■Features
◎ Accept more type sensors(switch,encoder,proximity.etc)
◎ Accept input rates up to 10KHz
◎ Readout range from -199999~999999
◎ Four counting modes Up,Down,Up/Down,Quadrature
◎Power down saving
◎ Decimal point can be modified
◎ Input scaling multiplied 0.00001~9.99999 can be modified
◎ Reset by panel or connect terminal
■Name of parts
Count value display
Setting value display
Per digit setting keys
■Connect diagram
◎Contact input(PNP)
IN
Inside jumper
12V
1
OFF ON ON OFF
COM
◎Contact input(NPN)
IN
Inside jumper
12V
1
ON OFF ON OFF
COM
■Alarm output control mode description
◎N(MANUAL): When count value equal setting value the relay ON & continue count until reset by panel or connect terminal
then relay OFF & count value return to RST setting value
◎R(RETURN): When count value equal setting value the relay ON & continue count until relay action time out then relay
OFF & count value return to RST setting value
◎ C(CONTINUE): When count value equal setting value the relay ON & count value return to RST setting value then continue
count & relay action time out the relay OFF
◎ N/R/C control mode is according to AL1 setting value
◎ WARN: When count to [AL1 value(digit 1~4)
AXE 6 Digit Microprocess Counter (72x72mm)
PV
SV
6
◎CMOS input(12V or 15V)
2
3
4
GND
◎TTL input(5V)
2
3
4
GND
-
◎ Quadrature sensing up to 4 times resolution
◎ Alarm output can programmable per-warn mode
◎ N,R,C alarm control mode
◎ Alarm output action times 0.1~99.9 sec. Can be modified
◎ 0.36" highlight display
◎ Man-machine interface,easy to operate
◎ EEPROM Saving,data safekeeping about 10 years
◎ Modified inside parameter,must have pass code
OUT1 OUT2 OUT3
AL1 AL2
5
4
3
2
IN
Inside jumper
12V
1
2
3
OFF ON OFF OFF
COM
IN
Inside jumper
12V
1
2
3
OFF ON OFF ON
COM
warn value(digit 5~6)]RELAY 2 ON , count to AL1 value RELAY 1 ON
RST
AL
Function keys
SEL
ENT
1
◎Sensor input(PNP 12V)
IN
12V
Sensor
4
COM
◎Sensor input(NPN 12V)
IN
12V
Sensor
4
COM
MC726 Series
Inside jumper
1
2
3
4
OFF ON OFF OFF
Inside jumper
1
2
3
4
ON OFF OFF OFF
