AN1404 4G Door Station Unit Introduction ..............5 Wiring Diagram ......................7 LED Indicator ....................... 8 AN1404 4G DOOR STATION OPERATION..............

  • Page 3: Important Safety Instruction

    AN1404 4G DOOR PHONE INTRODUCTION The 4G Door Station AN1404 is an intercom system and access control device which can be installed at the entrance of a building, gate fence or door. The device can operate on local 12-24volt AC or DC power.

  • Page 4: An1404 4G Door Station Introduction

    10. Simple programming via SMS 11. Works with power supplies in the range 12~24V AC/DC. 12. Check dial in and out numbers log via SMS or E-mail 13. Works with mobile phones and land lines. AN1404 4G DOOR PHONE AND ACCESSORIES Item Description Q’ty...

  • Page 5: Installation

    INSTALLATION AN1404 4G Door Station Layout This 4G Door Station is suitable for both flush and surface mounting. Speaker Call Button Microphone Connector Antenna (Rear View) (Front View) (Surface Mounting Enclosure) (Side View) AN1404 4G Door Station Revision R11 Feb. 2020...
  • Page 6 4. Put the main station unit into the enclosure and fasten it with screws on top and bottom. 5. Connecting the flat cable (BLUE side face up) back to the back panel 6. Fasten the front panel with security screws AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 7: Wiring Diagram

    Register your SIM card with the network, and check it works in a mobile phone You MUST remove the PIN code from the SIM before inserting it in the AN1404. Ensure the power is OFF before inserting the SIM card. Carefully slide the SIM holder in the OPEN direction, insert the SIM, and slide in the CLOSED direction to lock it in place.

  • Page 8: Led Indicator

    Solid Red (power off) AN1404 4G Door Station Operation When the visitor pushes the call button to activate 4G door station, a ring tone will be heard from the Door Station. At the same time, a connection is being established with the phone number that is stored in the door station.

  • Page 9: Enter Listener Monitoring Mode

    * This feature can also be carried out by sending the same SMS commands * Under the monitoring mode speaker is OFF. (Press 35＃to turn on speaker) * You can still press * to active relay under this mode but speaker must be ON status. AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 10: Enter Access Control Mode

    *12*1234 # [command Code1] # [command Code 2] # [command Code3] #..Each SMS must start with the pass code , default 1234 in the following format *12*1234 # Followed immediately by a command. AN1404 4G Door Station Revision R11 Feb. 2020...
  • Page 11 Caller ID display (withhold the number) on the mobile before using to bypass. (Prefix the number with 1831) To gain access to the programming mode via phone follows these steps: AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 12: Door/ Gate Release

    CODE and mobile numbers into the memory before using. Example: Ireland Country code: 353 (UK: 44 / USA: 1) 086 5683624 (1. mobile number) 086 5682554 (2. mobile number) 086 2235644 (3. mobile number) AN1404 4G Door Station Revision R11 Feb. 2020...
  • Page 13 WCDMA network signal is poor will automatically switch to GSM to get better signal. Example SMS format: *20# SMS reply: Vodafone , WCDMA, Signal Level = 31 【Signal is very strong】 AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 14: Check Relay And Detect Status

    Example: Program a mobile number as an administrator number via SMS Mobile number: 0865682554 Command to use *12*1234#74 [Admin number]# SMS format *12*1234#740865682554# To delete the Admin number *12*1234#74*# AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 15: Check A Log Of Dial In And Dial Out Numbers Via E-Mail Or Sms

    *41*1234#SMTP server,port,user name, paANword, ( Doesn’t support Gmail) e-mail addreAN, e-mail sender name# Command code Example : *42*1234# recipient e-mail addreAN, recipient name, carbon copy e-mail addreAN, carbon copy name# Recipient & Carbon copy settings AN1404 4G Door Station Revision R11 Feb. 2020...
  • Page 16 When the device detects NITZ information is not available from the network will automatically send a command to itself via the SIM card used in the AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 17: How To Program Checking The Log Of Dial In Numbers Via Sms

    *12*1234 # [command Code1] # [command Code 2] # [command Code3] #..Example: Mobile number for receiving a log 0907967223 SIM phone number used in the 4G door station 0948778458 *12*1234#841#850907967223#860948778458# Send *44*1234# to check log Replied log information via SMS example: AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 18: User Commands

    Signal Level 0~31( from poor to best) Service provider name, network O [ number]…I [ number]…..E (N) O：call button numbers list I ：dial in to open numbers list Check stored numbers *21# E：End N：Next SMS AN1404 4G Door Station Revision R11 Feb. 2020...
  • Page 19 10~99 sec 20 sec (2 digit codes) Call Time 53 [call time] # call time= 005~999 sec 060 sec (3 digit codes) Monitoring duration time 55 [time] # Time= 00~60 minutes 10 mins AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 20: How To Reset The Hardware When You Forget Your Password

    EG. 11, 00, 112, 122, 88 are not recommended as echo cancellation network software may cancel the second same digit if entered quickly. Use passwords like 89, 12 , 23 , 56, 14, 123, 369 , 789 etc without repeating the same digit numbers. AN1404 4G Door Station Revision R11 Feb. 2020...

  • Page 21: Quick Programming Via Sms

    AN1404 4G Door Station Specification AN1404 4G Audio Intercom Model 700/850/900/1700/1800/2100/2300/2600 MHz Frequencies Operating Voltage 12 ~ 24 Volt AC/DC Operating Current Maximum 250mA, Typically 55mA CMOS camera module / 2 M pixels / lens angle 65.5∘ Camera Physical material...
  • Page 22 Press * to open Press # to hold open Press 1 to release again. Send SMS commands to have access control SMS format: *33*85678# (to open) *34*85678# (to hold open) *35*85678# (to release again) AN1404 4G Door Station Revision R11 Feb. 2020...
