  • Page 1 Litter Box STORAGE CABINET - Coffee Oak support@litterbox.com | 1.877.250.7729 | Mon-Fri, 9am-7pm EST...
  • Page 2 Thank you for purchasing the Litter Box Storage Cabinet! register your new product online www.sauder.com/service Jacob Zuppke, Founder of Litterbox.com Table of Contents Assembly Tools Required rewdriver Tip Sh Hardwar Assembly Steps 5-23 Hammer Français 24-26 27-29 Skip the p wer trip.

  • Page 3: Part Identification

    Now you know Part IdentificaTION our ABCs. While not all parts are labeled, some of the parts will have a label or an inked letter on the edge å to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. END PANEL (1) TOP (1) RIGHT FRONT LEG (1)

  • Page 4: Hardware Identification

    Hardware IdentificATION Screws are shown actual size. You may receive extra hardware with your unit. å 7F TWIST-LOCK ® HIDDEN FOOT - 1 CAM SCREW - 14 WOOD DOWEL - 12 CAM - 14 FASTENER - 11 CROSS SLOTTED MAGNETIC HINGE - 4 STRIKE PLATE - 2 KNOB - 2...
  • Page 5 Step 1 View our assembly video at www.litterbox.com/support Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. STOP To begin assembly, push eleven SAUDER TWIST-LOCK® å FASTENERS (7F) into the large holes in the UPPER SIDE If you purchased SKIRTS (G), UPPER BRACE (J), and BACK (K).
  • Page 6 Step 2 Push fourteen HIDDEN CAMS (1F) into the UPPER å BRACE (J), BACK (K), and BOTTOM (L). Arrow (14 used) Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 6 425616 www.litterbox.com/support...
  • Page 7 Step 3 Turn fourteen CAM SCREWS (8F) into the exact holes å shown in the LEGS (F and D) and SIDE SKIRTS (G and H). Do not use this hole. Do not use this hole. www.litterbox.com/support 425616 Page 7...
  • Page 8 Step 4 Push eight CROSS-SLOTTED DOWELS (24F) into the SIDE å SKIRTS (G and H) as shown. NOTE: The threads in the DOWEL should be pointed toward å the hole in the edge of the SIDE SKIRT. The long slot should face up and be parallel to the long edges of the SIDE SKIRTS.
  • Page 9 Step 5 Fasten the FOOT (1E) to the BOTTOM (L). Use one å BLACK 9/16" PAN HEAD SCREW (51S). BLACK 9/16" PAN HEAD SCREW (1 used in this step) www.litterbox.com/support 425616 Page 9...
  • Page 10 Step 6 Insert eight WOOD DOWELS (15F) into the SIDE SKIRTS (G and H). å Fasten the LEGS (C, D, E, and F) to the SIDE SKIRTS (G and H) exactly as å shown. Use eight BLACK 2-3/4" FLAT HEAD BOLTS (143S). NOTE: The BOLTS will thread into the DOWELS in the SIDE SKIRTS.
  • Page 11 Step 7 Insert one WOOD DOWEL (15F) into the RIGHT REAR LEG (D). å Fasten the BACK (K) to the RIGHT REAR LEG (D). Tighten å three HIDDEN CAMS. NOTE: Be sure the WOOD DOWEL in the LEG inserts into å...
  • Page 12 Step 8 Fasten the BOTTOM (L) to the LOWER SIDE SKIRT (H). å Tighten three HIDDEN CAMS. Fasten the BOTTOM (L) to the BACK (K). Use two BLACK å 1-15/16" FLAT HEAD SCREWS (113S). C A M D E N H I D i t h f a c...
  • Page 13 Step 9 Insert one WOOD DOWEL (15F) into the UPPER SIDE SKIRT (G). å Fasten the UPPER BRACE (J) to the UPPER SIDE SKIRT (G). å Tighten one HIDDEN CAM. NOTE: Be sure the WOOD DOWEL in the UPPER SIDE SKIRT å...
  • Page 14 Step 10 Insert two WOOD DOWELS (15F) into the LEFT REAR LEG (F) and UPPER SIDE SKIRT (G). å Fasten the LEFT REAR LEG (F) to the BACK (K). Tighten three HIDDEN CAMS. å NOTE: Be sure the WOOD DOWEL in the LEG inserts into the BACK. å...
  • Page 15 NOTE: If you purchased the 425766 Hutch, go to that book now å to prepare the TOP (B) for fastening the Hutch if you have not Thinking outside the already done so. litter box. Push the MAGNETIC CATCHES (3I) into the holes in the TOP (B). å www.litterbox.com/support 425616...
  • Page 16 Step 12 Carefully stand your assembly upright. å How to use the SAUDER TWIST-LOCK® FASTENER Fasten the TOP (B) to the UPPER SIDE SKIRTS (G), 1. Insert the dowel end of the FASTENER into the å hole of the adjoining part. UPPER BRACE (J), and BACK (K).
  • Page 17 Step 13 With a hammer, gently tap four SHELF SNAPS (6R) into the å holes in the END PANEL (A). www.litterbox.com/support 425616 Page 17...
  • Page 18 Step 14 You have the option of having the opening for the å litter-robot® on the right or left side of your unit. Opening on the left Opening on the right Page 18 425616 www.litterbox.com/support...
  • Page 19 Step 15 Insert four METAL PINS (1R) into the holes in the LEGS (C å and D) or LEGS (E and F) according to your choice for the litter-robot® opening. Set the END PANEL (A) against the METAL PINS so the SHELF SNAPS are resting on the METAL PINS.
  • Page 20 Step 16 Fasten the STRIKE PLATES (6I) to the DOORS (M). Use two å BLACK 1/2" FLAT HEAD SCREWS (11S). Almost time to celebrate! Fasten the HINGES (2H) to the DOORS (M) exactly as shown. With a cat nap. å Use eight BLACK 9/16"...
  • Page 21 Step 17 Fasten one of the DOORS (M) to the RIGHT FRONT LEG (C). Use four BLACK 9/16" LARGE å HEAD SCREWS (1S). NOTE: Be sure the HINGES are even with the front edge of the LEG. å Fasten one KNOB (5K) to the DOOR (M). Use one GOLD 1" MACHINE SCREW (50S). å...
  • Page 22 Step 18 Push four HOLE PLUGS (11P) into the empty holes in the å LEGS (C and D) or (E and F). Using your hammer, gently tap a CAM COVER (12P) onto å each visible HIDDEN CAM in the BACK (K). (6 used) To cover HIDDEN CAMS Page 22...
  • Page 23 Step 19 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. å And to celebrate, why not share your success story at litterbox.com or www.litterbox.com/support 425616 Page 23...

  • Page 24: Liste De Pièces

    Litière MEUBLE DE Modèle 425616 RANGEMENT - Chêne café Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
  • Page 25 ÉTAPE 1 ÉTAPE 7 Ne pas serrer les FIXATIONS TWIST-LOCK® à cette étape. Insérer une CHEVILLE EN BOIS (15F) dans le PIED ARRIÈRE DROIT (D). Assembler l'élément sur un sol à moquette ou sur le carton vide Fixer l' A RRIÈRE (K) au PIED ARRIÈRE DROIT (D). Serrer trois pour éviter d' e ndommager l'élément ou le sol.
  • Page 26 ÉTAPE 12 ÉTAPE 16 Relever, avec précaution, l'assemblage dans sa position verticale. Fixer les PLAQUES DE BUTÉE (6I) aux PORTES (M). Utiliser deux VIS TÊTE PLATE 13 mm NOIRES (11S). Fixer le DESSUS (B) aux PLINTHES LATÉRALES SUPÉRIEURES (G), à l'ENTRETOISE SUPÉRIEURE (J) et l’ A RRIÈRE (K). Serrer onze Fixer les CHARNIÈRES (2H) aux PORTES (M) exactement comme FIXATIONS TWIST-LOCK®.

  • Page 27: Lista De Partes

    Caja de arena ARMARIO DE Modelo 425616 ALMACENAMIENTO - Roble café Use estas instrucciones de ensamblaje en español junto con las CONTÁCTENOS PRIMERO fi guras paso-a-paso provistas en el folleto inglés. Cada paso en ANTES DE HACER DEVOLUCIONES A LA TIENDA. español corresponde al mismo paso en inglés.
  • Page 28 PASO 1 PASO 7 No apriete los SUJETADORES TWIST-LOCK® en este paso. Inserte un PASADOR DE MADERA (15F) en la PATA POSTERIOR DERECHA (D). Ensamble la unidad sobre un piso alfombrado o sobre el cartón vacío para evitar rayar la unidad o el piso. Fij e el DORSO (K) a la PATA POSTERIOR DERECHA (D).
  • Page 29 PASO 12 PASO 16 Coloque con cuidado el ensamble en posición vertical. Fij e las PLACAS DE CONTACTO (6I) a las PUERTAS (M). Utilice dos TORNILLOS NEGROS DE CABEZA PERDIDA de 13 mm (11S). Fij e el PANEL SUPERIOR (B) a los FALDONES LATERALES SUPERIORES (G), a la RIOSTRA SUPERIOR (J) y al DORSO (K).
  • Page 30 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Children climbing on furniture. •...

  • Page 31: Year Limited Warranty

    1-YEAR LIMITED WARRANTY 1. Sauder Woodworking Co. (Sauder®) provides limited warranty coverage to the original 4. This Warranty applies only to warranted defects that fi rst arise and are reported purchaser of this product for a period of one year from the date of purchase against to Sauder within the warranty coverage period.
  • Page 32 If you need assistance, please contact our Michigan-based Customer Service team support@litterbox.com | 1.877.250.7729 | Mon-Fri, 9am-7pm EST (except holidays) Learn more at www.litterbox.com/support General Conformity Certificate This certificate applies to the Sauder Woodworking Product identified by this Instruction Book. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
