Autofidelity AD-200A Instruction Manual

High definition integrated drive incident recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
High Definition Integrated
Drive Incident Recorder
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AD-200A and is the answer not in the manual?

Questions and answers

Summary of Contents for Autofidelity AD-200A

  • Page 1 High Definition Integrated Drive Incident Recorder Instruction Manual...
  • Page 2 Thank you for purchasing our product. All information in this manual is protected by copyright law. This manual is used in other products and services are registered trademarks of their respective owners. This manual is based on current specifications for the product. For example graphics and photos, features and details of the product hardware and software specifications are subject to change without notice Notice...

  • Page 3: Table Of Contents

    Contents Before using the product Productregistrationand notes ........... 6 Product features ................ 7 Safety precautions ..............9 Verifycomponentsofproducts ..........15 Nameofthe partsand function ..........16 Install product ................17 Connectrearviewcamera(2channelmodel) ........18 Alwaysconnectthe power ............. 19 Low voltage protection ............. 19 Use product Start it ..................
  • Page 4 Contents Event recording ................ 28 Parking record ................31 Additional functionality During operation, when remove the Micro SD......37 During operation, when power cable fallen ......37 During parking recording, when shocking event occurs ....38 Further information Micro SD card management ............ 40 Button action instruction ............
  • Page 5 Before using Product registration and notes ......6 Product features ..........7 Safety precautions .......... 9 Verify components of products ....15 Name of the parts and function ....16 Install product ..........17 Connectrearviewcamera .......... 18 Connectexternalmonitor ..........18 Alwaysconnectthepower ........... 19 Lowvoltageprotection ........

  • Page 6: Productregistrationand Notes

    Before using Product registration and notes Visit www.autofidelity.com.au to download the PC viewer. If you request after sales service, please bring your product warranty. Warranty is issued at the time of purchase, and is not reissued. Before using this product, please check attached serial number and then register on our website.

  • Page 7: Product Features

    Before using Product features HD quality video recording 2 Mega-pixel COMS Image Sensor captures high-definition video. 720p HD(1280 x 720 pixel)/30fps/16:9 Wide for front camera. 480P (640 x 480 pixel)/10fps for rear camera. Optimised viewing angle 120 degree wide viewing angle provides an excellent view without image distortion. Built-in high-definition microphone Captures high-definition sound with your video recording, and is user selectable from the device.
  • Page 8 Before using Active power monitoring Allows the system to continue recording while the vehicle is parked. Recording stops once the battery voltage drops too low to conserve your car battery. Built-in Real Time Clock (RTC) Includes date and time information with your recordings. Simplified status indication and voice prompts Get instant status updates via the operation indicator LED on the device, as well as voice prompts whenever a setting is adjusted.

  • Page 9: Safety Precautions

    Before using Safety precautions This product is designed as a driver assistance device to capture and record events that occur while driving, and while the vehicle is stationary. Recordings from this device are only intended to provide a reference. Please read the entire manual carefully before using the product. The warnings and cautions contained herein are intended to ensure the safety of the user and general public.
  • Page 10 Before using About product ¦ If the power supply is disconnected or the product Do not change product location. Keep it damaged because of an accident, normal fixed to where this manual indicates. video recording may be disrupted. • If you connect misplace, recording may not carry out normally.
  • Page 11 Before using Any obstruction on or in front of the lens of Do not attempt to adjust the device the device will impair its operation and whilst driving. • May cause a car degrade the quality of the recording. The lens should be kept accident.
  • Page 12 Before using This device must not interfere with the driver 's Do not leave this device or its components view when installed into a vehicle. unattended around infants, children or pets. • Smaller components may be swallowed or • Interference with driver's field of view could cause cause suffocation.
  • Page 13 Before using When cleaning the inside of the vehicle, do not spray water or wax directly on the device. • This may cause electric shock or product malfunction. Do not use products and components with this device unless certified by the manufacturer as being compatible.
  • Page 14 Before using Related power supply Do not use a damaged power cable When the power cable is plugged in and the • Risk of fire or electric shock. device not being used, turn OFF the power switch at the bottom of the product. •...

  • Page 15: Verify Components Of Products

    Before using Check product components Main black box Power cable MicroSD card (Design may vary depending on vehicle) Manual GPS (sold separately) Rear-view camera (2channel models only) • Components may vary depending on the product specifications, Note...

  • Page 16: Name Of The Parts And Function

    Before using Part names and functions Function description Parking mode indicator light: Parking mode ① or operating. ② Camera lens: Captures image from front of vehicle. ③ Micro SD slot: Insert micro SD card. Button / indicator light operation: Manual ④...

  • Page 17: Install Product

    Before using Installing the product 1. Insert MicroSD card As shown on the picture, insert the MicroSD card into the product. • Ensure the MicroSD card's connector pins are facing inwards. Note Forcing the MicroSD card in the wrong way may result in breakage and repairs will need to be paid for with after sales service.

  • Page 18: Connectrearviewcamera(2Channelmodel)

    Before using 4. MicroS' formaW • We recommend the MicroSD card format. The MicroSD card should be replaced periodically for a defect-free device. Connect rear-view camera (2channel models only) • Rear-view camera can be connected to the VIDEO IN socket. •...

  • Page 19: Alwaysconnectthe Power

    Before using Always connect the power • Before connecting the power, please read the information within this manual. • Power cable must only be plugged into the indicated area. If the cable is connected incorrectly, back voltage occurs which may damage to your product. Yellow wire(BATT+): Fuse box in the vehicle should always be powered.
  • Page 20 Using the product Getting started ............ 21 MicroSD card check........21 Continuous recording ......... 22 Manual recording ..........26 Eventrecording ................28 Parkingrecording ................31...

  • Page 21: Microsd Card Check

    Using the product Getting started When you connect the power, the LED indicator turns RED to indicate it is on. When recording begins, the LED indicator will then turn BLUE. LED : RED ON LED : BLUE ON Power connection Power ON with sound effect, starts “continuous recording” Continuous recording MicroSD card check If you do not have a MicroSD card inserted, the device will inform you with voice...

  • Page 22: Continuous Recording

    Using the product / Continuous recording Continuous recording Start continuous recording with voice Voice guidance: Start continuous guidance. The LED indicator will turn BLUE. recording Continuous recording with BLUE LED ON. Continuous recording management A recorded file will be generated per minute. Recorded file is stored on the MicroSD card. Insert the MicroSD card into your PC to view the files.
  • Page 23 Using the product / Continuous recording Continuous recording file characteristic (When recording 1channel) For 720p resolution, 30fps and .avi format, the recorded file is about 47MB in size for a 30 second file. Video Properties Audio Properties H. 264 (MPEG4 AVC) PCM encoding format PCM 1280 x 720 resolution 22.05 KHz sample rate...
  • Page 24 Using the product / Continuous recording During continuous recording, when you briefly press the main button twice it starts manual recording with sound effects. The indicator LED will flash RED. When manual recording ends, the indicator LED will turn BLUE, and then start continuous recording with BLUE on. LED : RED LED : BLUE On Press button two times briefly Sound effect Manual recording...
  • Page 25 Using the product / Continuous recording When impact is detected During continuous recording, when the acceleration sensor detects an impact, it starts event recording with event sound effects and the indicator LED with flash RED. When event recording ends, the indicator LED will flash BLUE and starts continuous recording with BLUE on.

  • Page 26: Manual Recording

    Using the product / Manual recording Manual recording Starts manual recording During continuous recording, briefly press the button twice, and the recording will begin with a sound effect. During manual recording, the indicator LED will flash RED. Complete manual recording The device continues continuous recording for 15 seconds before and after the BLUE LED is turned on.
  • Page 27 Using the product / Manual recording Manual recording file attributes For 720p resolution, 30fps and .avi format, the recorded file is approx. 23MB for a 30 second file. Move during manual recording During manual recording, events recorded during the impactare not supported. Manual recording file management The recorded file is saved on the MicroSD card in the event file.

  • Page 28: Event Recording

    Using the product / Event recording Event rec ording Start event recording During parking recording or continuous recording, if the acceleration sensor detects an impact, it LED : RED begins event recording with sound effect. Complete event recording When an impact is detected, the device will record 15 seconds before impact and 15 seconds after for a complete event recording.
  • Page 29 Using the product / Event recording Event Recording File Management 30 seconds (previous 15 seconds + after 15 seconds) of recording is created. The recorded file is saved to the MicroSD card in the event folder. The files can be managed via your PC, and up to 50 folders will be created to store recorded files.
  • Page 30 Using the product / Event recording Event recording file properties If previous mode iscontinuous recording at 720p resolution, 30fps and .avi file format, the recorded file size is 23MB for 30 seconds. If previous mode is parking recording at 15 - 23fps and .avi file format, the size of the recorded file is approximately 10MB - 18MB During Event recording During event recording, parking and continuous recording is not supported.

  • Page 31: Parking Record

    Using the product / Parking record Parking record Parking record definition The definition of parking is if no movement within the camera's field of view is detected, and will go into standby and stop recording. When motion is detected, the device will record for a certain period of time.
  • Page 32 Using the product / Parking record Auto parking mode This unit allows for automatic parking mode • Start parking mode: If ACC+ power is on, after approximately one minute, the parking recording will start • End of the parking mode: When ACC+ power is detected, the device automatically switches to continuous recording.
  • Page 33 Using the product / Parking record Complete parking record. If ACC+ power is detected and BATT+ power settings are complete, the device will start continuous recording with voice guidance and the indicator LED will turn BLUE. LED : BLUE On Voice guidance “It Parking record Condition satisfaction...
  • Page 34 Using the product / Parking record Parking record file management 15 seconds before motion is detected and 15 seconds after motion has ceased is recorded for a total of 30 seconds. The recorded file is stored on the MicroSD card. The recorded file can be managed on your PC, and up to 50 sub-folders will be created.
  • Page 35 Using the product / Parking record Parking record file feature Recording is at 720p resolution, 15 - 23fps in .avi format. A file of 30 seconds is approx. 10MB - 37MB. During the parking record During parking recording, manually recording is not supported. When impact is detected During parking recording, if impact is detected by the acceleration sensor, it begins event recording and event sound effect.
  • Page 36 Additional function Removing the MicroSD card when in operation ..........37 When impact event occurs during When cable is removed during operation…………………….37 record…………………………………38 parking When you use MicroSD After connecting power to the body and pressing the main button for a brief period, you can start then MicroSD card format function.
  • Page 37 Additional function Removing the MicroSD card when in operation During all recording modes (continuous recording, manual recording, event recording, parking recording), if you remove the MicroSD card the device will reboot and enter 'record ready mode'. If you remove the MicroSD card while in operation, recorded files will not be stored in their normal condition.
  • Page 38 Additional function If the power cable is removed during manual recording and event recording, power, sound effect and recording in progress turns off automatically. LED : RED LED : OFF Event recording Take out power cable Sound effect: Power OFF Recording end during progress Power OFF If you remove the MicroSD card before the power is completely turned off the last...
  • Page 39 기 타 Other information 정 MicroSD card management ......40 보 Button operation guide........41 LED condition mark manual ......41 Voice guidance or sound effect guidance ... 42 Product specification ........43 Support / AS Service ........45 Product warranty ..........47...

  • Page 40: Microsd Card Management

    Other information MicroSD card management Memory Management 1. Continuous recording area 4. Parking record area Folder name: Continuous recording Folder name: Motion recording Area use: 60% of the available area (8GB Standard Use area: 10% of the available area (8GB standard about 4.47GB) about 762MB) Number of files: 72 (1 minute per file at 62MB)

  • Page 41: Button Operation Guide

    Other information Button operation guide Button in each mode of operation of the product is as follows: Mode Press the button shorter Press the button longer Remark Continuous recording Convert MIC ON/OFF MicroSD card format Manual recording No action No action Event recording No action No action...

  • Page 42: Product Specification

    Product Specification Voice guidance or sound effect guidance In each mode, the product’s voice prompts and sound effects are as follows: Voice guidance / Sound effect Mode Remark Start continuous recording During booting Sound effect Booting Voice guidance At the start of continuous recording At the beginning of the recording manual Event Sound effect...

  • Page 43: Product Specification

    Product Specification Specifications Mode Remark CareVue Model Name 1 or 2 channel Number of channel 2.0 Megapixel camera CMOS2.0 Camera 1/3.2 inch Rear D1 level CMOSD camera (option) 1CH : 1,280 x 720p, 30fps Recording resolution 2CH : 1,280 x 720p, 20fps (front) Frame 640 x 480p, 10fps (rear) H.264 / MPEG-4 AVC...
  • Page 44 Product Specification Specifications Division Remark When recording, Manual recording, Event (impact) Driving recording mode recording Parking mode recording (motion Parking mode recording When installing power detection) Event (impact) recording Operating temperature 0~60°C Operating voltage DC 12V ~ 24V...

  • Page 45: Support / As Service

    Support / AS Service 1) Function failure up to 7 days after purchase • Exchange the faulty device at the location in which it was purchased. This can be done up to 7 days after purchase. • Contact after sales for support. •...

  • Page 46: Support & After Sales Service

    Support / After Sales Service 4) Paid after sales service • Determined by the after sales criteria. • Through the guidance of technical support, we would check the exact cost. • Paid after sales - If user fault is obvious - If the warranty period has passed...

  • Page 47: Product Warranty

    Product warranty This product has passed strict quality control measures and inspection. Within the warranty period, if malfunction occurs, support service information is contained below. Model number Serial number Main body 1 year Warranty period Accessories 3months and consumables Purchase date...
  • Page 48 Autofidelity Pty Ltd | ABN: 47 120 910 269 26-28 Kilpa Road Moorabbin, Victoria Australia 3189 P.O. Box 122 Moorabbin, Victoria Australia 3189 P: +61 3 9555 7343 | F: +61 3 9555 7379 | M: +61 4 12 114 514...
