AVLT-Power AVLT-MT41-1 Installation Manual

Vesa

VESA Adapter AOC 57, 67 Series

AVLT-MT41-1

AP4-0092A

UNPACKING INSTRUCTIONS

Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage.

Check package contents against the Supplied Parts List in the next page to assure that all components were

received undamaged. Do not use damaged or defective parts.

Carefully read all instructions before attempting installation.

Install and operate this device with care. Please read this instruction before beginning the installation, and carefully

follow all instructions contained herein. Use proper safety equipment during installation.

Please call a qualified installation contractor for help if you:

If you don't understand these directions or have any doubts about the safety of the installation.

If you are uncertain about the nature of your wall, consult a qualified installation contractor.

Do not use this product for any purpose or in any configuration not explicitly specified in this instruction. We hereby

disclaim any and all liability for injury or damage arising from incorrect assembly, incorrect mounting, or incorrect use

of this product.

Note:

The mounting components and hardware supplied in this package are not designed for installations to walls with steel studs

or to cinder block walls. If the hardware you need for your installation is not included, please consult your local hardware store for

proper mounting hardware for the application.

AOC

i2067f

i2367F

i2367Fm

i2367Fh

i2757Fh

i2757Fm

i2267Fw

i2267Fwh

Table of Contents

Do you have a question about the AVLT-MT41-1 and is the answer not in the manual?

Page 1 AVLT-MT41-1 AP4-0092A UNPACKING INSTRUCTIONS Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List in the next page to assure that all components were received undamaged.
Page 2 Step1 Remove Monitor Base Supplied Parts List (1)Adaptor Bracket-a (2)Set Screw-c (4)M4x12 Thumb Bolt-b (1)Allen Key-d Depress the button on the base and detach it from the monitor. Attach Adaptor Bracket to Connect the Adaptor Bracket Step2 Step3 Monitor to VESA Plate Attaching the Adaptor Bracket(a) to the curved Connect the VESA plate to the Adaptor Bracket pole on the back of the monitor.Using Allen Key...
