EDGARSSON SECURITY DESIGNS

GSM-VAC4+LITE

VOICE & SMS GSM ALARM

COMMUNICATOR

INSTALLER'S MANUAL

V 1.0

EDGARSSON SECURITY DESIGNS, CILYMAENLLWYD HOUSE, LOGIN, WHITLAND, SA34 0XA

Phone 01437 563 900

Fax 01437 563475

Email info@edgarsson.co.uk

Web pages at www.edgarsson.co.uk

Table of Contents

Need help?

Do you have a question about the GSM-VAC4+LITE and is the answer not in the manual?

Questions and answers

Summary of Contents for Edgarsson GSM-VAC4+LITE

Page 1 S S S S EDGARSSON SECURITY DESIGNS GSM-VAC4+LITE VOICE & SMS GSM ALARM COMMUNICATOR INSTALLER’S MANUAL V 1.0 EDGARSSON SECURITY DESIGNS, CILYMAENLLWYD HOUSE, LOGIN, WHITLAND, SA34 0XA Phone 01437 563 900 Fax 01437 563475 Email info@edgarsson.co.uk Web pages at www.edgarsson.co.uk...
Page 2: Table Of Contents
TABLE OF CONTENTS 1.1 R ....................................8 ECORDING MODE 1.2 PLAY......................................8 1.3 PROGRAMMING TELEPHONE NUMBERS - TN........................9 1.3.1 TN remote programming by SMS........................10 1.4 PROGRAMMING INPUT STATUS - IN............................10 1.4.1 IN parameter remote programming by SMS....................11 1.5 DE – DD................................11 LAY BEFORE DIAL 1.5.1 DD remote programming by SMS........................11 1.6 INPUT FILTER PARAMETR –...
Page 3 1.19 DTMF REMOTE COMMAND TABLE............................25 1.19.1 Receive all parameters (PALL) ........................26 1.19.2 Receive telephone numbers (PTN).........................26 1.19.3 Receive links (PLN)............................26 1.19.4 Receive input parameters (PIN)........................26 1.19.5 Receive input filter value (PID)........................26 1.19.6 Receive delay before dial value (PDD)......................26 1.19.7 Receive clip identification functions (PTC)....................26 1.19.8 Receive access telephone numbers (PSL)......................27 1.19.9 Receive output parameters (POS)........................27 1.19.10 Receive link for local alarm output (POD)....................27...
Page 5 GSM-VAC4+LITE INSTALLER’S MANUAL FOR YOUR SAFETY Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information. SWITCH ON SAFELY Do not switch the unit on when wireless phone use is prohibited or when it may cause interference or danger.
Page 6 GSM-VAC4+LITE INSTALLER’S MANUAL FEATURES ⇒ Built in GSM module ⇒ 2 alarm inputs ⇒ 2 remote control alarm outputs ⇒ Pre-recorded alarm messages – 1 for each alarm input ⇒ SMS for each alarm input ⇒ Memory stores up to 4 different telephone numbers ⇒...
Page 7 GSM-VAC4+LITE INSTALLER’S MANUAL DESCRIPTION The GSM-VAC4+-GSM is a new kind of a mobile voice and SMS dialing system. The phone memory in the form of a SIM card is used either to store telephone numbers or to program certain parameters. The alarm event is possible send on to 4 different telephone numbers. The alarm inputs can be normal open (N.O.) and are thus triggered by a positive (+12V) or a negative pulse (GND);...
Page 8 GSM-VAC4+LITE INSTALLER’S MANUAL START UP ⇒ Insert SIM card to be used for GSM-VAC4+ LITE in your personal mobile phone. ERASE THE PIN CODE! ⇒ ⇒ Enter telephone numbers and the required operating parameters in SIM memory – at least 1 telephone No.
Page 9 GSM-VAC4+LITE INSTALLER’S MANUAL LED DISPLAY Blue LED (LED1) – Indicate the level of the GSM signal from 1-5 LED flash (1 = weak signal, 5 excellent signal) Red LED (LED2) When the LED 2 is ON the unit has a problem with a GSM network connection or the GSM part of the unit is out of order.
Page 10 GSM-VAC4+LITE INSTALLER’S MANUAL PURPOSE AND APPLICATION The GSM-VAC4+ LITE mobile device can provide us with different information on the state of the alarm mounted on the protected object. It can also transmit other useful information important for operating applications such as: ⇒...
Page 11 GSM-VAC4+LITE INSTALLER’S MANUAL CONNECTING DIAGRAM Page 7...
Page 12: Recording Mode
GSM-VAC4+LITE INSTALLER’S MANUAL VOICE MESSAGES – RECORD & PLAY The memory of each alarm input enables us to record our own voice message in the total length of 10 seconds. The device is namely equipped with a Play/Record audio connector. For recording and listen recorded message the headset is necessary.
Page 13: Programming Telephone Numbers - Tn
GSM-VAC4+LITE INSTALLER’S MANUAL GSM-VAC4+ LITE PROGRAMMING MODE All data, programming values and telephone numbers need to be stored in the phone book located on the SIM card. The GSM-VAC4+ LITE is possible to program on 4 different ways: ⇒ Using the USB SIM manager on the PC - recommended ⇒...
Page 14: Tn Remote Programming By Sms
GSM-VAC4+LITE INSTALLER’S MANUAL 1.3.1 TN remote programming by SMS For the upper example send the following SMS from the host phone to the GSM-VAC4+ LITE: ; TN1=042376678; TN2V=040719479; TN3M=040308350; If you want to get the confirmation SMS back then write “+” before SMS command: ;...
Page 15: In Parameter Remote Programming By Sms
GSM-VAC4+LITE INSTALLER’S MANUAL GSM-VAC4+ LITE- GSM PROGRAMMING TABLE SIM CARD PHONE BOOK Name Number Description Alarm activated by connecting to GND Alarm activated by disconnecting GND or +12V 1.4.1 IN parameter remote programming by SMS For the upper example send the following SMS from the host phone to the GSM-VAC4+ LITE: ;...
Page 16: Input Filter Parametr - Id
GSM-VAC4+LITE INSTALLER’S MANUAL INPUT FILTER PARAMETR – ID The ID parameter determine time period of the pulse length to trigger the Input. The pulse time can be from 0, 5 second up to 9999 seconds. The default time is 0,5 seconds when the parameter value is 0.
Page 17: Programming Output Status - Os
GSM-VAC4+LITE INSTALLER’S MANUAL PROGRAMMING OUTPUT STATUS - OS The GSM-VAC4+ LITE device has two open collector outputs and each of them can be programmed through network in a different way: as a bi-stable or mono-stable (pulse) output. The programming time is in seconds.
Page 18: Direct Alarm Output - Od
GSM-VAC4+LITE INSTALLER’S MANUAL DIRECT ALARM OUTPUT – OD If you want to activate a local alarm (siren) you can program any GSM-VAC4+ LITE output for this function. OD5 to OD8 are links between fictive inputs like telephone line failure, GSM failure to dedicated output.
Page 19: Programming Table For Linking The Inputs And Telephone Numbers - Ln
GSM-VAC4+LITE INSTALLER’S MANUAL 1.9.1 Programming table for linking the inputs and telephone numbers – LN GSM-VAC4+ LITE- GSM PROGRAMMING TABLE SIM CARD PHONE BOOK Name Number (default) Description Input & telephone No. linking for 1 alarm input (TN1 – TN0) Input &...
Page 20: Programming Table For The Main Power Lost And Telephone Numbers Linking
GSM-VAC4+LITE INSTALLER’S MANUAL 1.10.1 Programming table for the MAIN POWER LOST and telephone numbers linking GSM-VAC4+ LITE- GSM PROGRAMMING TABLE SIM CARD PHONE BOOK Name Number (Default) Description Telephone number from TN1 to TN0 Example: GSM-VAC4+ LITE- GSM PROGRAMMING TABLE...
Page 21: Ln4 Remote Programming By Sms
GSM-VAC4+LITE INSTALLER’S MANUAL 1.11.2 LN4 remote programming by SMS For the upper example send the following SMS from the host phone to the GSM-VAC4+ LITE: ; LN6=12; If you want to get the confirmation SMS back then write “+” before SMS command: ;...
Page 22: Input Time Window - It
GSM-VAC4+LITE INSTALLER’S MANUAL 1.13 INPUT TIME WINDOW – IT The IT parameter determinate the time window within we can trigger (n) alarms (programmed by AR parameter) before the input will automatically blocks. After the IT time the input will be setting free and it will start counting alarm triggers (AR) again.
Page 23: The Input Trigger Counter Before Block Remote Programming By Sms
GSM-VAC4+LITE INSTALLER’S MANUAL GSM-VAC4+ LITEPROGRAMMING TABLE SIM CARD PHONE BOOK NAME NUMBER DESCRIPTION The Input has been blocked after 3 alarm triggers The Input has been blocked after 10 alarm triggers 1.14.1 The input trigger counter before block remote programming by SMS For the upper example send the following SMS from the host phone to the GSM-VAC4+ LITE: ;...
Page 24: Security Level - Sl
GSM-VAC4+LITE INSTALLER’S MANUAL 1.15 SECURITY LEVEL - SL Which telephone number stored into the phone book from TN1 – TN4 can enter into programming and remote control unit of the GSM-VAC4+ LITE(dialing the GSM-VAC4+ LITE No. or sending the SMS) is defined by SL parameter form SL0 to SL4.
Page 25: Pre-Pay Card Credit And Validity Information
GSM-VAC4+LITE INSTALLER’S MANUAL 1.16 PRE-PAY CARD CREDIT AND VALIDITY INFORMATION If we use the pre-pay SIM card into the GSM-VAC4+ LITE it is very useful if we can get the information about remain credit. The GSM providers have different ways to get the credit information. At the moment we can hold up 3 different strings.
Page 26: Gsm-Vac4+ Liteset-Up Paramerters
GSM-VAC4+LITE INSTALLER’S MANUAL 1.17 GSM-VAC4+ LITESET-UP PARAMERTERS ⇒ CRE – repetition of calling sequences. With the number from 1 to 99 we define how often the sequence is repeated in case the number is busy or not answered. The default value is set to number “3”.
Page 27: Set-Up Parameters Programming By Sms
GSM-VAC4+LITE INSTALLER’S MANUAL Programming table for GSM-VAC4+ LITE Set-up parameters GSM-VAC4+ LITE- GSM PROGRAMMING TABLE SIM CARD PHONE BOOK Name Number Description Number of dialing attempts (1 – 99) Hidden telephone number (1= displayed, 0 = hidden) Number of rings before answering...
Page 28: Sms Messages Editor
GSM-VAC4+LITE INSTALLER’S MANUAL 1.18 SMS MESSAGES EDITOR You can write and send a short SMS message for each alarm input. The default message is English but the language is possible change with LNG parameter. Each message is build from 3 parts and user can write the first (User Location) and the second (alarm event) part of the message.
Page 29: Dtmf Remote Command Table
GSM-VAC4+LITE INSTALLER’S MANUAL GSM-VAC4+ LITE DTMF REMOTE COMMANDS NOTE: If you can’t enter into remote mode, check the SL level first! 1.19 DTMF REMOTE COMMAND TABLE REMOTE COMMAND ACTION DESCRIPTION All outputs OFF All outputs ON Output 1 OFF Output 1 ON...
Page 30: Receive All Parameters (Pall)
GSM-VAC4+LITE INSTALLER’S MANUAL PRINT-OUT OF THE PARAMETERS 1.19.1 Receive all parameters (PALL) Command; PALL; Sending this command to the GSM-VAC4+ LITE you will get 14 SMS back from it with all parameters that are currently programmed in the unit. 1.19.2 Receive telephone numbers (PTN) Command;...
Page 31: Receive Access Telephone Numbers (Psl)
GSM-VAC4+LITE INSTALLER’S MANUAL 1.19.8 Receive access telephone numbers (PSL) Command ;PSL; Sending this command to the GSM-VAC4+ LITE you will get back the SMS with programmed SL level. 1.19.9 Receive output parameters (POS) Command ;POS; Sending this command to the GSM-VAC4+ LITE you will get back the SMS with all currently programmed Outputs parameters (OS1 –...
Page 32: State Of The Outputs (Porc)
GSM-VAC4+LITE INSTALLER’S MANUAL Sending this command to the GSM-VAC4+ LITE you will get back the SMS with Credit amount on your Pre-pay SIM card (for Vodafone GSM Italian provider). 1.19.15 State of the outputs (PORC) Command ;PORC; Sending this command to the GSM-VAC4+ LITE you will get back the SMS with current outputs state.
Page 33: Checking System Status By Sms Command
GSM-VAC4+LITE INSTALLER’S MANUAL CHECKING AND CHANGING THE SYSTEM STATUS (ON/OFF) 1.20 CHECKING SYSTEM STATUS BY SMS COMMAND Sending this command to the GSM-VAC4+ LITE you will get back the SMS with state of the system. Command ;SYS; The replay SMS can be: ⇒...
Page 34: Checking The Input Status By Dtmf
GSM-VAC4+LITE INSTALLER’S MANUAL CHECKING THE INPUT STATUS You can get the information's about inputs status on two different ways: ⇒ Call in the GSM-VAC4+ LITE and use DTMF commands ⇒ Send the SMS command and get back the SMS with inputs status 1.24 CHECKING THE INPUT STATUS BY DTMF...
Page 35: Outputs Remote Control By Sms Command
GSM-VAC4+LITE INSTALLER’S MANUAL OUTPUTS REMOTE CONTROL You can use outputs remote control on two different ways: ⇒ calling the GSM-VAC4+ LITE and use DTMF commands ⇒ send the SMS command and get back the SMS with outputs status 1.26 OUTPUTS REMOTE CONTROL BY SMS COMMAND Command ;ORCX=1;...
Page 36 GSM-VAC4+LITE INSTALLER’S MANUAL CLEAR ALL PROGRAMMED DATA FROM SIM Command ;SDCLR; Sending this SMS to the GSM-VAC4+ LITE will clear all before programmed parameters and numbers. This is highly recommended when the SIM you’ll use for the GSM-VAC4+ LITE is not new and it already has some data stored into the phone book memory.
Page 37 GSM-VAC4+LITE INSTALLER’S MANUAL CHANGEING PARAMETERS USING COMMAND You can send all programming parameters to the GSM-VAC4+ LITE by SMS command. Each SMS command should start and stop with semicolon. If the confirmation need we must put “+” on the beginning of the command.
Page 38 GSM-VAC4+LITE INSTALLER’S MANUAL TECHNICAL SPECIFICATION Description Value Power Supply (without using battery) 9VDC – 25VDC Power Supply (with connecting battery) 13,8VVDC – 14,5VDC Current consumption - pick Current consumption(transmit mode) 350 mA Current consumption (idle mode) 40 mA Tri band GSM module...
Page 39 GSM-VAC4+LITE INSTALLER’S MANUAL CONTACTS EDGARSSON SECURITY DESIGNS, CILYMAENLLWYD HOUSE, LOGIN, WHITLAND, SA34 0XA Phone 01437 563 900 Fax 01437 563475 Email info@edgarsson.co.uk Web pages at www.edgarsson.co.uk Page 3...
